  • Page 1 FMS500 TACHO SDK GNSS VEHICLE TRACKER User manual FMS500 TACHO SDK...

  • Page 2: Table Of Contents

    Contents FMS500 TACHO SDK general device information ..............3 1.1. Safety and legal information ....................3 1.2. Description ..........................3 1.3. Package ..........................3 1.4. Technical specifications ......................4 1.5. Physical properties ......................... 5 1.6. Pinout & diagnostic LED ....................... 7 1.6.1.

  • Page 3: Fms500 Tacho Sdk General Device Information

    Installed by qualified professionals only. Copyright © XIRGO GLOBAL, Ltd. All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without prior written permission of XIRGO GOBAL is strictly prohibited.

  • Page 4: Technical Specifications

    1.4. Technical specifications Table 1. FMS500 TACHO SDK technical specifications General Physical Peripherals 2x CAN lines 1-Wire RS-232 EIA-485 / J1708 Digital Inputs 4x discrete (frequency, impulse counter, ON/OFF modes) Voltage threshold dynamic Analog Inputs 3x analogue, 12 bit, 0-31V...

  • Page 5: Physical Properties

    Physical properties Fig. 1. FMS500 TACHO SDK front view. Note. To insert a SIM card, open the box by lifting plastic holders from both sides. Table 2. FMS500 TACHO SDK components. Short description LED indicator SIM card Socket 2x8 pins...
  • Page 6 Fig. 2. FMS500 TACHO SDK dimensions, mm Xirgo Global Chemijos st. 15 LT-51332, Kaunas, Lithuania www.xirgoglobal.com...

  • Page 7: Pinout & Diagnostic Led

    Purple Blue CAN2 H CAN2 L 1-WIRE IN5/ADC5 IN3/OUT1 IN2/ADC4 RS485 (B) RS485 (A) Yellow Yellow/black Brown Grey/black Purple/black White/black Green Green/black Fig. 3. FMS500 TACHO SDK pinout and cable colors. Xirgo Global Chemijos st. 15 LT-51332, Kaunas, Lithuania www.xirgoglobal.com...

  • Page 8: Diagnostic Led

    1.5.2. Diagnostic LED FMS500 TACHO SDK has an indication LED – for GNSS, Cellular modem and CAN line status. LED starts flashing only if IN5 digital input is connected to battery +. Fig 4. Cellular signal flashing example Fig 5. GNSS signal flashing example Fig 6.
  • Page 9 Modem GPRS registered, Modem GSM registered, Modem SIM card ok, Modem turned on Modem GSM registered, Modem SIM card ok, Modem turned on Modem SIM card ok, Modem turned on Modem turned on Device started Xirgo Global Chemijos st. 15 LT-51332, Kaunas, Lithuania www.xirgoglobal.com...

  • Page 10: Installation

    1.8. Support FMS500 TACHO SDK is built to be a reliable, stable and easy to install device. Please read and follow provided installation and operating instructions carefully. However, if you encounter difficulties while installing or using this product, technical support is available and may be reached by e-mail support@xirgo.com...

  • Page 11: Annex 1. Installation Instructions

    List of suitable vehicles FMS500 TACHO SDK is intended for internal combustion engines, hybrid and electric engines, where power supply specifications are met. Device must be connected to the vehicle battery, ensuring constant power supply even if the engine is not working and ignition is off.
  • Page 12 6. Connect ignition wire to a digital input (usually IN5); 7. Connect array; 8. Connect other devices (optional). Tools/equipment necessary for the installation: 1. Pliers 2. Stripping pliers 3. Screwdriver 4. Multimeter (tester) 5. Fastening straps 6. Isolation tape Xirgo Global Chemijos st. 15 LT-51332, Kaunas, Lithuania www.xirgoglobal.com...
  • Page 13 If the vehicle is travelling to foreign countries, roaming service must be activated for the SIM card. The SIM card and phone number must be checked and clearly marked on the installation certificate of the device. Xirgo Global Chemijos st. 15 LT-51332, Kaunas, Lithuania www.xirgoglobal.com...
  • Page 14 Cellular antenna does not require orientation to open sky; however you should be aware that metal elements weaken the GSM signal. It is also necessary to take into account the emission of the antenna’s high frequency radio waves, which may interfere with operation of electronic devices. Xirgo Global Chemijos st. 15 LT-51332, Kaunas, Lithuania www.xirgoglobal.com...
