ATTACHING / REMOVING THE BASE

Install:
Align the release button on the bottom of the monitor
with the corresponding slots on the bottom of the
base.

SCREEN POSITION ADJUSTMENT

In order to optimize the best viewing position, you can adjust the tilt of the monitor by using both of your
hands to hold the edges of the monitor as shown in the figure below.
The monitor can be adjusted to 15 degrees up or 5 degrees down as indicated by arrow below.
Remove:
Depress the release button as indicated first before
removing the base and follow the arrow direction to
remove it.
EN- 6
X233H
