KNOW YOUR PRODUCT
INVERTER
GENERATOR
• 4000W MAX. POWER
• 3500W RUNNING WATTS
• 2 X 240V 15A POWER OUTLETS
• PARALLEL CAPABILITY
• USB PORT
INSTRUCTION MANUAL
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
0620

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD4000IRS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Full Boar SD4000IRS

Summary of Contents for Full Boar SD4000IRS

  • Page 1 KNOW YOUR PRODUCT INVERTER GENERATOR • 4000W MAX. POWER • 3500W RUNNING WATTS • 2 X 240V 15A POWER OUTLETS • PARALLEL CAPABILITY • USB PORT INSTRUCTION MANUAL WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.

  • Page 2: Specifications

    SPECIFICATIONS - MODEL NO. SD4000IRS ENGINE GENERATOR Motor type: 4-stroke, OHV, 1-cylinder AC Output: 240V Displacement: 224 cm³ 50Hz Engine speed: 3100/min̄ ¹ ( ECON switch is off) 14.6 Amp 3500W Rated Ignition system: C.D.I 4000W Max. Oil capacity: 600 ml DC Output: 12V, 8.0 Amp...
  • Page 3 KNOW YOUR PRODUCT (cont.) AC 240V AC 240V 5V DC 1.0A CHOKE 2.1A 12V DC 8A PARALLEL AC SW. OPERATION OUTLETS ECONOMY OVERLOAD OUTPUT 21 22...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS............Page 02 KNOW YOUR PRODUCT........... Page 02 INTRODUCTION............Page 05 SAFETY INSTRUCTIONS........... Page 05 EXPLANATION OF RISKS ......... Page 08 PRE-OPERATION CHECK.......... Page 12 OPERATION............... Page 14 MAINTENANCE............Page 20 TRANSPORTING & STORAGE ........Page 23 TROUBLE SHOOTING ..........

  • Page 5: Introduction

    The petrol generator has been designed to output 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Full Boar tools are interchangeable for Australia and New Zealand.
  • Page 6 SAFETY WARNINGS FOR GENERATORS IMPORTANT! When using the equipment, a few safety precautions must be observed to avoid injuries and damage. Please read the complete operating manual with due care. Keep this manual in a safe place so that the information is available at all times.
  • Page 7 SAFETY WARNINGS FOR GENERATORS (cont.) • Your power tool should only be passed on with these instructions. • Children should be supervised to ensure they do not play with the appliance. WARNING! Do not parallel connect other cables to receptacles, use special jack, or it may cause an electrical shock.

  • Page 8: Explanation Of Risks

    RISK OF ELECTROCUTION AND FIRE Hazard What could happen How to prevent it Improper storage Extension cord can come into Remove extension cord from the of extension cord. contact with hot engine parts generator and store separately resulting in damage. Using a away from generator.
  • Page 9 RISK OF FIRE Hazard What could happen How to prevent it Attempting to fill Fuel and fuel vapours can Turn engine off and allow it to the fuel tank while become ignited by coming in cool before adding fuel to the the engine contact with hot components tank.
  • Page 10 RISK OF INJURY AND PROPERTY DAMAGE WHEN TRANSPORTING GENERATOR Hazard What could happen How to prevent it Fire, Inhalation, Fuel or oil can leak or spill and Transport fuel only in an Damage to Vehicle could result in fire or breathing approved fuel container.
  • Page 11 RISK OF UNSAFE OPERATION Hazard What could happen How to prevent it Operation of All sources of energy include Review and understand all of generator in careless the potential for injury. Unsafe the operating instructions and manner operation or maintenance of warnings in this manual.

  • Page 12: Pre-Operation Check

    PRE-OPERATION CHECK Checking the oil Note: The generator is shipped without oil and must be filled before starting. Oil tank capacity 600 ml. 1. Be sure to check that the generator is on a level surface with the engine stopped. 2.
  • Page 13 KNOW YOUR PRODUCT PRE-OPERATION CHECK (cont.) Refuelling the generator Upper level allowed WARNING! Never refuel the inverter generator while the engine is running and always allow the engine to cool before refuelling. WARNING! Keep away from cigarettes, smoke and sparks when refuelling the inverter generator.

