ACTiSYS IR8200D Brochure
Irda compliant protocol processor
Hide thumbs
Also See for IR8200D:
- Supplementary manual (4 pages) ,
- Reference manual (2 pages) ,
- Design specification (21 pages)
Advertisement
Quick Links
Download this manual
See also:
Reference Manual
I
I
A complete IrDA
No any driver is needed.
Includes IrPHY
Infrared transceivers for data rate up to 115.2 kbps. Only an external
Infrared transceiver is needed to complete an IrDA
infrared communication subsystem.
Supports mandatory IrDA
Supports upper layers TinyTP, IrCOMM
transport.
Supports host baud rate from 1.2 kbps to 115.2 kbps, which is
changed by PC utility or 8 pins on chip. IrDA
kbps to 115.2 kbps, which is flexible, setting by IrDA
Supports both IrDA
IR frame and Host buffer are 2048 bytes separately.
Low supply voltage, 3.0 V to 3.6 V.
Current consumption: 20mA standby, 30mA active.
Small low profile plastic 52-pin QFP package.
Available in programmed and tested chips, assembled & tested
boards, or fully packaged devices.
A ready-made IrDA
available. It is strongly recommended to test ACT-IR100SD before
purchasing ACT-IR8200D chip.
