Centralized Lubrication Systems
PE-60, 70, 80 Series
Automatic Lubricator
Operation Manual
Thank you for purchasing Trico Corporation centralized lubrication system. For proper operation, please
read the operation manual carefully to avoid incorrect operation and damage.
1 - 25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PE-60 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Trico PE-60 Series

Summary of Contents for Trico PE-60 Series

  • Page 1 Centralized Lubrication Systems PE-60, 70, 80 Series Automatic Lubricator Operation Manual Thank you for purchasing Trico Corporation centralized lubrication system. For proper operation, please read the operation manual carefully to avoid incorrect operation and damage. 1 - 25...

  • Page 2: Table Of Contents

    Contents Safety Information..........................3 Transportation, Delivery and Storage ....................4 Operation............................6 Instruction............................20 Maintenance............................20 Faults ..............................21 Warranty............................22 Remarks............................22 Technical Data ..........................23 2 - 25...

  • Page 3: Safety Information

    0.5 bar above the normal atmospheric pressure in the permissible application temperature range. Unless otherwise noted, products of Trico Corporation must not be used in conjunction with explosive atmospheres according to the ATEX-Directive 94/9/EC.
  • Page 4 only be carried out by qualified experts on products that have been disconnected from the power supply. The supply voltage must be turned off before any product components are open. 1-5 Danger relating to system pressure DANGER! Centralized lubrication systems are under pressure during operation. The system should be depressurized before installation, repair, and maintenance.

  • Page 5: Transportation, Delivery And Storage

    2 . Transportation, Delivery and Storage 2.1 Transportation Our products must be transported with care. Products must be protected against impacts. 2.2 Receipt Inspection The products must be inspected if any damage occurs. Keep the packaging material until the inspector makes sure there is no discrepancy. 2.3 Storage Storage conditions are listed as below, Storage Environment is a dry, dust-free, and well ventilated area...

  • Page 6: Operation

    3. Operation 3.1 Safety Information 3.1.1 Before Installation Ensure the wiring of cables and supplied power is correct before installation Trico Corporation centralized lubrication systems are designed for the mechanism lubrication ONLY. Shutdown 3-1.2 ONLY qualified personnel is authorized to repair Trico Corporation centralized lubrication □...
  • Page 7 3-2 Parts of lubricator (PE-6003) 7 - 25...
  • Page 8 Description Philips screw M4*P0.7*10L Top cover of electronic box O-ring Ø2*Ø129.5 (S130) Wiring(yellow/green)set-CE grounding 130L Philips screw M3*P0.5*10L Philips screw M4*P0.7*10L Terminal plate 8P Philips screw M4*P0.7*6L Fixing plate for terminal plate Pressure gauge 35kg*PT1/8*1.5" (kg/MPa) Philips screw M5*P0.8*12L Spring washer Ø5 Compression bushing Ø4 Compression bushing Ø6 Compression sleeve Ø4...
  • Page 9 Parts of lubricator (PE-7008) 9 - 25...
  • Page 10 Description Philips screw M4*P0.7*10L Top cover of electronic box O-ring Ø2*Ø129.5 (S130) Wiring(yellow/ green)set-CE grounding 130L Philips screw M3*P0.5*10L Philips screw M4*P0.7*10L Terminal plate 8P Philips screw M4*P0.7*6L Fixing plate for terminal plate Pressure gauge 35kg*PT1/8*1.5" (kg/MPa) Philips screw M5*P0.8*12L Compression Bushing Ø4 Compression Bushing Ø6 Compression Sleeve Ø4...
  • Page 11 Parts of lubricator (PE-8008) 11 - 25...
  • Page 12 Description Philips screw M4*P0.7*10L Top cover of electronic box O ring Ø2*Ø129.5 (S130) Wiring(yellow/ green) set-CE grounding 130L Philips screw M3*P0.5*10L Philips screw M4*P0.7*10L Terminal plate 8P Philips screw M4*P0.7*6L Fixing plate for terminal plate Pressure gauge 35kg*PT1/8*1.5" (kg/MPa) Philips screw M5*P0.8*12L Compression busing Ø4 Compression busing Ø6 Compression Sleeve Ø4...
  • Page 13 Danger Label Outside of the electrical Right front side of control box control box top cover Wiring Diagram Operation Notice (PE-60 Series) Inside of the e Left side of the oil tank lectrical control box top cover 13 - 25...
  • Page 14 O p u j d f O p u j d f )G p s !QF.8 1 - !9 1 !T f s j f t * )G p s !QF.7 1 !T f s j f t * S j h i u ! g s p o u ! t j e f ! p g ! d p o u s p m ! c p y S j h i u ! g s p o u ! t j e f ! p g ! d p o u s p m ! c p y Operation Notice (PE-70 Series) Operation Notice (PE-80 Series)
  • Page 15 1. Mount the system on the machine fixing holes 2 by fastening it with two screws (M6) 1 at the upper lid holes 3 2. The distance of machine fixing holes is Y and Z as below listed Remark Model Tank Capacity (Fig. B) PE-60 series 190~205 (Fig. B) PE-60 series 232~284 (Fig. C) PE-60, 70 series (Fig.
  • Page 16 Viscosity higher (lower) than recommended viscosity range may result the burn down (insufficient pressure) of the lubrication systems. Use new lubricant only. 3-4.3 Oil pipe connection (including related parts list) PE-60 series parts list Item Specification Q’ty Ø4 Compression bushing Ø6...
  • Page 17 3-4.4 Installation of power and alarm Note !! The installation of a fuse between the power supply and Trico Corporation centralized lubrication systems is strongly recommended !! Operation Note !! Make sure the power cable is disconnected before the installation.
  • Page 18 (Fig. G) (Fig. H) (Fig I) (Fig. J) (Fig. K) d. Connect the power cable as the wiring diagram (Fig. J), then connect the ground cable. e. The function of float switch is to release the warning message to stop the machine when the lubricant is at the low level.