  • Page 14: Operation

    OPERATION KNOW YOUR PRODUCT Starting the inverter generator Note: Before starting the engine, disconnect all appliances from the generator. Note: Always operate the inverter generator on a dry surface free of any moisture. WARNING! Do not rest inverter on exhaust panel (26). Do not move Inverter Generator while it is on.
  • Page 15 AC SW. KNOW YOUR PRODUCT OPERATION (cont.) Stopping the engine Upper level allowed In normal operation 1. Switch off the connected equipment and pull out the plug. 2. Turn the AC switch (22) to OFF (O) (fig. 10). AC SW. Fig.
  • Page 16 OPERATION (cont.) Oil alert system The oil alert system is designed to prevent engine damage caused by an insufficient amount of oil in the crankcase. Before the oil level in the crankcase falls below a safe limit, the oil alert system will automatically shut down the engine (the engine control switch (5) will remain in the RUN position).
  • Page 17 OPERATION (cont.) AC Applications Check the total rating of the appliance to be connected and ensure the rating of the appliance/s does not exceed the rating of the inverter generator. 1. Make sure the output indicator LED (green) (11) illuminates and the AC switch (22) is in the ON (I) position.
  • Page 18 OPERATION (cont.) KNOW YOUR PRODUCT USB Outlet The USB port (16) 5V DC outlets that come with 1 Amp & 2.1 Amp rating (fig. 14). It is suitable for charging mobile phones, MP3 players etc. 5V DC 1.0A 2.1A Fig. 14 12V Battery charging outlet The DC socket (14) is suitable most lead acid type car batteries.
  • Page 19 OPERATION (cont.) Inverter parallel operation It is possible to connect two Full Boar SD4000irs generators to each other, using a parallel cable kit (sold separately), to increase available power output. DANGER! Never connect the paralleling cord to the inverters with the inverters running.

  • Page 20: Maintenance

    MAINTENANCE The purpose of the maintenance and adjustment schedule is to keep the generator in the best operating condition. Inspect or service as scheduled in the table below. WARNING! Shut off the engine before performing any maintenance. If the engine must be run, make sure the area is well ventilated.
  • Page 21 MAINTENANCE (cont.) Checking the engine oil See “Checking the oil” section on page 12 of this manual for full details. Changing the engine oil It is recommended that SAE 10W-30 (multi-viscosity) 4-stroke engine oils are used at temperatures from 5 to 35°C and synthetic oils 5W-30 (multi viscosity) is used for temperatures -5 to 5°C.
  • Page 22 MAINTENANCE (cont.) KNOW YOUR PRODUCT Spark plug servicing Use only compatible spark plugs. To ensure proper engine operation, the spark plug must be properly gapped and free of deposits. 1. Remove the routine maintenance cover (6) to gain access to the spark plug. 2.

  • Page 23: Transporting & Storage

    TRANSPORTING & STORAGE When transporting generator: • When transporting a short distance, it is advised that you use the telescopic handle (24). The handle can be extended out from its position at the front base of the generator. Along with the wheels at the rear base of the unit, the telescopic handle (24) makes transporting easy over short distances.

  • Page 24: Troubleshooting

    TROUBLESHOOTING Engine will not start Enough Fuel? Add fuel Is the engine Turn to the “CHOKE” control switch in the position. “CHOKE” position? Enough lubricating Add good quality oil oil? Turn engine control switch to “CHOKE” position and pull Is there fuel in the the recoil starter a carburettor? few times to ensure...

  • Page 25: Description Of Symbols

    DESCRIPTION OF SYMBOLS Read instruction manual Hot surface Do not parallel connect other cables to receptacles, use special jack, or it may cause an electrical shock. Extremely hot surface. Do not touch a hot mu er or exhaust system. You may get burned. These parts get extremely hot from operation and remain hot a short time after the unit is turned o .
  • Page 26 CARING FOR THE ENVIRONMENT Power tools that are no longer usable should not be disposed of with household waste but in an environmentally friendly way. Please recycle where facilities exist. Check with your local council authority for recycling advice. Recycling packaging reduces the need for landfill and raw materials.

  • Page 27: Contents

    CONTENTS 1 x Inverter generator 1 x Convertible screwdriver 1 x Charging cable and clamp set 1 x Spark plug socket 1 x Spark plug (spare) 1 x Engine oil bottle 1 x Funnel Note. The inverter generator warranty does not cover components that have been subjected to operator abuse or negligence.

  • Page 28: Warranty

    WARRANTY YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE (see www.bunnings.com.au or www.bunnings.co.nz for store locations) WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE: Australia 1800 069 486 New Zealand 0508 069 486...
