AVer COMSVCMNT Installation Manual

CAMERA WALL MOUNT INSTALLATION GUIDE
1. Paste the drilling paper on the wall and
drill the holes for installing mount plate.
2
1
3. Asssemble the two mount plates and make sure
the two mount plates are jammed. Next, secure
two mount plates with screws.
5. For SVC series camera, paste the sponge to
the specified position as figure shown.
[Note] PTC seriec camera skip this step to step 6.
2. Secure the mount plate with screws on the wall. The mount
plate has two ways of installation as figure shown.
[Note] The screws are not inculded.
2
1
4. Install the nuts on the screws.
6. Secure the screw to the bottom of camera.
DO NOT serew tight, leave some spece
for sliding to mount bracket
