Operation and Service Instructions
MicroBlaster® MB1006
This manual covers all variations of the MB1006 series
manufactured after September 2003(MB1006-1, MB1006-2, ETC)
Burbank, California 91504
Dual Tank
(High Pressure)
Issue Date: September 2003
Comco Inc.
2151 N. Lincoln Street
USA
Phone: 818-841-5500
FAX: 818-955-8365
www.comcoinc.com
Book P/N MB1316
File: MB1006.doc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MicroBlaster MB1006 and is the answer not in the manual?

Questions and answers

Related Manuals for Comco MicroBlaster MB1006

Summary of Contents for Comco MicroBlaster MB1006

  • Page 1 Dual Tank MicroBlaster® MB1006 (High Pressure) Issue Date: September 2003 This manual covers all variations of the MB1006 series manufactured after September 2003(MB1006-1, MB1006-2, ETC) Comco Inc. 2151 N. Lincoln Street Burbank, California 91504 Phone: 818-841-5500 FAX: 818-955-8365 www.comcoinc.com Book P/N MB1316...
  • Page 2 Congratulations! The Comco MicroBlaster® you have purchased is equipped with the latest features to make it simple to operate and easy to maintain. The addition of the auto-vent component means it is no longer necessary to manually vent air from the unit after turning the power off.

  • Page 3: Table Of Contents

    Table of Contents The Comco Warranty ....................v Safety Precautions .....................vi Section 1: The MicroBlaster MB1006 ............1-1 This section introduces you to the basic unit, including its description, principles of operation, and detail specifications. Overview ......................1-2 Figure 1-1, MicroBlaster MB1006 ............1-2 How The MicroBlaster Works ................1-3...
  • Page 4 This section details optional equipment available on the MicroBlaster, and the use and servicing of these options. Appendices This section presents parts lists, drawings and schematics for the MicroBlaster MB1006 and Workstations. Appendix A: Parts Lists .....................A-1 Major Assemblies and Principal Parts ............A-2 Standard Accessory Parts ................A-6 Optional Parts ....................A-7...

  • Page 5: The Comco Warranty

    The warranty period begins when the equipment ships from the Comco facility and applies to the original owner only. Comco is not liable for damages from any cause or use of such equipment beyond the cost of repairing any defective parts.

  • Page 6: Safety Precautions

    General issues involved in operating machinery. Working with a Device that is Pressurized The MicroBlaster uses pressurized air to perform its basic function. To minimize the risk of an accident related to air pressure, Comco also recommends the following: √...
  • Page 7 The MicroBlaster uses several types of abrasive media that should not be inhaled or ingested in large quantities or maintained in prolonged contact with the skin. When working with the abrasive media, Comco recommends the following: √ Do not direct the abrasive blast on bare skin or face/eyes.
  • Page 8 Also, always fill the tank through the flapper valve to greatly reduce the amount of wear on the threads. Material safety data sheets (MSDS’s) for all abrasives distributed by Comco are available from the Comco factory. Every powder shipment includes an MSDS.
  • Page 9 Avoiding Hazards Associated with Operating Machinery The following warning labels/pictograms are utilized in the MicroBlaster CE (European) versions: Symbol Meaning ELECTRICAL HAZARD HAND PROTECTION RECOMMENDED WHERE APPROPRIATE EYE PROTECTION RECOMMENDED WHERE APPROPRIATE RESPIRATORY PROTECTION RECOMMENDED WHERE APPROPRIATE Comco Inc. Issue Date: September 2003...

  • Page 11: Section 1: The Microblaster Mb1006

    MicroBlaster MB1006 Section 1: The MicroBlaster MB1006 Section 1: The MicroBlaster MB1006 In This Section This section gives you an overview of your MicroBlaster including:  A general description of the MicroBlaster.  How the MicroBlaster Works.  Detail specifications.

  • Page 12: Overview

    MicroBlaster MB1006 Overview The Comco MicroBlaster® model MB1006 is a compact bench-top machine that delivers a precisely controlled stream of micro-abrasive particles at high velocity. With the appropriate abrasive powder and the necessary adjustments, it will clean, deburr, cut or drill any material, particularly hard or brittle ones.

