- Page 1 Mounting guide...
-
Page 2: Important Warnings And Safety Instructions
Do not clean the camera with harsh detergents, gasoline or chemicals such as Acetone. • Do not try to repair the unit yourself. Refer all servicing of the camera to Ava or contact a reseller. • This product should be supplied by a Power over Ethernet (PoE) Power Sourcing Equipment (PSE) compliant to IEEE 802.3af. -
Page 3: Box Content
Box content Screw dimensions Anchor dimensions = 9.2 mm = 30 mm l = 32 mm = 6 mm d = 4.1 mm 3 /8 Ava Compact Dome • Mounting guide |... -
Page 4: Camera Placement
High on a wall or in the ceiling are good placements for the camera. 300 mm Avoid placing the camera near obstacles and overhangs, or in a corner. This causes reflections which reduce the image quality, especially when using night vision. 4 /8 Ava Compact Dome • Mounting guide |... - Page 5 Using the drilling template to place the camera For through the wall cable connections, mark the cable entry position using the template. 5 /8 Ava Compact Dome • Mounting guide |...
- Page 6 Drill the holes and install the anchors and camera Dia: 6mm, [¼”] Depth: 40mm [1.5”] 6 /8 Ava Compact Dome • Mounting guide |...
-
Page 7: Adjust The Picture
Attach the ethernet cable Adjust the picture Use the video stream to confirm the image orientation. Adjust the image orientation in Ava Aware. Ava Compact Dome • Mounting guide |... -
Page 8: Install The Top Cover
Install the top cover For side entry cable connections, Use a long nose pliers or similar to you must remove the the cable pull out the cable bridging piece. bridging piece. 8 /8 Ava Compact Dome • Mounting guide |...
