Related Manuals for Techly ICA-LCD 482-T
Summary of Contents for Techly ICA-LCD 482-T
- Page 1 MULTIPLE DESKTOP MONITOR ARM WITH CLAMP Istruzioni installazione Installation Instruction ICA-LCD 482-T...
- Page 2 MULTIPLE DESKTOP MONITOR ARM WITH CLAMP Gentile Cliente, Dear Customer, grazie per aver scelto un prodotto Techly. thanks for choosing a Techly product. Enjoy the using. Istruzioni disimballaggio Unpacking Instructions • Aprire il cartone con cura, rimuovere il contenuto e • Carefully open the carton, remove contents and lay...
- Page 3 MULTIPLE DESKTOP MONITOR ARM WITH CLAMP LISTA DELLE PARTI FORNITE | SUPPLIED PaRTS LIST (1) Morsetto-b (1) Tubo di supporto da 48mm-a (1) Placca VESA con braccio assemblato-c (1) Disconnected (1) 48mm Tube Support-a (1) VESA Plate with Arm Assembled-c “C” Clamp-b (12) M4x12 vite–d (12) M4x30 vite–e (24) M4 rondella-f (12) M4 distanziatori-g (12) M4x12 Bolt-d (12) M4x30 Bolt-e (24) M4 Washer-f (12) M4 Space-g (2) M8x10 vite-h (2) M10x15 vite–i (1) Chiave a brugola-j (2) Elemento di copertura-k (2) M8x10 Bolt-h (2) M10x15 Bolt-i (1) Allen Key-j (2) Spare Plastic Cover-k CaUTIon: This monitor desktop mount must be securely attached to the horizontal desk. If the mount is not properly installed it may fall, resulting in possible injury and/or damage. TOOLS REQUIRED: Phillips Screwdriver...
- Page 4 Stringere la viti utilizzando il cacciavite. Install arm to the tube support, please make sure the wire clip in the downside. Fasten the bolt by screw driver. STEP 3 Montaggio del monitor alla placca VESA | Mount the Monitor to VESa Plate Per monitor con retro piatto Per monitor con retro curvo For Flat Back Monitor For Curved Back Monitor Regolazioni e gestione dei cavi STEP 4 Do necessary adjusting & Manage the Wires www.techly.it...