  • Page 13: How The Microblaster Works

    MicroBlaster MB1006 Section 1: The MicroBlaster MB1006 How the MicroBlaster Works As shown in Figure 1-2, below, when the MicroBlaster Power Switch on the front panel is initially turned “ON”, supply air enters through the energized air valve at the back of the unit.
  • Page 14 Section 1: The MicroBlaster MB1006 MicroBlaster MB1006 How the MicroBlaster MB1006 Works (cont’d) Stepping on the footswitch used to operate the MicroBlaster causes two things to happen: The hose pinch (shut-off) assembly for the selected tank opens, which allows air to flow from the nozzle. Refer to Figure 1-3, item 1.
  • Page 15 MicroBlaster MB1006 Section 1: The MicroBlaster MB1006 (cont’d) How the MicroBlaster MB1006 Works In the second half of the operating cycle, the modulator coil becomes energized. This pulls the modulator core against the seat (see Figure 1-4, below), shutting off the airflow from the regulator.

  • Page 16: Detail Specifications

    Section 1: The MicroBlaster MB1006 MicroBlaster MB1006 Detail Specifications Abrasive (see Section 3) Type Selected powder, smooth to sharp, soft to hard Size 20 to 300 Microns Nozzles (see Section 3) Material Highest quality Tungsten Carbide Sizes, Round 0.015 to 0.060 in. Dia. (.381 to 1.524 mm) Sizes, Rect.

  • Page 17: Section 2: Getting Started

    MicroBlaster MB1006 Section 2: Getting Started Section 2: Getting Started In This Section This section tells you what you need to do to prepare for using your MicroBlaster, including:  The work area required to properly use the MicroBlaster. ...
  • Page 18 The propellant required for the abrasive is compressed air or neutral gas that meets the Detail Specifications outlined in Section 1. Comco has a complete line of air dryers for shop (compressed) air supplies that will meet or exceed those specifications.
  • Page 19 MicroBlaster MB1006 Section 2: Getting Started Figure 2-1: Micro-abrasive Blasting System Requirements Dust Collector Abrasive Media Workstation Air Dryer MicroBlaster MB1006 Electric Power A source of 115 or 230 VAC, 50/60 Hz, capable of providing 100 watts is required for the MB1006.
  • Page 20 You may use this tip sheet to quickly get your MicroBlaster set up and ready to operate, and as a ready reference for common questions regarding the operation of the MicroBlaster. Keep it nearby and refer to it often. For complete details on the MicroBlaster, Comco strongly urges you to read the manual completely.
  • Page 21 The following pages describe what is needed, and how to set up and test your micro-abrasive blasting system for proper operation. Once you receive your MicroBlaster MB1006, check the contents of the shipping carton to make sure that you have received all of the items. Besides this manual and the Reference Sheet pictured on the previous page, the standard Accessory Parts Kit is enclosed.
  • Page 22 Section 2: Getting Started MicroBlaster MB1006 Basic Components of the MicroBlaster MB1006 Power Switch The Power Switch is located on the left-hand side of the unit. It is the primary ON/OFF switch for the unit. The Power Indicator will illuminate when the power is “ON”.
  • Page 23 MicroBlaster MB1006 Section 2: Getting Started Figure 2-3: External Component Locations Abrasive Tanks Powder Flow Air Pressure Control Control Power Switch Powder Flow Control Pressure Gauge Handpieces & Nozzles FRONT VIEW "Quick Fill" Flapper Valve Tank Cover Pinch Vent Hose...

  • Page 24: Setup And Test

    Section 2: Getting Started MicroBlaster MB1006 Set-Up and Test 1. Place the MicroBlaster in the area it will normally occupy, within reach of the electrical outlet and the air source. Generally, this will be on top of or alongside the workstation.
  • Page 25 MicroBlaster MB1006 Section 2: Getting Started Set-Up and Test (cont’d) 7. Place the ends of the hoses connected to each “Tank Vent” on the rear of the machine into the grommeted openings on the back of the workstation. With the 4"...
  • Page 26 Section 2: Getting Started MicroBlaster MB1006 THIS PAGE INTENTIONALLY BLANK Comco Inc. 2-10 Issue Date: September 2003...

