Summary of Contents for Toyota 2008 SIENNA
- Page 1 2008 Quick Reference Guide...
- Page 2 Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Sienna. A word about safe vehicle operations This Quick Reference Guide is not a full description of Sienna operations.
- Page 3 Seat belts Seat belts-Shoulder belt anchor Spare tire & tools Tire Pressure Warning System reset Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. ® HomeLink...
-
Page 4: Instrument Panel
Emergency flasher button Audio system or navigation system 115V AC Power outlet ON/OFF button AUX adapter Toyota park assist system and indicator Front Air Conditioning controls Front passenger occupant classification indicator Seat heater switch 12V DC Power outlets Interior lights main switch Engine switch “TRAC OFF”... - Page 5 Tilt and telescopic steering lock release Tire Pressure Warning System reset Power rearview mirror controls Power quarter window switch Headlight beam level control dial Conversation mirror Front personal lights Microphone Power sliding door button Power back door button Electric moonroof switch Steering wheel audio controls Telephone controls Dynamic Laser Cruise Control distance switch...
-
Page 6: Instrument Cluster
OVERVIEW Instrument cluster If equipped Service indicator and reminder Speedometer Engine coolant temperature Low fuel level warning Fuel gauge Trip meter reset knob Odometer and two trip meters Tachometer Dynamic Laser Cruise Control master warning Dynamic Laser Cruise Control display Indicator symbols Brake system warning Driver seat belt reminder... - Page 7 Open door warning Airbag SRS warning Vehicle Stability Control/Traction Control warning Low Tire Pressure Warning Low windshield washer fluid level warning Engine oil replacement reminder Third seat fold incomplete warning Theft deterrent/Engine immobilizer system indicator “AIRBAG ON” indicator “AIRBAG OFF” indicator Headlight low beam indicator Headlight high beam indicator Turn signal indicator...
-
Page 8: Keyless Entry
OVERVIEW Keyless entry Locking operation Unlocking operation Push ONCE: Driver door Push TWICE: ALL doors NOTE: After unlocking, if a door is not opened within 60 seconds, all doors will relock for safety. Power sliding door operation (if equipped) Right side power Left side sliding door power... -
Page 9: Fuel Tank Door Release And Cap
Fuel tank door release and cap Driver seat Pull up Turn Store NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Engine maintenance Power steering fluid reservoir Windshield and rear window washer fluid tank Engine oil filler cap Engine oil level dipstick Engine coolant reservoir... -
Page 10: Features/Operations
FEATURES/OPERATIONS Auto lock functions Automatic door locks can be programmed to operate in four different modes, or turned OFF. -Doors lock when shifting from “Park.” -Doors lock when the vehicle speed goes above approximately 12 mph. -Doors unlock when the engine key is turned to the “ACC”... -
Page 11: Lights & Turn Signals
Lights & turn signals Headlights AUTO* Headlights Parking lights High beam Low beam High beam flasher * If equipped -Daytime Running Light system (if equipped) Automatically turns on the headlights at a reduced intensity. -Automatic light cut off system Automatically turns lights off after 30 seconds when any of the doors are opened and closed with the engine off. -
Page 12: Window Wipers & Washers
FEATURES/OPERATIONS Window wipers & washers Front Single wipe Adjust interval Interval wipe Pull to wash and wipe Slow Fast Rear Wash and wipe Wipe Interval wipe Wash and wipe Parking brake Set: Depress Release: Depress again Windows-Power quarter (if equipped) Open Push and hold Close... -
Page 13: Moonroof (If Equipped)
Windows Driver side Window lock switch Down Down Automatic operation* (driver side only) Push the switch completely down or pull it completely up and release to fully open or close. To stop window midway, lightly push the switch in the opposite direction. -
Page 14: Door-Power Back (If Equipped)
FEATURES/OPERATIONS Doors-Power sliding (if equipped) Instrument panel ON/OFF switch Push Center pillar Front overhead console Open: Push Close: Push again NOTE: • When the engine switch is in the “ON” position, power sliding doors will open only when gear selector is in the “P” (Park) position, and doors are unlocked. - Page 15 Console box (if equipped) Remove Inst Front seat Second row seat Lock release lever Auxiliary box The console box can be removed and installed between the front or second row seats. To remove Open the auxiliary box on the rear side, and pull the lock release lever.
