TASCAM DR-07 digital recorder* guide

Using recorder for interviews, oral histories, and spoken word recordings.

1. Turning recorder on

Plug in recorder with power cord

-Or-

If using recorder with battery power, be sure to have 2

extra AA batteries on hand. Battery compartment is on

back of unit.

Turn on power by pushing and holding the power button

on the left side of the unit.

Digital recorder is set for archival recording: WAV 24bit format, 48k sampling rate.**

Recorder is also set to use its built-in microphone. Please do not adjust these settings!

You should have 2 hours worth of recording time at these settings.

Table of Contents

Do you have a question about the DR-07 and is the answer not in the manual?

Page 1 Madison Library TASCAM DR-07 digital recorder* guide Using recorder for interviews, oral histories, and spoken word recordings. 1. Turning recorder on Plug in recorder with power cord -Or- If using recorder with battery power, be sure to have 2 extra AA batteries on hand. Battery compartment is on back of unit.
Page 2 Note: You can use earphones to monitor while recording, but you don’t have to. Earphone plug is on right side at top. 3. Getting ready to record Press RECORD button once to put unit on standby. Red light around the button will start flashing. If using earphones, do some test speaking and adjust REC LEVEL using control on right side of unit.
Page 3 ANY FILES. 8. Turning recorder off Turn off power by pushing and holding the power button on the left side of the unit. *For technical details about the Tascam DR-07 recorder, see http://transom.org/?p=3266 **For technical information about digital audio formats, see...