  • Page 27: Section 3: Using The Microblaster

    MicroBlaster MB1006 Section 3: Using the MicroBlaster Section 3: Using the MicroBlaster In This Section This section tells you how to efficiently operate your MicroBlaster, including:  Abrasive selection.  Orifice and Nozzle selection.  General operation of the MicroBlaster.
  • Page 28 Section 3: Using the MicroBlaster MicroBlaster MB1006 The Essence of Micro-Abrasive Blasting There are many variables that affect the results you will get from the micro-abrasive blasting process. In order to get the most from your MicroBlaster, a thorough understanding of these factors is essential.
  • Page 29 MicroBlaster MB1006 Section 3: Using the MicroBlaster Table 3-1: General Summary of Factors Affecting Abrasive Blasting Variable Comments Manual Reference The Abrasive The abrasive you use has the most significant See the information impact on how well the unit works. Hardness,...

  • Page 30: Abrasive Selection

    Section 3: Using the MicroBlaster MicroBlaster MB1006 Abrasive Selection An abrasive material has three characteristics that affect its cutting action: hardness, sharpness (shape), and particle size. The most common abrasive materials are listed below. Material Hardness Shape Sodium Bicarbonate Soft...
  • Page 31 MicroBlaster MB1006 Section 3: Using the MicroBlaster Table 3-2: Common Abrasives and Their Applications Particle Size Average Abrasive Description/Characteristics Comco Range Particle Size Material Type (Microns) Micron Inch Aluminum 0.0004 5 - 25 The most common abrasive used. A very...
  • Page 32 Refer to the table above to determine the size. The tank orifice should be installed finger tight only with a 1/4” nut driver (see Figure 3-1). For improved performance and longer life, all Comco orifices are carbide lined. Rev. 5/14 Comco Inc.
  • Page 33 MicroBlaster MB1006 Section 3: Using the MicroBlaster Table 3-3: Orifice Selection Chart Abrasive Particle Size Average Particle Range Recommended Micron Inch (Microns) Tank Orifice 0.0004 5 - 30 0.025 0.0008 10 - 40 0.025 0.001 15 - 45 0.025 0.002 30 - 80 0.025...
  • Page 34 With larger nozzle openings, more abrasive can flow, and thus cutting speed is increased and efficiency will improve. Comco offers many different sizes and configurations (see Figure 3-2 and Table 3-4), from a 0.015" diameter round nozzle, to 0.012" x 0.150" rectangular. For most applications a round nozzle would be preferred due to the precise spray pattern.
  • Page 35 MicroBlaster MB1006 Section 3: Using the MicroBlaster Table 3 - 4: Nozzle Chart HIGH PERFORMANCE NOZZLES (ROUND) - MB1520 Part Holder Size Size Tank Orifice Abrasive Comments Color I.D. I.D. mm O.D. (Microns) Violet .018 .046 .018 - .025 20 - 50...
  • Page 36 Section 3: Using the MicroBlaster MicroBlaster MB1006 Nozzle Distance The velocity at which the abrasive particles are expelled from the nozzle produces a well-defined stream that only flares about 7 - 10 degrees. Therefore, the distance the nozzle is held from the work surface will determine the size of the blast pattern as well as the material removal rate (or cutting action).
  • Page 37 A significant increase in abrasive flow does not always increase the speed at which parts can be processed. The micro-abrasive blasting process is optimized to work with less abrasive, using air flow and particle velocity to improve efficiency. Please contact Comco's Technical Support team for assistance in fine-tuning your abrasive blasting process. Rev. 9/12 Comco Inc.

  • Page 38: General Operation Of The Microblaster

    Section 3: Using the MicroBlaster MicroBlaster MB1006 General Operation of the MicroBlaster This section gives step-by-step procedures on how to use the MicroBlaster. Before proceeding, make sure you have: √ Reviewed the safety precautions in the introductory selection of this manual.
  • Page 39 MicroBlaster MB1006 Section 3: Using the MicroBlaster Before You Begin 1. Check the tightness of the tank covers. The O-ring seals must be firmly seated against the tanks. 2. Check to see that the ends of the tank vent hoses are inserted into the back of the workstation or dust collector hose.
  • Page 40 Section 3: Using the MicroBlaster MicroBlaster MB1006 Figure 3-4: Controls and Indicators Abrasive Tanks Powder Flow Air Pressure Control Control Power Switch Powder Flow Control Pressure Gauge Handpieces & Nozzles FRONT VIEW "Quick Fill" Flapper Valve Tank Cover Pinch Vent Hose...
  • Page 41 MicroBlaster MB1006 Section 3: Using the MicroBlaster Power Up 1. Switch "Power" to the "ON" position. The Power indicator should light. 2. Check to see that no air is escaping from either of the tank covers. If a leak is discovered, follow the “Stopping-Refilling the Tank”...
  • Page 42 Section 3: Using the MicroBlaster MicroBlaster MB1006 Blasting (cont’d) 8. During use, maintain a generous loop in the abrasive hose between the abrasive pinch valve tube and the hose connection on the rear panel. A tight (small) loop may cause rapid wear to the hose and result in premature failure.
  • Page 43 MicroBlaster MB1006 Section 3: Using the MicroBlaster (cont’d) Changing the Abrasive 3. Empty the remaining abrasive into a suitable waste container by tipping the machine on its side. Alternately, slip the dust collector hose off the workstation and use it to vacuum the inside of the tank and cover.
  • Page 44 Section 3: Using the MicroBlaster MicroBlaster MB1006 THIS PAGE LEFT INTENTIONALLY BLANK Comco Inc. 3-18 Issue Date: September 2003...

