ACTiSYS IR8250P Brochure

I r D
I r D
®
A complete IrDA
TM TM
IrLAP , IrLMP
or TinyTP with customized IAS
Also includes IrPHY
for data rate from 9.6kbps up to 115.2 kbps. Only an external Infrared transceiver is
needed to complete an IrDA compliant infrared communication subsystem.
®
Supports IrDA Secondary mode only.
Supports 64 bytes data packet for IrDA

Interfaces to Host device via a full function UART port.

Supports host baud rate from 300k bps to 115.2k bps selecting by programmable settings.
Programmable Device name, IAS
Available in programmed and tested chip (ACT-IR8250P), assembled & tested board
(ACT-IR8250PDB), or assembled & tested evaluation kit (ACT-IR8250PEK).

Low supply voltage, 3.0 V to 3.6 V.

Low current consumption; 2 μA standby, 3 mA active.

Small low profile plastic 28-pin SSOP/TSSOP package.

In-system-programmable FLASH, facilitates firmware changes or updates.
The evaluation kit (ACT-IR8250PEK) includes AC power supply, RS232 level translators,
and PC software for in-system re-programming of firmware and future firmware options
All company and product names are the trademarks of the respective companies
921 Corporate Way, Fremont, CA 94539
Tel: +1-510-490-8024, Fax: +1-510-623-7268
E-mail: irda-info@actisys.com, http://www.actisys.com
®
®
A C o m p l i a n
A C o m p l i a n
A C T
A C T
A C T
Protocol stack in a single chip, including mandatory protocols (IrPHY
) and optional protocols (IrLPT
TM
class name for IrSocket).
TM
encoding/decoding, and interfaces directly to Infrared transceivers
TM
class name and data format setting.
t P r o t o c o l P r o
t P r o t o c o l P r o
- I R 8 2 5 0 P
- I R 8 2 5 0 P
- I R 8 2 5 0 P
TM TM
, IrCOMM
® TM
IrLAP frame.
c e s s o r
c e s s o r
TM
+TinyTP , OBEX transport
TM
,
.
