Dellmeco DME Series Instruction Manual

Electro-mechanical operated double diaphragm pumps
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTION MANUAL
Electro-Mechanical Operated
Double Diaphragm Pumps
(DME Series Pumps)
Ver. 8.4
Ver. 8.1
Models: DME 15 R.., Z..
DME 20 A.., B.., C.., S..
DME 25 A.., B.., C.., H.., R.., S.., Z..
DME 40 A.., B.., C.., H.., R.., S.., Z..
DME 50 A.., B.., C.., H.., R.., S.., Z..
DME 80 A.., B.., H.., R.., S..
(also for DME Pumps with ATEX Certificate)
Date of manufacture:
Serial no.:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DME Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dellmeco DME Series

Summary of Contents for Dellmeco DME Series

  • Page 1 INSTRUCTION MANUAL Electro-Mechanical Operated Double Diaphragm Pumps (DME Series Pumps) Ver. 8.4 Ver. 8.1 Models: DME 15 R.., Z.. DME 20 A.., B.., C.., S.. DME 25 A.., B.., C.., H.., R.., S.., Z.. DME 40 A.., B.., C.., H.., R.., S.., Z..
  • Page 2 Electromagnetic compatibility (EMC) — Part 6-4: Generic standards — Emission standard for industrial environments EN 60204-1:2006 Safety of Machinery — Electrical equipment of machines Part 1: General requirements Date: January 1 2015 K. Ziemann Managing Director 2 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 3: Table Of Contents

    12.4. Appearance and dimensions – DME Hygienic series (AISI 316L) _______________________________________ 44 12.5. Pump code __________________________________________________________________________________ 46 13. Optional equipment for DELLMECO DME Pumps ______________________________________________ 47 13.1. Frequency Inverter (Option code FI) ______________________________________________________________ 47 13.2. Additional Cooling System (Option code ACS) _____________________________________________________ 47 13.3.
  • Page 4 14. Active Pulsation Dampener for DME Series Pumps ______________________________________________ 50 14.1. Main specification ____________________________________________________________________________ 50 14.2. PDEM Plastic Series Pulsation Dampener – exploded view ____________________________________________ 52 14.3. PDEM Aluminium Series Pulsation Dampener – exploded view ________________________________________ 55 14.4. PDEM Industrial (AISI 316) Series Pulsation Dampener – exploded view ________________________________ 58 14.5.

  • Page 5: Introduction

    DELLMECO DME Pumps consist of two pump housings located opposite each other. The diaphragms that separate drive and liquid areas from side housings, include a built-in metal core which ensures an optimum service life of diaphragm.

  • Page 6: Operating Caution And Safety Instruction

    4. Operating caution and safety instruction This chapter is designed for users, fitters and operators of the DELLMECO DME Pump. You will find important safety instructions here to be followed in operating the DME Pump. The safety instructions contained in this chapter are of general nature.
  • Page 7 DME Pump is not originally equipped into a pushbutton switch with differential pressure control. Pushbutton switch must be assembled to the pump or installation obligatorily by a customer. DELLMECO DME Series Pump can be equipped by supplier with such safety device, but only on customer’s request. CAUTION Ø...

  • Page 8: Organizational Measures

    10. Flange connections (option code FE, FEM); 11. Back flushing system (option code BFE); 12. Trolley for pump (option code T); 13. ATEX Certificate. For more information, please refer to Chapter 13 – DELLMECO DME Pumps Optional Equipment. 8 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 9: Safety Instruction To Certain Operation Stages

    Due to a computer-aided design of the pumps, internal pump spaces and valves are shaped so as to achieve a high efficiency. A high value has also been put on easy maintenance and handling. 9I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 10: Names Of Parts And Materials

    5. Names of parts and materials 5.1. DME 15, 25 R.., Z.. Plastic Series Diaphragm Pump – exploded view 10 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 11: Dme 40, 50 R

    5.2. DME 40, 50 R.., Z.. and DME 80 R.. Plastic Series Diaphragm Pump – exploded view 11I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 12 9 40 244 50 9 50 244 50 9 80 244 50 DELLMECO label Diverse 1 15 094 00 1 25 094 00 1 40 094 00 1 50 094 00 1 80 094 00 12 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 13 – set consists of: allen bolts (4 pcs), nuts (4 pcs) and washers (8 pcs); required per 1 pump (10) – set consists of: covered nuts (4 pcs) and washers (4 pcs); required per 1 pump (11) 13I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 14: Dme 20, 25, 40 A