  • Page 45: Section 4: Maintenance

    MicroBlaster MB1006 Section 4: Maintenance Section 4: Maintenance In This Section This section tells you how to maintain your MicroBlaster in peak operating condition, including:  Maintenance intervals.  Extending the life of wear items.  Replacing worn out components.

  • Page 46: Normal Maintenance

    The maintenance intervals given in this section are intended for use as guidelines only. The machine’s frequency of use will determine how often these maintenance items will need to be performed. Contact Comco if you have questions. Note the following cautions before beginning any maintenance or repair task: ...
  • Page 47 Comco recommends that these parts be replaced annually, or every 2000 hours of operation, whichever comes first. Establishing and following a regularly scheduled maintenance program for your equipment, can reduce costly downtime.

  • Page 48: Parts Subject To Normal Wear

    Section 4: Maintenance MicroBlaster MB1006 Parts Subject to Normal Wear All the parts through which the abrasive flows are subject to wear. These include the nozzles, hoses, hose connectors, and tank orifices. As a general rule, the smaller the opening the abrasives flow through, the greater the possibility of wear. Parts also subject to wear are the tank cover (threads) and modulator.
  • Page 49 MicroBlaster MB1006 Section 4: Maintenance Parts Subject to Normal Wear (cont’d) Modulator The modulator for each tank is an electro-mechanical device that is activated each time the footswitch is depressed. The stop/start action of the modulator contributes to a consistent flow of abrasive powder from the tank into the mixing chamber and out the nozzle.
  • Page 50 At weekly intervals (or as necessary), spray or wipe a dry lubricant such as graphite, molycote, or Teflon powder on the tank threads (order Comco P/N ST8062). If an aerosol dispenser is used, or the lubricant is suspended in a solvent, allow a few minutes for the solvent to dry before installing the cover.

  • Page 51: Leaks

    MicroBlaster MB1006 Section 4: Maintenance Cabinet and Cables At six-month intervals, unplug the power cord and inspect it for cracks or cuts. Also check the footswitch cable. Remove the cabinet cover and inspect the inside of the MicroBlaster for obvious leaks. Clean thoroughly with a small brush and vacuum hose (never use air or try to blow off abrasive).

  • Page 52: Moisture

    Comco maintains an extensive library of technical bulletins that address issues including the effects of moisture on the micro-abrasive blasting process and methods for reducing moisture contamination.

  • Page 53: Section 5: Trouble-Shooting And Repair

     How to correct most problems that may develop with the MicroBlaster.  How to contact Comco’s Customer Service Department.  How to order replacement parts for the MicroBlaster. Comco Inc.

  • Page 54: Trouble-Shooting

    NOTE: Improper repairs may void your warranty. If you have any questions, consult with Comco before you do any work on the inside of the MicroBlaster MB1006. Most problems that can occur with your MicroBlaster will fall into either one of two categories: No air flow - Nothing happens when you depress the footswitch.

  • Page 55: How To Order Replacement Parts

    Providing this information will expedite your request and will also ensure that you receive the proper component for your unit. Comco offers a Repair Kit for its customers who prefer to do their own maintenance. This kit contains the parts and instructions needed to keep your MicroBlaster in top condition.