  • Page 19: Instruction

    Please clean periodically the oil tank of Trico Corporation centralized lubrications. If the user wants to clean the tank, please TURN OFF the system first and remove the bolts on the tank to separate the tank for cleaning.

  • Page 20: Faults

    6 Faults Trico Corporation centralized lubrication systems spare parts are used for Trico ! Only original Corporation centralized lubrication systems. It is prohibited for changing to non-original spare parts. TURN OFF the power before any checking or maintenance Faults / Fault finding...

  • Page 21: Warranty

    7 Warranty Trico Corporation centralized lubrication systems is under the warranty coverage at a period of 12 months. Material and manufacturing faults of is under the Trico Corporation coverage. Below conditions applied Trico Corporation centralized lubrication systems on are beyond...

  • Page 22: Technical Data

    9. Technical data 9-1 Specification Model PE-6003 PE-6004 PE-6006 110V or 220V Voltage (Single Phase) Consumption Power (W) 0.3(Float switch ) Capacity of Terminal Output (A) 5(Pressure switch) Cooperate with PLC control system Lubrication time Cooperate with PLC control system Intermittent Time Ø4 or Ø6 Output Bore...
  • Page 23 Model PE-7006 PE-7008 110V or 220V Voltage (Single Phase) Consumption Power (W) 0.3(Float switch ) Capacity of Terminal Output (A) 5(Pressure switch) Cooperate with PLC control system Lubrication time Cooperate with PLC control system Intermittent Time Ø4 or Ø6 Output Bore Max.
  • Page 24 Model PE-8008 110V or 220V Voltage (Single Phase) Consumption Power (W) 0.3(Float switch ) Capacity of Terminal Output (A) 5(Pressure switch) Cooperate with PLC control system Lubrication time Cooperate with PLC control system Intermittent Time Ø4 or Ø6 Output Bore Max.
  • Page 25 9-2 Diagram 9-3 Flow circuit diagram (PE-60 series) (PE-70, PE-80 series) 25 - 25...