    5.3. DME 20, 25, 40 A.., C.., S.. Metal Series Diaphragm Pump – exploded view 14 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 15: Dme 50 A

    5.4. DME 50 A.., C.., S.. Metal Series Diaphragm Pump – exploded view 15I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 16: Dme 80 A

    5.5. DME 80 A.., B.. Metal Series Diaphragm Pump – exploded view 16 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 17: Dme 80 S

    5.6. DME 80 S.. Metal Series Diaphragm Pump – exploded view 17I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 18 9 80 273 00 Diaphragm shaft hub seal, set Diverse 9 15 373 00 9 25 373 00 9 40 373 00 9 50 373 00 9 80 373 00 9 80 373 00 18 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 19 – set consists of: allen bolts (8 pcs), covered nuts (8 pcs) and washers (8 pcs); required per 1 pump (10) – set consists of: covered nuts (4 pcs) and washers (4 pcs); required per 1 pump (11) 19I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 20: Dme 25, 40, 50 H

    5.7. DME 25, 40, 50 H.. Hygienic Series Diaphragm Pump – exploded view 20 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 21: Dme 65 H

    5.8. DME 65 H.. Hygienic Series Diaphragm Pump – exploded view 21I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 22: Dme 80 H

    5.9. DME 80 H.. Hygienic Series Diaphragm Pump – exploded view 22 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 23 1 15 67 00 1 15 67 00 1 40 67 00 Air hose/Air tube Diverse/Aluminium 1 15 267 00 1 25 267 00 1 40 267 00 1 50 267 60 1 80 267 60 23I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 24 – set consists of: allen bolts (4 pcs), covered nuts (4 pcs) and washers (8 pcs); required per 1 pump – set consists of: covered nuts (4 pcs) and washers (4 pcs); required per 1 pump 24 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 25: Installation And Mounting

    (values calculated for pumping water at 20 degrees Celsius). POSITIVE SUCTION HEAD Common as a method of drawing off the bottoms of holding tanks and clarifiers. Optimum inlet pressure should be kept at 0.2-0.3 bar. 25I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 26 DO NOT install closing and/or throttling valve on the discharge side. Any attempt of closing/throttling the flow while the pump is still working will result in the pump’s damage (diaphragms break). Before start-up of the DME Pump make sure that the suction (inlet) valve is completely opened. 26 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 27: Mounting The Dme Pumps

    In the event that pumping is carried out to a pressure line or against a pressure control valve, an air valve must be installed in the discharge line.  DME Series Pumps are not intended to be working in total or partial submersion. WARNING ...
  • Page 28 “settle”. Fixing all these parts is necessary as well after longer periods of stoppage, at extreme temperature variations, after transport and dismantling the pump. Electro-mechanical Operated Double diaphragm Pumps (DME Series) – torque data Torque value [Nm] Series...

  • Page 29: Connecting The Ground Wire

    2) Connect a hose on the suction-side intake and the discharge-port side to the respective vessels. 3) Check oil level in the crankshaft mechanism via the transparent plug (plug location on the picture below). Required amount of oil for different sizes of DME Series Pumps in the below chart: Estimated...

  • Page 30: Operation

    Before starting the pump, check that all the bolts are securely tightened.  Check that suction valve is completely opened. CAUTION Ø Starting the electrical motor causes running pump run at maximum capacity (depending on the actual frequency rate). 30 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 31: Pump Capacity Regulation

    Keep a vessel below the relief valve for any drain off.  Be careful! - Fluid under pressure will gush out the moment you open the valve.  If the pump is to be unused for a prolonged period, purge and clean it. 31I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 32: Method Of Cleaning

    Make sure that the connection parts of the piping and peripheral equipment are not loose. Make sure that any parts of the pump that are to be replaced at regular intervals have been changed. Make sure that inlet and outlet valves are completely opened. 32 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 33: Possible Problems