  • Page 56: Common Problems, Causes, And Solutions

    Section 5: Trouble-Shooting and Repair MicroBlaster MB1006 Common Problems, Causes, and Solutions Table 5-1: No Air Flow Problem Items to Check Solution √ Is the electrical power Nothing happens Verify that the POWER switch is ON when the and the POWER LIGHT is footswitch is illuminated.
  • Page 57 MicroBlaster MB1006 Section 5: Trouble-Shooting and Repair Common Problems, Causes, and Solutions (cont’d) Table 5-2: No Abrasive Flow Problem Items to Check Solution √ Cutting ceases Is any abrasive Verify the quality of abrasive flow by holding a but air is...
  • Page 58 Section 5: Trouble-Shooting and Repair MicroBlaster MB1006 The Handpiece Nose The handpiece nose is the main part of the handpiece that holds the nozzle. The nose holds together the abrasive hose, handpiece tube and the nozzle. Abrasive will wear away the inside of the nose to a point where it can no longer support the hose. Also, if the nozzle is not tightened firmly into the nose, abrasive leakage will wear away the threads and the nozzle will not fit properly.
  • Page 59 MicroBlaster MB1006 Section 5: Trouble-Shooting and Repair (cont’d) Abrasive Hose Replacement Procedure Feed a 6 ft. length of new hose MB1233 (or the old cut back hose) through the pinch tube. Slip the rubber grommet (ST5010) and the Quicknut onto the hose.

  • Page 60: Inspecting And Repairing The Pinch Valve

    (see replacement procedure, “Abrasive Hose”, above). Remove the pinch tube. Inspect it for sharp edges or pitting due to abrasive leakage. Replace if necessary with Comco part number MB1282. Inspect the pinch plunger for sharp edges or pitting due to abrasive leakage.
  • Page 61 MicroBlaster MB1006 Section 5: Trouble-Shooting and Repair (cont’d) Inspecting and Repairing the Pinch Valve Unscrew the pinch tube completely (Item 3). Inspect the pinch tube and pinch plunger as described above. Inspect the piston rod by pulling it out about 2". It should be clean, dry (not oily), and not “gritty”.

  • Page 62: Inspecting And Repairing The Modulator

    Section 5: Trouble-Shooting and Repair MicroBlaster MB1006 Pinch Delay Adjustment The abrasive pinch assembly is equipped with a delay valve (flow control) to prevent it from opening for 10 - 15 seconds after internal pressure is released. This allows the tank pressure to escape through the vent hose, rather than the nozzle.
  • Page 63 MicroBlaster MB1006 Section 5: Trouble-Shooting and Repair Figure 5-1: Modulator Assembly and Modulator Housing Assembly MODULATOR ASSEMBLY --------------------------------------------------------------------------------------------------------------------- MODULATOR HOUSING ASSEMBLY Comco Inc. 5-11 Issue Date: September 2003...
  • Page 64 Section 5: Trouble-Shooting and Repair MicroBlaster MB1006 (cont’d) Inspecting and Repairing the Modulator Using a 5/8" open-end wrench, remove the modulator housing from the tank. Note: If it is difficult to reach the housing, it may be necessary to remove the tank to allow better access to the modulator housing.

  • Page 65: Clogging

    MicroBlaster MB1006 Section 5: Trouble-Shooting and Repair Clogging Moisture or particulate matter contamination in the abrasive powder can cause clogging problems in your MicroBlaster. The most likely place for clogging to occur is in the tank orifice. Provided the orifice is sized properly for the type of abrasive being used (see Section 3, “Orifice Selection”), the powder should always flow freely from the tank.

  • Page 66: Air Pressure Regulator

    Replace the Regulator Assembly according to the following procedure: Air Pressure Regulator Assembly Replacement Procedure (Refer to Appendix B, Figure 10, or contact Comco for part number.) 1. Turn Power OFF. 2. Remove the MicroBlaster cover (4 screws). 3. Using a 7/16" open-end wrench, remove the hose connector nuts and hoses from the regulator assembly.

  • Page 67: Tank Cover

    Tank Cover Flapper Valve The flapper valve allows for quick filling of the abrasive tank. If the valve becomes worn or damaged, replace it with Comco part number MB1145. Tank Cover Flapper Valve Replacement Procedure (MB1145) Turn Power OFF.
  • Page 68 Section 5: Trouble-Shooting and Repair MicroBlaster MB1006 Tank Cover O-ring Replacement Procedure Using long needle nose pliers, remove the 4-inch diameter O-ring from the inner cover plate. Lift the flapper valve and remove the O-ring underneath. Press the new O-rings in place, as shown in Figure 2. Press directly down on O-rings to seat them in the dovetail grooves.

