Jandy iQ20 Quick Start Manual page 2

1. WIRE IQ20 WEB-CONNECT DEVICE TO THE
AQUALINK ® AUTOMATION SYSTEM
2
1
Connect RS485 cable to an open
Turn off power to AquaLink.Remove
connector on the AquaLink power center
the dead panel. Pass iQ20 web-connect
board. Do not connect more than two
device cable through the low voltage
RS485 cables per red terminal bar.
raceway.
4
3
Restore power to the AquaLink
Reinstall the dead panel (and close doors
system.
if applicable) to ensure high-voltage areas
are secured.
2. START WI-FI SETUP MODE
NOTE:
This step will clear all current Wi-Fi settings from memory.
Remove the device lid by removing
the two screws on the cover. To
clear any previous Wi-Fi settings,
toggle the Wired-Wi-Fi switch.
Then set the switch to the desired
mode. Proceed to step 3A or 3B to
reprogram the Wi-Fi settings.
i
See Helpful Hints #2 for
more info
3. CONNECT IQ20 WEB-CONNECT DEVICE TO THE HOME NETWORK
3.1 Wi-Fi: Hotspot Method
(*Home network name (SSID) and password are required)
WiFi
iAquaLink ***
1
2
Remove two screws on front cover. Remove the Open the Wi-Fi settings on your smart
cover and gasket from the web-connect device. To device and choose the network named
clear Wi-Fi settings and enter Wi-Fi Setup mode, "iAquaLink-***"
toggle the WIRED / WI-FI switch to WIRED then
i
Some devices will automatically redirect you to the
back to WI-FI.
Log In screen. If this does not occur, open a browser
and navigate to "setup.iaqualink.com".
3.2 Wi-Fi: WPS Method
1
2
Remove the two screws on front cover. Remove the
Press the WPS Button on the home network
cover and gasket from the web-connect device. To
router. To find it, look for the
clear WiF-i settings and enter Wi-Fi Setup mode,
toggle the WIRED / WI-FI switch to WIRED then back
to WI-FI.
3.3 Wired: Ethernet Method *
1
2
Remove two screws on front cover. Remove
Using needle-nosed pliers, remove
the cover and gasket from the web-connect
the plastic break-away.
device. To clear Wi-Fi settings and enter
Wi-Fi Setup mode, toggle the WIRED / WI-FI
switch to WIRED then back to WI-FI.
4. SET UP USER ACCOUNT
Download the free iAquaLink app from the Apple App Store
or from Google Play, or navigate to "iAquaLink.com" from
any browser. Select "Sign Up" to create an account.
i The pool owner must register with their own email and
i
password to use the iAquaLink app or web interface.
My Network
Neighbors Network
3
Neighbor #2
All networks within range will be displayed.
Select the desired network.
i
If prompted for a password, enter the password
for the home network (caps sensitive).
i
The web-connect device will disconnect
from your smart device at this point.
3
Press and release the WPS button
on the web-connect device. The
symbol.
small yellow LED next to the button
will start blinking slowly.
3
Insert the ethernet cable into the ethernet port
and wrap the cable inside the device and out
of the break-away.
Replace the device cover and gasket and tighten screws.
i Weatherproof the cable break-away by
sealing with silicone.
4
After creating an account, select the [+] in the top right corner (app) or
"Add Location" tab (web). Enter the device serial number found on the
door hanger or the side of the web-connect device.
For security reasons, you must be connected to the same network
as the iQ20 web-connect device to add it to your account.
4
When connection to the home network is established, the
yellow 'LAN' LED stops blinking and turns solid. When
connection to the Internet is established, the green 'WEB'
LED illuminates.
Replace device cover and gasket and tighten screws.
i
See Helpful Hints #1 for more info.
4
When connection to the home network is established, the
yellow 'LAN' LED stops blinking and turns solid. When
connection to the Internet is established, the green 'WEB'
LED illuminates.
Replace device cover and gasket and tighten screws.
i
See Helpful Hints #1 for more info
4
When connection to the home network is established, the
yellow 'LAN' LED stops blinking and turns solid. When
connection to the Internet is established, the green 'WEB'
LED illuminates.
Replace device cover and gasket and tighten screws.
i
See Helpful Hints #1 for more info.
Select your system from the "My Systems" screen (app) or the "Locations" tab
(web) to monitor, program, and control your entire pool system.
i
The web interface is also available from the app. Access it by selecting [Web] from
the top-right corner after selecting your system from the "My Systems" screen.
