SMD REWORK STATION User Manual
Welcome to use 858D rework station. This manual will show the parameters, performance, usage
and precautions of this machine.
If you have any problem of usage or any suggestion about this soldering station, please send the
email to
support@newacalox.com,

Warranty

1: if hot air gun was broken within a year, we will send a replacement to you after connecting with
After-sales service mailbox.
2:If the gadgets in the package are lost during the shipping, please contact us for re-send.
3:We will guide you carefully about the use and maintenance of this product.
858D rework station is good for repair phone and PCB circuit board. Please read this operating
instruction manual carefully before using the serial soldering station of our company.
If you like our product, can you share your experience or review for it on Amazon. It can help us a
lot,thanks in advance.

Specification

Model
NEW858D
Type
LED indicator light
Power
700W
Consumption
Blower Fan
Brush-less Fan
Amount Of Wind
120L/m(MAX)
Temperature Range
100℃-500℃
Discharge Feature
LED indicator light
Handle Length
120cm
(With Cable)
12.4(h)*18.7(w)*
Size
24.9(l)(cm)
Weight
2.20kg
Noises
<45db

Usage

Hot-air rework stations can be very handy. As mentioned above, they are a crucial tool when it comes to
reworking a board. The term rework just means you are refinishing or repairing an already reflowed board,
and it is a term commonly used in the electronics world. Just think of it as doing any work to the board
that wasn't involved in the actual production process. Here are some common rework scenarios:
Polarized Components - Parts that have been placed incorrectly (backwards, shifted x degrees off). These
include ICs, diodes, some capacitors, connectors, etc.
Tombstone Parts - This is when a part (usually a resistor or capacitor) reflows only on one side. The part
usually sticks strait up resembling a tombstone.
Cold Joints - This is similar to a tombstone except the parts might not be sticking strait up, making it
harder to see the connection that is not being made.
Removing Defective Parts - Sometimes, during the IC manufacturing process, errors can arise and go
unnoticed. These ICs are then placed on perfectly good PCBs. Hot-air is great for replacing these bad parts.
Missing Components - The smaller the component, the easier it is for it to disappear. This can happen
before or during reflow, resulting in a spot where something should be, but isn't. Hot-airing a new part in
858D
thank you.
13.8(h)*10(w)*15(l)(cm)
1.52kg
1.55kg

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEW858D and is the answer not in the manual?

Questions and answers

Summary of Contents for Newacalox NEW858D

  • Page 1 If you like our product, can you share your experience or review for it on Amazon. It can help us a lot,thanks in advance. Specification Model NEW858D Type LED indicator light Power 700W...
  • Page 2 its place is a snap with this rework station. Unintentional Solder Jumpers - If too much solder or solder paste is used, the result can be jumpers on one or more of your surface mount IC's legs. Hot-air can sometimes be used in conjunction with a flux pen to remove these pesky buggers.
  • Page 3 lot of smoke at this time but not catching fire) Troubleshooting Low Airflow when “Air” Dial is Turned Up If you are getting low airflow when the “Air” Dial is turned up, make sure that you have the nozzle securely attached. With the nozzle, you will get more air flowing through the hot-air rework station’s handle.
  • Page 4 4. Be aware that heat may be transferred to distant flammable materials; Someone must be present at all times while the device is connected. This device is not intended to by operated by Individuals with diminished physical, sensory, or mental capacities or by those who lack experience (such as children), except in the presence of individuals qualified to provide necessary supervision and guidance Attached: Technical section-rework process (for reference only)
  • Page 5 X. Replacement Instruction Replacement of Hot Air rework heating element(Figure 7) 1. Ensure that the air gun temp fully cools down before replacing the air gun heater. 2. As Figure, loosen the two screws on the handle. 3. Screw out the handle assembly and then remove the handle's cover. 4.