  • Page 69: Section 6: Optional Equipment

    MicroBlaster MB1006 Section 6: Optional Equipment Section 6: Optional Equipment In This Section  Optional equipment available on your MicroBlaster  Operation and service of these options Comco Inc. Issue Date: September 2003...
  • Page 70 Section 6: Optional Equipment MicroBlaster MB1006 THIS PAGE LEFT INTENTIONALLY BLANK Comco Inc. Issue Date: September 2003...

  • Page 71: Appendix A: Parts Lists

    MicroBlaster MB1006 Appendix A: Assemblies, Components, and Parts Appendix A Parts Lists for the MicroBlaster MB1006 Comco Inc. Issue Date: September 2003...

  • Page 72: Major Assemblies And Principal Parts

    Appendix A: Assemblies, Components, and Parts MicroBlaster MB1006 MAJOR ASSEMBLIES AND PRINCIPAL PARTS PART NUMBER DESCRIPTION QTY. Orifice, Tank, 0.040” MB1409-40 MB1568 Cover, Tank, Assy.  MB1145 Flapper Assy  ST5022 O-ring, Cover Seal  ST5624 O-ring, Flapper Seal MB1083-3 Handpiece, Nozzle, Assy.
  • Page 73 MicroBlaster MB1006 Appendix A: Assemblies, Components, and Parts (cont’d) MAJOR ASSEMBLIES AND PRINCIPAL PARTS PART NUMBER DESCRIPTION QTY. MB1290-7 Modulator, Air, Assy, 115VAC  MB1301-2 Housing, Modulator, Assy ► MB1294 Core, Modulator ► MB1307 Nose, Modulator, Assy ► MB1482 Body, Modulator ►...
  • Page 74 Appendix A: Assemblies, Components, and Parts MicroBlaster MB1006 (cont’d) MAJOR ASSEMBLIES AND PRINCIPAL PARTS PART NUMBER DESCRIPTION QTY. MB1396 Knob, Assy. MB1397-1 Powder Adjustment Assy. (right) MB1397-2 Powder Adjustment Assy. (left) MB1404-17 * Tank Assy Powder, Acme Thd, Right ...
  • Page 75 MicroBlaster MB1006 Appendix A: Assemblies, Components, and Parts (cont’d) MAJOR ASSEMBLIES AND PRINCIPAL PARTS PART NUMBER DESCRIPTION QTY. MB1520-30 Hi/Performance Nozzle, .030, Green  ST5020 O-ring, Nozzle MB1520-46 Hi/Performance Nozzle, .046, Yellow  ST5020 O-ring, Nozzle ST5465-4 Pin, Spring, 0.062" x 0.250"...

  • Page 76: Standard Accessory Parts

    Appendix A: Assemblies, Components, and Parts MicroBlaster MB1006 STANDARD ACCESSORY PARTS, MB1089-1 PART NUMBER DESCRIPTION QTY. MB1520-30 Hi/Performance Nozzle, .030, Green MB1520-46 Hi/Performance Nozzle, .046, Yellow MB1409-25 Orifice, Tank, .025 MB1233 Tube, Abrasive, Poly 6 ft ST4005 Bushing, .250T x.125P, Brs...

  • Page 77: Optional Parts

    MicroBlaster MB1006 Appendix A: Assemblies, Components, and Parts OPTIONAL PARTS PART NUMBER DESCRIPTION QTY. MB1456-3 Extender Tank Kit, 5", Acme Thd Opt. MB1456-4 Extender Tank Kit, 10" , Acme Thd Opt. MB1409-18 Orifice, Tank, .018 Opt. MB1409-30 Orifice, Tank, .030 Opt.
  • Page 78 Appendix A: Assemblies, Components, and Parts MicroBlaster MB1006 RECOMMENDED SPARE PARTS (Optional) PART NUMBER DESCRIPTION QTY. MB1409-x* Orifice, Tank MB1500-x* Nozzle MB1301-2 Housing Assy, Modulator MB1560 Filter & Check Valve Assy MB1233 Abrasive Hose 25 ft. MB1230-1 Handpiece Nose MB1455...

