Included Parts with the Keyboard Desk - BOX 3
Please check to see you have all parts before
starting. Once all parts are confirmed begin assembly.
Instructions for
Assembling Keyboard Desk
Keyboard Desk Main Surface
Keyboard Desk Leg - Left
Keyboard Desk Leg - Right
Keyboard Spreader Bar Assembly
Work Surface Stiffener
#8 x .75" Pan Head Wood Screw
Work Surface Bracket
Leg Leveler Assembly
x50
970.776.1920 . www.ultimatesupport.com
Copyright 2017, Ultimate Support Systems . All Rights Reserved
x1
x1
x1
x1
x1
x4
x4
