Bestway Flowclear AquaCrawl Owner's Manual

AQUACRAWL POOL VACUUM
OWNER'S MANUAL
WARNING
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS.
WARNING: To reduce the risk of injury, do not permit
children to use this product.
WARNING: Assembly and disassembly of this product
should only be performed by adult.
WARNING: Do not remove or obstruct the float opening
while the filter pump/sand filter is operating.
WARNING: Keep hands and hair away from the Pool
Vacuum while the filter pump/sand filter is operating.
WARNING: Do not use the filter pump/sand filter while the
pool is occupied.
WARNING: Ensure the filter pump/sand filter is unplugged
before any maintenance begins or severe risk of injury or
death exists.
NOTE: Remove the product from the pool before placing a
cover over the pool.
NOTE: Please examine and verify all components are
present before use. Notify Bestway at the customer service
address listed on this manual for any damaged or missing
parts at the time of purchase.
NOTE: Drawings for illustration purpose only. May not
reflect actual product. Not to scale.
SAVE THESE INSTRUCTIONS

Specification

Filter Pump/Sand Filter Compatibility :
Pool Compatibility :

Parts Reference Overview

P6704ASS16
P03867
P6357ASS16
P6705ASS16
NOTE: Drawing may not reflect actual product, not scaled to size.
No. Name No.
P6704ASS16 Suction Head P6334ASS16
Super Vacuum
P6705ASS16 P03867
Brush Nozzle
P6355ASS16 Vacuum Body P6124ASS16
P6352ASS16 Poles P6357ASS16
Vacuum Cover
P6706ASS16
NOTE: To order Pool Vacuum spare parts, please provide us with part No.
Assembly Illustrations
Step 1(a)
P6704ASS16
Step 2
Step 4
2,006 L/h (530 gal./h) flow rate and above
15' and below
P6124ASS16
P6355ASS16
P6334ASS16
P6352ASS16
Name
Hose
Hose Adapter
(Fix to pools with Connection Valves)
Hose Clamps
Debris Bag
Step 1(b)
P6705ASS16
Step 3
Diagram 5
Step 5.1
IMPORTANT: Place the vacuum into the water and fill the
vacuum hose with water in order to remove all the air.
Follow the 3 steps in diagram 5. Use the vaccum only when
the hose is full of water.
6(a1)
B
6(a2)
6(b)
B
NOTE: We supply Hose Adapter, use it for your pool.
(See Step 6a1)
If there are two outlet valves on your pool, please block one
of them. (See Step 6a2)

Operation

1. Set up the filter pump/sand filter following the filter
pump/sand filter owner's manual. Turn on the Filter
Pump/Sand filter to activate the Pool Vacuum.
NOTE: If the filter pump/sand filter is running dry, no water
flowing into the filter pump/sand filter, please unplug the
pump, open the Air Release Valve to bleed the air from
the filter pump/sand filter. When water starts to flow out,
close the Air Release Valve. restart the pump.
2. Sweep the entire bottom surface of the pool liner until it is clean.
3. When finished unplug the Filter Pump/sand filter, and
remove any debris from the Debris Bag.
NOTE:The internal debris bag is designed to trap leaves
and larger debris. Never use your Pool Vacuum without
the debris bag; failure to do so may clog your filter
pump/sand filter. Make sure to empty the debris bag
regularly to ensure the maximum suction possible.
Storage
1. Disassemble the product.
2. Clean and dry all the parts thoroughly.
3. Store it in its original package in a warm dry place.
1
Step 5.2 Step 5.3
A
(1)
B
(2) (3)
A
B
P03867
P03867