  • Page 79: Appendix B: Drawings And Schematics

    MicroBlaster MB1006 Appendix B: Drawings and Schematics Appendix B Drawings and Schematics for the MicroBlaster MB1006 Comco Inc. Issue Date: September 2003...
  • Page 80 Appendix B: Drawings and Schematics MicroBlaster MB1006 List of Figures Figure 1: Front View ..................... B-3 Figure 2: Top View ....................... B-4 Figure 3: Pneumatic Schematic ................... B-5 Figure 4A: Electrical Schematic – MB1006 ..............B-6 Figure 4B: Electrical Schematic – MB1006-CE ............B-7 Figure 5: P/N MB1568 Tank Cover Assembly ..............

  • Page 81: Figure 1: Front View

    MicroBlaster MB1006 Appendix B: Drawings and Schematics FIGURE 1: FRONT VIEW, MODEL MB1006 Item Description Part # Item Description Part # Tank Cover MB1568 Gage, 2.5" MB1407-1 Nozzle Handpiece MB1083-3 Power Switch ST7003 Tank Switch ST7159 Indicator Lamp ST7004 Air Pressure Reg.

  • Page 82: Figure 2: Top View

    Appendix B: Drawings and Schematics MicroBlaster MB1006 FIGURE 2: TOP VIEW, MODEL MB1006 Item Description Part No. Item Description Part No. Tank Orifice Terminal Block ST7007-10 By-pass Tube MB1025-5 Diode, Assy MB1229 Quicknut Conn. MB1455 Tube, Plastic ST4012 Air Valve...

  • Page 83: Figure 3: Pneumatic Schematic

    MicroBlaster MB1006 Appendix B: Drawings and Schematics FIGURE 3: PNEUMATIC SCHEMATIC, MODEL MB1006 Comco Inc. Issue Date: September 2003...
  • Page 84 Appendix B: Drawings and Schematics MicroBlaster MB1006 FIGURE 4A: ELECTRICAL SCHEMATIC, MODEL MB1006 Comco Inc. Issue Date: September 2003...
  • Page 85 MicroBlaster MB1006 Appendix B: Drawings and Schematics FIGURE 4B: ELECTRICAL SCHEMATIC, MODEL MB1006-CE Comco Inc. Issue Date: September 2003...

  • Page 86: Figure 5: P/N Mb1568 Tank Cover Assembly

    Appendix B: Drawings and Schematics MicroBlaster MB1006 FIGURE 5: P/N MB1568 TANK COVER ASSEMBLY Item Description Part No. Flapper, Assy MB1145 O-ring, Cover Seal ST5022 O-ring, Flapper Seal ST5624 Comco Inc. Issue Date: September 2003...

  • Page 87: Figure 6: P/N Mb1404-17 (-18) Abrasive Tank Assembly

    MicroBlaster MB1006 Appendix B: Drawings and Schematics FIGURE 6: P/N MB1404-17 (-18) ABRASIVE TANK ASSEMBLY [1] Item Description Part No. Item Description Part No. Tube, Bypass MB1025-5 Nipple .125 x 2.4 ST4110 Orifice, Tank Cross .12 FNPT ST4131 Ell, Street, 1/8P ST4004 Elbow, St, .125P Brs...

  • Page 88: Figure 7: P/N Mb1290-7 (-8) Modulator Assembly

    Appendix B: Drawings and Schematics MicroBlaster MB1006 FIGURE 7: P/N MB1290-7 (-8) MODULATOR ASSEMBLY WITH COIL [1] Item Description Part No. Item Description Part No. Mod. Housing Assy MB1301-2 Conn, M 1/4T-1/8P[2] ST4006 Modulator Coil [3] MB1310-1 Nut, Hx Stl 9/16-18...

  • Page 89: Figure 8: P/N Mb1083-3 Handpiece Assembly

    MicroBlaster MB1006 Appendix B: Drawings and Schematics FIGURE 8: P/N MB1083-3 HANDPIECE ASSEMBLY Item Description Part No. Item Description Part No. Handpiece Tube MB1012-6 [1] Quicknut Connector (Ref) MB1455 Handpiece Nose MB1230-1 [1] Grommet, Rubber (Ref) ST5010 Abrasive Hose MB1233...

