6. Put the dust bag A17 back in.
7. Close the top cover A10.
Attention:
Never insert the filter back into the vacuum cleaner if it is wet or
damp! Always wait until it is thoroughly dry.
Replacing the outflow filter
1. Remove the protective grille A3 and take out the outflow filter A4.
2. Replace it with a new one and reinstall the grille A3.
Attention:
Do not use the vacuum cleaner without the filters (A4 and A19)
installed.
Cleaning the vacuum cleaner
To clean the outside parts of the appliance use a fine cloth dipped in lukewarm
water. Do not use aggressive cleaning agents, paint thinners or solvents. Using these
solutions could damage the surface of the appliance.
Storage
You may store the vacuum cleaner disassembled into its individual parts or you can
store it assembled in the parking position.

TROUBLESHOOTING

Before you decide to contact an authorised service centre, please read through the
following table:
Problem Possible cause
The motor will The power cord is not
not start inserted correctly in the
power socket.
The power socket is
damaged.
The vacuum cleaner is not
switched on.
Suction power The appliance cleaner is
is weak clogged.
The dust bag A17 is full.
The power cord The power cord may have
is not wound in slipped down from the
completely. winding pulley during
winding.
The cable cannot The cable is wound up
be pulled out. incorrectly.
The power The winding mechanism is
cord winds up damaged.
automatically.
It is not possible The inflow filter A19 is not
to close the top inserted correctly.
cover A10.
TECHNICAL SPECIFICATIONS
Rated voltage range ..........................................................................................................220 – 240 V~
Rated frequency ........................................................................................................................50 / 60 Hz
Rated power input .......................................................................................................................... 700 W
Noise level ......................................................................................................................................75 dB(A)
Length of the power cord ................................................................................................................ 5 m
Operating range .................................................................................................................................. 8 m
Dust bag capacity .................................................................................................................................... 2 l
Dimensions (length × width × height) .....................................................350 × 268 × 228 mm
Weight ................................................................................................................................................ 3.75 kg
The declared noise emission level of the appliance is 75 dB(A), which represents a level
A of acoustic power with respect to a reference acoustic power of 1 pW.
Copyright © 2019, Fast ČR, a.s.
We reserve the right to change text and technical specifications.
INSTRUCTIONS AND INFORMATION REGARDING
THE DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at a site designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC
EQUIPMENT
and prevents potential negative effects on the environment and human health, which
could result from improper waste disposal. Ask your local authorities or collection
facility for more details.
In accordance with national regulations penalties may be imposed for the incorrect
disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier
for the necessary information.
Disposal in other countries outside the European Union
Possible solution
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the local
Insert the plug firmly into
council or from your retailer.
the power socket.
Inspect the power socket.
Turn on the appliance.
Remove the items
that have clogged the
appliance.
Replace it with a new one.
Hold the cable under
tension while winding
the cable.
Press button A1 and try
again
Contact an authorised
service centre.
Install the inflow filter A19
correctly.
- 7 -
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by double or heavy-
duty insulation.
This symbol on products or original documents means that used
electric or electronic products must not be added to ordinary
municipal waste. For proper disposal, renewal and recycling hand
over these appliances to determined collection points. Alternatively,
in some European Union states or other European countries you may
return your appliances to the local retailer when buying an equivalent
new appliance.
Correct disposal of this product helps save valuable natural resources
This product meets all the basic requirements of EU directives related to
it.
12/2019
