Features

The 300A ESC is one of the most powerful brushless speed controllers for rc model
airplanes. It is microprocessor controlled, and extremely low resistance. The unique
design, extreme powerful and optimum performance make the 300A ESC be the best
choice for big model airplanes. Meanwhile, it comes with following features:
Accurate current control and current limiting
Multi-point temperature protection
Smoothly start up with constant power output
Motor block-up protection
Very good cooling system, and easily to mount
With Data logger (optional version)

Specifications

Voltage: 12V-65V (4s-15s Lipo)
Current: 300A (380A surge within 10 seconds)
No BEC
Size:19cm x 12cm x 4.9cm
Weight:850g
Auto detect Lipo cells
Fully Programmable LVC, cutoff voltage of each Lipo, current limiting, cutoff type, brake type, timing
advance, start type and governor mode.
The parameters with asterisk * behind are the preset parameters of 300A ESC in factory.
1 cell
LVC
2.5v
LVC/per cell
Sensitivity Standard* Insensitivity Close
Current limiting
Close*
Brake type
Auto*
Timing advance
Hard*
Cutoff type
Soft
Start type
Auto*
Governor mode
300A ESC Manuals
2 cells
3 cells
2.6v
2.7v
Soft
Hard
Low
Middle
Soft
Standard* Fast
Low
Hight
4 cells*
5 cells
...
2.8v
2.9v
3.0v *
High
19 cells
20 cells
Auto
3.1v
3.2v
3.3v
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fatboy 300A ESC and is the answer not in the manual?

Questions and answers

Summary of Contents for Turnigy Fatboy 300A ESC

  • Page 1 Page 1 300A ESC Manuals Features Ⅰ The 300A ESC is one of the most powerful brushless speed controllers for rc model airplanes. It is microprocessor controlled, and extremely low resistance. The unique design, extreme powerful and optimum performance make the 300A ESC be the best choice for big model airplanes.
  • Page 2 Page 2 Ш Using the ESC A. ESC picture Red LED Green LED Battery wire (-) Two small wires Battery wire (+) Receiver lead Battery wire (+): Connect positive battery wire of ESC to positive polarity of battery pack. Anti-spark pin: the pin is used to eliminate the generated sparks when connect ESC to battery. Power LED: The LED is red.
  • Page 3 Page 3 B. Connect ESC to motor, receiver, battery pack Preparation before connecting: 1. Solder three 8.0mm male golden bullet connectors to brushless motor; 2. Solder good conductive connectors to battery wires of ESC; 3. Prepare a UBEC or a separate receiver battery. Connecting steps: - Switch ‘OFF’...
  • Page 4 Page 4 C. Calibrate throttle travel of transmitter Push the joystick of transmitter to max throttle position, power on the transmitter. 2nd: max throttle position (it will be 100% throttle point) 3rd: 4th: After the following 2 beeps , immediately pull joystick to minimum throttle . minimum throttle (it will be zero throttle point) 5th: 2 beeps...
  • Page 5 Page 5 HIFEI ESC Press left arrow ‘←’ to get into PARA SETTING menu Fulcrum-300A Up and down arrow‘↑’‘↓’ to select Press left arrow ‘←’ again to get into set LVC of ESC. ‘↓’ Parameter options Press down arrow to back ESC’s parameter to default Fulcrum-300A 1 cell 2 cells...
  • Page 6 Page 6 Using warnings Ⅴ • It’s strongly recommended to calibrate the throttle travel of your transmitter when you fist use the ESC or when use a new/different transmitter or receiver. • When connecting the ESC to battery pack, please ensure the polarity is correct. Incorrect polarity may cause permanent damage to the ESC and such damage is not covered by the WARRANTY.
