Bagless Vacuum Cleaner
User's manual
SVC 1030 (Cat & Dog)
Translation of the original manual
Before first use, please read all instructions contained in this user's manual carefully, even if you are already
familiar with using similar products. Only use this product in accordance with the instructions described in the
user's manual. Keep the user's manual in a safe place where it can be easily retrieved for future use.
Save the original packaging, including the internal packing material, warranty card and proof of purchase receipt,
at least for the duration of the warranty. If you need to ship this product, pack it in the original cardboard box
to ensure maximum protection during shipping or transport (e.g. when moving or when you need to send this
product for repair).
EN-1
2019
09/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVC 1030 Cat & Dog and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sencor SVC 1030 Cat & Dog

Summary of Contents for Sencor SVC 1030 Cat & Dog

  • Page 1 Bagless Vacuum Cleaner User's manual SVC 1030 (Cat & Dog) Translation of the original manual Before first use, please read all instructions contained in this user's manual carefully, even if you are already familiar with using similar products. Only use this product in accordance with the instructions described in the user's manual.

  • Page 2: Table Of Contents

    Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) CONTENTS IMPORTANT SAFETY NOTICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 DESCRIPTION .

  • Page 3: Important Safety Notice

    Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) IMPORTANT SAFETY NOTICE READ CAREFULLY AND STORE FOR FUTURE USE. This vacuum cleaner may be used by children 8 years of age ■ and older and by persons with physical or mental impairments or by inexperienced persons, if they are properly supervised or have been informed about how to use this vacuum cleaner in a ...
  • Page 4 Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) Do not use the vacuum cleaner to vacuum the following items: ■ – smouldering cigarettes, burning items, matches or embers; – water and other liquids; – flammable or volatile materials; – sharp items, e.g. broken glass, needles, pins, etc.; –...

  • Page 5: Description

    Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) DESCRIPTION 1 START/STOP button 2 Dust container button 3 Dust container handle 4 Vacuum hose connection socket 5 Vacuum cleaner handle 6 Motor power output control 7 Outflow micro-filter cover 8 Cord winding button 9 Rubber wheel 0 Dust container qa Handle...

  • Page 6: Assembly

    Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) 1 Handle 2 Vertical parking position 3 Front wheel mechanism ASSEMBLY Inserting the hose into the air suction socket on the vacuum cleaner: Press the safety button on the hose end and insert the hose end into the air suction socket on the vacuum cleaner until you hear "click"...

  • Page 7: Using Your Accessories

    Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) Turning your vacuum cleaner on and off To switch your machine on or off, press the START / STOP button on the vacuum cleaner body . Adjusting the suction strength The suction strength may be adjusted by moving the rider on the vacuum cleaner body ( small range) or by the moveable rider on the hose handler .

  • Page 8: Storage Of Vacuum Cleaner

    Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) Ending the vacuuming process When you finish vacuuming, switch the vacuum cleaner off by pressing the START / STOP button and then disconnect the power plug from the socket . To wind the power cord back to the vacuum cleaner, press and hold the winding button with one hand . Hold the cord with your other hand to protect the vacuum cleaner input area from damage Tip: If the winding process stops and part of the power cord is still outside, release the winding button and pull...
  • Page 9 Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) Press the safety lock and pull the dust container handle up at the same time to remove the dust container from the vacuum cleaner . Place the dust container over a waste bin . Press the safety clip of the bottom hatch on the dust container and the bottom hatch will open .
  • Page 10 Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) Press the safety clip and pull the dust container handle up at the same time to remove the dust container from the vacuum cleaner . Fold out both safety clips of the H .E .P .A . filter frame, take it off the dust container and from behind it also remove the foam pre-filter .

  • Page 11: Troubleshooting

    Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) First remove the grill of the outflow filter by pulling upwards in the place of both safety clips . Then remove the outflow filter and the foam pre-filter and replace them with new ones . After reinserting both filters attach the cover and click in both clips .

  • Page 12: Technical Specifications

    Bagless Vacuum Cleaner SVC 1030 (Cat & Dog) TECHNICAL SPECIFICATIONS Nominal voltage ........................220 – 240 V AC Nominal frequency .