-
Page 16: Seat Adjustments-Front
FEATURES/OPERATIONS Seat adjustments-Front Manual seat Power seat Position Height crank (driver side only) Seatback angle Lumbar support (driver side only*) Position, cushion angle and height Seatback angle * If equipped Seat adjustments-Rear Second row seat Outer Center Third row seat Manual Power Position... -
Page 17: Seats-Head Restraints
Seats-Head restraints Front Rear Lock release button Lock release button Seat arrangements (examples) These are some possible seat arrangements. Please read the following section and refer to the Owner’s Manual for more information about seat positions. 7-passenger models 8-passenger models 7-passenger models The right seat can be placed in the inside or outboard position. -
Page 18: Seats-Tumble/Remove Second Row Seats
FEATURES/OPERATIONS Seats-Tumble/Remove second row seats (1) Lower the head restraint and slide the seat to the rear-most locked position. (2) Pull the strap or lever and tumble the seat. (3) Pass the strap through the assist grip. (4) Pull and hold the strap, then fold down the seat to disengage from front hooks. - Page 19 Seats-Stowing third row seats (power)(if equipped) Lower Push Stowing seat Returning seat Third seat fold Third seat fold incomplete warning light incomplete warning light Push and hold Push and hold This light will remain “ON” until the seat is fully open or stowed.
-
Page 20: Cruise Control (If Equipped)
FEATURES/OPERATIONS Cruise control (if equipped) System ON/OFF System ON/OFF Functions Resume /Increase speed Cancel Set/Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed reaches 25 mph. Dynamic Laser Cruise Control (if equipped) Refer to the Owner’s Manual for more details and complete safety precautions before attempting to... -
Page 21: Light Control-Instrument Panel
Distance control mode Push System ON/OFF The distance control mode will cruise at a set speed, decelerate to maintain a selected distance from a slower vehicle in front of you, and accelerate back up to the selected speed if the vehicle in front of you changes lanes or speeds up. - Page 22 FEATURES/OPERATIONS Audio Type 1 Preset buttons - functions in other modes indicated above number. Eject CD Push to adjust Push to turn tone & ON/OFF balance Seek Push to station/ skip CD track up/down Mode View CD Station/CD select folder information track scan Type 2 additional functions...
-
Page 23: Telephone Controls (Bluetooth (If Equipped)
Steering wheel switches (if equipped) “ ” Volume control “ ” -In radio mode Push to select a preset station; push and hold to seek the next strong station. -In CD mode Push to skip up or down to next/ previous track. -
Page 24: Air Conditioning/Heating
FEATURES/OPERATIONS Air Conditioning/Heating Front manual Air Conditioning Air Conditioning ON/OFF Use fresh air to quickly cool interior, then change to recirculate for cooler air. Fresh or recirculated cabin air Airflow vent In “ ” or “ ” mode, use fresh air (“... - Page 25 Front automatic Air Conditioning Temperature (driver side) Temperature (front passenger side) Air Conditioning ON/OFF Synchronizes front and rear temperature settings Airflow vent In “ ” or “ ” mode, use fresh air (“ ” indicator ON) to reduce window fogging. Windshield airflow/defogger Temperature (rear passenger side) Fan speed...
-
Page 26: Rear Seat Entertainment System (If Equipped)
* can be programmed to operate garage doors, estate gates, security lighting, etc. Refer to “Multi-information display,” Section 1-10 in the Owner’s Manual for more details. For programming assistance, contact the Toyota Customer Experience Center at 1-800-331-4331, or visit http://www.homelink.com. Change display information... -
Page 27: Power Outlets
Power outlets 12V DC Luggage compartment Instrument panel 115V AC (if equipped) Beside second row seat ON/OFF switch Beside third row seat Designed for car accessories. Engine switch must be in the “ACC” or “ON” position to be used. Bottle holders Front doors Sliding doors Note: Do not place open containers in the sliding... -
Page 28: Cup Holders
FEATURES/OPERATIONS Cup holders Instrument panel Front side table Third row area Rear console box Rear side Front side Tray... -
Page 29: Safety And Emergency Features
SAFETY AND EMERGENCY FEATURES Door locks Unlock Lock Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seat belts-Shoulder belt anchor Push up, or squeeze lock release to lower Seat belt comfort guide... -
Page 30: Seat Belts
SAFETY AND EMERGENCY FEATURES Seat belts Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. This feature is used to help hold child restraint systems securely. -
Page 31: Spare Tire And Tools
Spare tire & tools All-wheel drive models are equipped with run-flat tires. Refer to the Owner’s Manual for more detail. Tool and spare tire location Two-wheel drive models Wheel nut wrench Jack handle Jack Spare tire Removing the spare tire Two-wheel drive models Spare tire clamp bolt Turn... - Page 32 Customer Experience Center 1-800-331-4331 MN 00505-QRG08-SIE Printed in the USA 7/07...
