Summary of Contents for Award GTSN462 S
- Page 1 Fridge -Freezer User Manual GTSN462 S GTSN462 BS...
- Page 2 Thank you for choosing this fridge - freezer. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your fridge - freezer. Please take the time to read this user manual before using your fridge - freezer and keep this book for future reference.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS ................4 1.1 General Safety Warnings ....................4 1.2 Installation warnings .......................8 1.3 During Usage........................9 2 DESCRIPTION OF THE FRIDGE-FREEZER ..........10 3 USING THE FRIDGE-FREEZER ..............11 3.1 Information about New Generation Cooling Technology ..........11 3.2 Display and Control Panel ....................11 3.3 Operating your Fridge Freezer ..................11 3.3.1 Freezer Temperature Settings ...................11 3.3.2 Fridge Temperature Settings ..................12... -
Page 4: Safety Instructions
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the fridge - freezer enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 5 is an environmentally friendly and natural gas, but it is explosive. In the event of a leak due to damage of the fridge - freezer elements, move your fridge - freezer away from open flames or heat sources and ventilate the room where the fridge - freezer is located for a few minutes.
- Page 6 • This fridge - freezer can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the fridge - freezer in a safe way and understand the hazards involved.
- Page 7 To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause a significant increase of the temperature in the compartments of the fridge - freezer. • Clean regularly surfaces that can come in contact with food and accessible drainage systems •...
-
Page 8: Installation Warnings
1.2 Installation warnings • Do not cover the body or top of fridge freezer. This will affect the performance Before using your fridge freezer for the first of your fridge freezer. time, please pay attention to the following • Clearance of at least 150 mm is required points: at the top of your fridge - freezer. -
Page 9: During Usage
- If the bottom cabinet cover is the drinks with high alcohol content vertically metal in the fridge compartment and make sure their tops are tightly closed. The condenser of your fridge - freezer is placed at the bottom of cabinet. •... -
Page 10: Description Of The Fridge-Freezer
2 DESCRIPTION OF THE service or the shop where you purchased the fridge - freezer. FRIDGE-FREEZER Packaging and the Environment Packaging materials protect your machine from damage that may occur during transportation. The packaging materials are environmentally friendly as they are recyclable. -
Page 11: Using The Fridge-Freezer
3 USING THE FRIDGE-FREEZER 3.2 Display and Control Panel 3.1 Information about New Generation Cooling Technology Fridge - freezers with new-generation cooling technology have a different operating system to static fridge - freezers. Other (static) fridge - freezers may experience a build up of ice in the freezer compartment due to Using the Control Panel... -
Page 12: Fridge Temperature Settings
NOTE: Eco mode gets activated the environmental temperature or when the automatically when the temperature freezer sensor reaches a sufficiently low of the freezer compartment is set to temperature. -18°C. Recommended Settings for the Freezer and Fridge Compartment Temperature 3.3.2 Fridge Temperature Settings •... -
Page 13: Accessories
3.5 Accessories the doors frequently or place large quantities of food in the fridge - freezer. Please note that, depending on the 3.5.1 Ice Tray ambient temperature, it may take 24 • Fill the ice tray with water and place in hours for your fridge - freezer to reach the freezer compartment. -
Page 14: The Chiller Shelf
3.5.3 The Chiller Shelf 3.5.4 The Fresh Dial Fresh dial Chiller shelf Keeping food in the Chiller compartment, If the crisper is full, the fresh dial located instead of the freezer or fridge in front of the crisper should be opened. compartments, allows food to retain This allows the air in the crisper and the freshness and flavour for longer, while... -
Page 15: Maxi-Fresh Preserver
4 FOOD STORAGE 3.5.5 Maxi-fresh preserver Maxi Fresh Preserver technology helps to remove ethylene gas (a 4.1 Fridge Compartment bioproduct released naturally from fresh foods) and • To reduce humidity and avoid the consequent formation of frost, always unpleasant odors from the crisper. -
Page 16: Freezer Compartment
• Do not put food in front of the air flow • Never place warm food in the freezer passage. compartment as it will thaw the frozen food. • Consume packaged foods before the recommended expiry date. • Always follow the manufacturer's instructions on food packaging when NOTE: Potatoes, onions and garlic storing frozen food. - Page 17 is normal. Once equilibrium has been reached, the door will open easily. Important note: • Never refreeze thawed frozen food. • The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar, assorted spices, ginger, garlic, onion, mustard, thyme, marjoram, black pepper, etc.) changes and they assume a strong taste when they are stored for a long period of time.
- Page 18 compartment. Maximum storage time Meat and fish Preparation (months) Steak Wrap in foil 6 - 8 Lamb meat Wrap in foil 6 - 8 Veal roast Wrap in foil 6 - 8 Veal cubes In small pieces 6 - 8 Lamb cubes In pieces 4 - 8...
-
Page 19: Cleaning And Maintenance
Maximum storage time Vegetables and Fruits Preparation (months) Strawberry and Wash and hull 8 - 12 Blackberry Maximum storage time Vegetables and Fruits Preparation (months) Cooked fruits Add 10 % of sugar to the container Plum, cherry, sourberry Wash and hull the stems 8 - 12 Maximum storage time Thawing time at room... -
Page 20: Shipment And Repositioning
6 SHIPMENT AND Replacing LED Lighting REPOSITIONING Location #1 Location #2 LED strip light LED strip light 6.1 Transportation and Changing Positioning • The original packaging and foam may be kept for re-transportation (optional). • Fasten your fridge - freezer with thick packaging, bands or strong cords and follow the instructions for transportation on the packaging. -
Page 21: Before Calling After-Sales Service
7 BEFORE CALLING AFTER-SALES SERVICE Errors Your fridge - freezer will warn you if the temperatures for the fridge and freezer are at improper levels or if a problem occurs with the fridge - freezer. Warning codes are displayed in the freezer and fridge indicators. ERROR TYPE MEANING WHAT TO DO... - Page 22 ERROR TYPE MEANING WHAT TO DO 1. Set the fridge temperature to a colder value or set Super Cool. This should remove the error code once the required temperature has been reached. Keep doors closed to improve time taken to reach the correct Likely to occur after: temperature.
-
Page 23: Tips For Saving Energy
• The fridge doors are opened frequently. not comply with these instructions, we Humidity of the room will enter the emphasise that the manufacturer and fridge each time the doors are opened. the dealer will not be responsible for any Humidity increases faster if the doors repair or failure within the guarantee are opened frequently, especially if the... - Page 24 Appliance Group Award Appliances (NZ) Limited e-mail: sales@award.co.nz www.awardappliances.co.nz 52327392...