  • Page 90: Figure 9: P/N Mb1298-3 (-4) Abrasive Pinch Assembly

    Appendix B: Drawings and Schematics MicroBlaster MB1006 FIGURE 9: P/N MB1298-3 (-4) ABRASIVE PINCH ASSEMBLY Item Description Part No. Item Description Part No. Plunger, Pinch MB1050-2 Tube, 1/4 x .040 ST4012 8" Bracket, Pinch MB1384-1 Valve, Sol, 115V [2] ST6003-1...
  • Page 91 MicroBlaster MB1006 Appendix B: Drawings and Schematics FIGURE 10: P/N MB1326-3 AIR PRESSURE REGULATOR [1] Item Description Part No. Item Description Part No. Press. Reg. 0-185 psi MB1406 Nipple, 1/8 NPT x 1 1/4 ST4050 Filter & Check Valve MB1560 Press.

  • Page 92: Figure 11: P/N Mb1198-3 (-4) Air Valve Assembly

    Appendix B: Drawings and Schematics MicroBlaster MB1006 FIGURE 11: P/N MB1198-3 (-4) AIR VALVE ASSEMBLY Item Description Part No. Elbow Male, 1/4T x 1/8P ST4010 Conn, Male, 1/4T x 1/8P ST4006 Nipple, Close, .125 ST4049 Valve, Sol, 115V [2] ST6013-1...

  • Page 93: Figure 12: P/N Mb1456-3 (-4) Tank Extender Kit

    MicroBlaster MB1006 Appendix B: Drawings and Schematics FIGURE 12: P/N MB1456-3 (-4) TANK EXTENDER KIT (Optional) Item Description Part No. Tank, Extender 5", Acme Thd [2] MB1090-3 Bypass Tube 10" [1] 5" Tank Extender Kit is shown, 10" Tank Extender Kit is P/N MB1456-4.
  • Page 94 Appendix B: Drawings and Schematics MicroBlaster MB1006 THIS PAGE LEFT INTENTIONALLY BLANK Comco Inc. B-16 Issue Date: September 2003...

  • Page 95: Appendix C: Workstations

    MicroBlaster MB1006 Appendix C: Workstations Appendix C Workstations Comco Inc. Issue Date: September 2003...
  • Page 96 The Comco WS2200 and WS6000 WorkStations are designed to work as part of a micro- abrasive blasting system consisting of the following: 1.
  • Page 97 MicroBlaster MB1006 Appendix C: Workstations Safety Precautions The following safety precautions are essential for safe use of the workstation: 1. The workstation operates using high voltage electrical power. It has been designed to be safe to operate when used properly. Any device that uses electrical power requires that certain safety precautions be observed to avoid potentially hazardous situations.
  • Page 98 Appendix C: Workstations MicroBlaster MB1006 Installation (cont’d) 4. Using a 4" diameter flexible duct and 2 hose clamps (usually provided with the dust collector) connect the workstation to a dust collection unit. 5. Follow the instructions in sections 2 and 3 of this manual to prepare for blasting.
  • Page 99 MicroBlaster MB1006 AppendixC: Workstations WS2200 Classic WorkStation WS6000 ClearView WorkStation Item Description WS2200-1 WS2200-3 WS2280-1 WS2280-3 WS6000-1 Window Assembly WS2014-2 WS2014-2 WS2014-2 WS2014-2 WS6014 Window (Glass only) WS1138-2 WS1138-2 WS1138-2 WS1138-2 Window Shield WS2278-3 WS2278-3 WS2278-3 WS2278-3 WS2278-3 Seal ST3260...
  • Page 100 Appendix C: Workstations MicroBlaster MB1006 WS2200 series Classic WorkStation – 115 or 230V For 230V CE compliant workstations see below For workstations equipped with ESD controls see page 7 WS2200 series Classic WorkStation – 230V CE Compliant For workstations equipped with ESD controls see page 7 Rev.
  • Page 101 MicroBlaster MB1006 AppendixC: Workstations WS2200 series Classic WorkStation with ESD Controls – 115 or 230V For 230V CE compliant workstation see below WS2200 series Classic WorkStation with ESD Controls – 230V CE Compliant Rev. 10/07 Comco Inc. Issue Date: September 2003...
  • Page 102 Appendix C: Workstations MicroBlaster MB1006 WS6000 series Clearview WorkStation – 115 or 230V For 230V CE compliant ClearView WorkStation see below WS6000 series ClearView WorkStation – 230V CE Compliant Rev. 10/07 Comco Inc. Issue Date: September 2003...
