Ceiling Mount Kit
Quick Installation Guide
Package Contents
M3 x 6mm Screws (x3)
Ceiling Mount Brackets (x2)
1/4"-20, L=7.5mm Screws (x3)
Ceiling Mount Kit QIG
Dimensions
104mm (4.09")
199.50mm (7.85")
112mm (4.41")
31.50mm (1.24")
80mm (3.15")
153mm (6.02")
© 2021 AVer Information Inc. All Rights Reserved.
P/N: 300AS500-EHF
Advertisement
Table of Contents
Related Manuals for AVer 300AS500-EHF
Summary of Contents for AVer 300AS500-EHF
- Page 1 M3 x 6mm Screws (x3) Ceiling Mount Brackets (x2) 1/4”-20, L=7.5mm Screws (x3) Ceiling Mount Kit QIG Dimensions 104mm (4.09”) 199.50mm (7.85”) 112mm (4.41”) 31.50mm (1.24”) 80mm (3.15”) 153mm (6.02”) © 2021 AVer Information Inc. All Rights Reserved. P/N: 300AS500-EHF...
- Page 2 Ceiling Mount Installations 1. Use two M2 x 4mm screws (in the DL camera package) to secure the cable fixing plate (in the DL camera package) to the camera. Plug in cables. Use four cable ties (in the DL camera package) to secure the cables and cable fixing plate. 2.