    Check and clean the fluid piping. clogged with sludge. The pump is clogged with sludge. Disassemble the casing, check and clean. The balls and valve seats are worn out or damaged. Disassemble the pump, check and replace parts. 33I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 34 Connection parts and pump mounting are loose. Check each connection part and tighten the bolts. If any of the above mentioned causes do not apply to your problem, contact your dealer or our office. 34 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 35: Returning The Product For Servicing

    1) Get an acceptance from your dealer or our office. 2) Clean the pump. 3) Return the product in the same package as when it was first shipped from the factory. 35I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 36 Fluid temperature ______________________ *C/*F Slurry: Suction side diameter _________________ m *YES Density ________________ wt% Discharge side _____________________ m Particulate diameter _____________________ mm Problem Draw a summary drawing of application (size, length of piping, and component parts) 36 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 37: Main Body Specification

    DME Pump. Before the purchase, please request for the dimensional drawing to confirm the DME Series Pump’s compliance with your requirements. Estimated tolerance of the dimensions on the assembled pump is ±3 mm.
  • Page 38 TFM/PTFE FEP-FKM PTFE cond. + EPDM + EPDM FEP-FKM + FEP-FKM DME 80 RE_ EPDM EPDM EPDM + EPDM DME 80 RN_ NBR + NBR DME 80 RT_ TFM/PTFE FEP-FKM FEP-FKM + FEP-FKM 38 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 39 DME Plastic Series Flow Characteristics 39I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 40: Appearance And Dimensions - Dme Metal Series (Aluminium, Cast Iron, Aisi 316)

    12.3. Appearance and dimensions – DME Metal series (Aluminium, Cast iron, AISI 316) DME 20 A.., B.., C.., S.. to DME 80 A.., B.. – main dimensions: DME 80 A.., B.. – main dimensions DME 80 S.. – main dimensions 40 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 41 DME 80 S.. 1266 834 1266 1211 645 675 DME Metal Series Technical Data DELLMECO DME Pump Size - Metal 80 A.., B.. 80 C.. 80 S.. Maximum capacity [l/min] at 50 Hz Maximum entry frequency [Hz] 140% (e.g. max. 70 Hz at 50 Hz power-line frequency) Electric motor power [kW] 0.75...
  • Page 42 EPDM + EPDM DME 80 SE_ EPDM EPDM DME 80 AN_, DME 80 BN_ NBR + NBR DME 80 SN_ DME 80 AT_, DME 80 BT_ TFM/PTFE EPDM + EPDM DME 80 ST_ TFM/PTFE PTFE 42 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 43 DME Metal Series Flow Characteristics 43I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 44: Appearance And Dimensions - Dme Hygienic Series (Aisi 316L)

    Material of pump housing AISI 316L Diaphragm options NBR, EPDM, TFM, TFM/PFA NBR, EPDM, TFM Valve balls NBR, EPDM, PTFE, AISI 316 NBR, EPDM, PTFE Clamp seals (DIN 32676) Silicone, PTFE, EPDM ,NBR 44 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 45 DME Hygienic Series Flow Characteristics 45I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 46: Pump Code

    P - PE, cylinder valve (Plastic Pump Series only) ATEX – Explosion-proof certificate (not available for DME Pumps with BS Option) C - Ceramic, ball valve *- drive unit consists of three components: gearmotor, coupling jaw and pump drive stand 46 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 47: Optional Equipment For Dellmeco Dme Pumps

    Additional information to the operating and installation instructions ought to be studied before installing the pump For special requirements DELLMECO DME Pumps of the Plastic and Metal Series can be furnished with several optional equipment. The pump code informs, which of these are included in the pump.

  • Page 48: Pushbutton Switch For Differential Pressure Control (Option Code Pbs1, Pbs2)

    13.8. Diaphragm Monitoring (Option code DM) Although DELLMECO DME diaphragm pumps with integrated metal core are designed for an optimum service life, the diaphragm remains a wear part. If it breaks, liquid can leak into the center housing and possibly penetrate the pump causing pump irregular work, or even its damage.

  • Page 49: Back Flushing System (Option Code Bfe1, Bfe2, Bfe3)

    13.13. Bare-Shaft (Option code BS) DME Series Pump with Bare-Shaft (BS) option means the pump is supplied without the drive unit (i.e., no electric motor, coupling jaw and gearbox) – please refer to the below picture of Plastic DME 15 R..-BS Pump: In this case the drive unit has to be assembled by the customer in accordance with DELLMECO guidelines and local safety regulations.

