- Page 1 Air-handling Units MANDÍK INSTALLATION COMMISSIONING MAINTENANCE Addition instructions of the hygienic design...
- Page 2 +420 311 706 706 fax: +420 311 584 810 email: mandik@mandik.cz service department: service@mandik.cz This manual is an integral part of the technical specifications TPM 088/12 Air-handling Units MANDÍK. © Copyright MANDÍK, a.s. 2021. Subject to change. IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz...
-
Page 3: Table Of Contents
KJM MANDÍK Installation, Commissioning, Maintenance CONTENTS GENERALY ........................4 INSTALLATION ....................... 5 COMMISSIONING ......................6 OPERATION AND MAINTENANCE................... 7 SERVICE ACCESS ....................10 REMOVAL AND CLEANING OF THE DOOR SEALING PROFILE ....... 11 CLEANING AND DISINFECTION ..................12 IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz... -
Page 4: Generaly
DIN EN 13779 EN 1886 DIN 1946-4 SWKI 99-3 ÖNORM H 6020 The design of the AHU is certified by a German authorized person - Hygiene-Institut des Ruhrgebiets (www.hyg.de). Certificate is available at https://mandik.cz/product-line/air- handling-units/air-handling-units-mandik IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz... -
Page 5: Installation
Cables shall, if possible, be laid outside the unit. Inside the unit, they should preferably not be laid in conduits and cable routes should be as short as possible IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz... -
Page 6: Commissioning
• before commissioning the intended air filters properly shall to installed • before commissioning, check that all inspection and cleaning openings and drains for cleaning are securely sealed. All condensate drains shall be tested with a IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz... -
Page 7: Operation And Maintenance
The AHU must be regularly inspected at short intervals by trained specialist personnel to ensure that the hygienic requirements for operation and maintenance are observed at all times! Hygienic inspections beyond standard procedures (general installation manual AHU MANDÍK) are summarized in the following table: IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz... - Page 8 Check impermeability between supply and 5.02. Repair exhaust air Check condensate tray for contamination and 5.03. Clean, repair drain trap function rotary heat exchangers: check of rotor sealing Adjust seals, clean, 5.04. tightness repair IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz...
- Page 9 … and its terms of the assessment values, the required qualifications, the measurement procedure, and the evaluation of the measurement results are beyond the scope of this manual and these points are described in VDI 6022, Blatt1, Section 8. IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz...
-
Page 10: Service Access
For cleaning and disinfection is each section (fans, filters, heat exchangers, silencres, …) accessible from both sides via doors or service panels: heat exchanger´s section light switch service door with handles/hinges service door with clamping brackets IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz... -
Page 11: Removal And Cleaning Of The Door Sealing Profile
4.2 REMOVAL AND CLEANING OF THE DOOR SEALING PROFILE The sealing profile can be extended by releasing the pressure ledge with screws M5 with hex socket 4 around the door: outer sealing pofile inner sealing pofile screw ledge IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz... -
Page 12: Cleaning And Disinfection
- in general a higher concentration guarantees a better disinfecting effect, but a low concentration is disinfectant ineffective, on the contrary too high leads to damage to the disinfected material IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz... - Page 13 Be careful not to damage the materials/surface Disinf ection w ith a cloth/spraying of the cleaned components Only for installations that are equipped w ith a Disinfection w ith a foam/low pressure fluid 1) 2) condensate tray and drain IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz...
- Page 14 Use only low pressure equipment up to a maximum of 20 bar. In the case of heat exchangers (heaters/coolers/recuperators) use recemended cleaning and disinfecting agents listed below (surfactants based on a Quaternary ammonium, …). IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz...
- Page 15 The company MANDÍK, a.s. recommends these effective bactericidal and fungicidal substances for the above-mentioned surfaces: Descosept Spezial, Dr. Schumacher GmbH, bactericidal, Active ingredient: Quaternary ammonium Sanosil, SANOSIL AG, bactericidal, fungicidal, Active ingredient: Hydrogen peroxide IZU 1.0 01/2021 MANDÍK, a.s., www.mandik.cz...