  • Page 50: Active Pulsation Dampener For Dme Series Pumps

    14. Active Pulsation Dampener for DME Series Pumps 14.1. Main specification DELLMECO DME Active Pulsation Dampeners are specially designed to be used along with DELLMECO Electro- Mechanical Operated Double Diaphragm Pumps of all Plastic, Metal and Hygienic range. A general aspect to be considered is that a pulsation dampener decreases the total capacity of the system depending on the point of operation.
  • Page 51 Before putting the pump and the dampener back into operation, the tightness of both (i.e. housing bolts) has to be checked.  DME Series Pump with installed PDEM Pulsation Dampener obligatorily has to be equipped with safety device (Push-Button Switch or Pressure Relief Valve). For more information, please refer to Chapter 4 (page 6).

  • Page 52: Pdem Plastic Series Pulsation Dampener - Exploded View

    14.2. PDEM Plastic Series Pulsation Dampener – exploded view 52 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 53 2 40 78 08 2 80 78 08 8/ 12**/ Housing bolt plug 8 10 058 20 8 25 058 20** 8 40 058 20** 8 50 058 20*** 8 80 058 20*** 16*** 53I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 54 Housing material (in contact with medium): PE conductive (PDEM xx R..), PTFE conductive (PDEM xx Z..) Diaphragm material available: EPDM, NBR, TFM/PTFE, TFM/PTFE/PFA ATEX compliance: EEx II 2GD IIB Tx (“Tx” – depends on the gearmotor’s ATEX properties) 54 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 55: Pdem Aluminium Series Pulsation Dampener - Exploded View

    14.3. PDEM Aluminium Series Pulsation Dampener – exploded view 55I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 56 2 40 78 08 2 80 78 08 8/ 12**/ Housing bolt plug 8 10 058 20 8 25 058 20** 8 40 058 20** 8 50 058 20*** 8 80 058 20*** 16*** 56 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 57 Diaphragm material available: EPDM, NBR, TFM/PTFE, TFM/PTFE/PFA DME Cast Iron Pumps have to be equipped with PDEM xx S.. (AISI 316 version) units ATEX compliance: EEx II 2GD IIB Tx (“Tx” – depends on the gearmotor’s ATEX properties) 57I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 58: Pdem Industrial (Aisi 316) Series Pulsation Dampener - Exploded View

    14.4. PDEM Industrial (AISI 316) Series Pulsation Dampener – exploded view 58 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 59 8 80 058 20*** 8*** 4/ 6** / Nut (DIN 1587) AISI 304 1 25 145 50 1 25 145 50** 1 40 145 50** 1 50 145 50*** 1 80 145 50*** 8*** with washer, cpl 59I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 60 Diaphragm material available: EPDM, NBR, TFM/PTFE DME Cast Iron Pumps have to be equipped with PDEM xx S.. (AISI 316 version) units ATEX compliance: EEx II 2GD IIB Tx (“Tx” – depends on the gearmotor’s ATEX properties) 60 I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 61: Pdem Hygienic (Aisi 316L) Series Pulsation Dampener - Exploded View

    14.5. PDEM Hygienic (AISI 316L) Series Pulsation Dampener – exploded view 61I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 62 8*** 4/ 6** / Nut (DIN 1587) AISI 304 1 25 145 50 1 25 145 50** 1 40 145 50** 1 50 145 50*** 1 80 145 50*** 8*** with washer, cpl 62 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 63 ATEX compliance: EEx II 2GD IIB Tx (“Tx” – depends on the gearmotor’s ATEX properties) Standard in-/outlet connection is in accordance with DIN 11851 Tri-Clamp connection (option) in accordance with DIN 32676 SMS (thread male) connection (option) in accordance with SMS 1145 standard 63I DELLMECO I EODD DIAPHRAGM PUMPS...

  • Page 64: Limited Warranty

    Parts for this product will be kept available for 5 years after discontinuation of production. Once 5 years have elapsed after close of production, availability of parts for this product cannot be guaranteed. 64 I DELLMECO I EODD DIAPHRAGM PUMPS...
  • Page 65 Notes:...
