- Page 1 User manual HYPRO WATER This product may be covered by one or more of the following EN | 09.2020 U.S. patents: US10,377,644 B2.
- Page 2 Information with the word CAUTION warns of a situation that can lead to minor or moderate injuries. D ATTENTION! Information with the word ATTENTION warns of a situation that can lead to damage to property or the environment. HYPRO WATER – 09.2020...
-
Page 3: Table Of Contents
Disposal..... 30 Disposing of the packaging . . . 30 Disposing of used filters..30 Disposing of the device ..30 HYPRO WATER – 09.2020... -
Page 4: Safety Information
– After reading and observing this user and maintenance without supervision. manual. – In technically faultless, unmodified condition. – When using new original accessories. – After correct assembly and checking. – In enclosed spaces. All other uses are deemed non-intended use. HYPRO WATER – 09.2020... -
Page 5: General Safety Information
Only check the function of the UV LEDs indirectly via the status LEDs on the device and the HYPRO app. The device’s components (such as UV LEDs or batteries) must be replaced only by the manufacturer. HYPRO WATER – 09.2020... - Page 6 – With a failure to observe this user manual. – With non-intended use. – With incorrect handling. – When using third-party accessories. Made in Germany. System and installation comply with state and local laws and regulations. HYPRO WATER – 09.2020...
-
Page 7: Product Information
– Per- and polyfluoroalkyl substances (e.g. PFOA and PFOS) – Odorants and flavourings “Dynamic Twist Technology” With the HYPRO WATER “Dynamic Twist A Device cover Technology”, the UV light has a flow- B Pressure point on the device cover optimised effect on the tap water. The C Screw cap for the filter chamber water is optimally disinfected in this way. - Page 8 H Type plate The device is connected with the Mains cable with plug WLAN. Thread for mounting on the wall bracket LED lights up or flashes red: K Water inlet Fault or filter change. Water outlet HYPRO WATER – 09.2020...
-
Page 9: Scope Of Supply
A HYPRO WATER device Scope of supply B Filter C Wall bracket 2.3 / 1 D Angled piece (5/16") Angled piece (3/ 8 ") Reducer piece G Connection piece (water tap 5/16") H Connection piece (water tap 3/ 8 ") Water inlet hose (5/16") -
Page 10: Technical Data
Weight with water 5.5 kg using the app: – Water consumption Filter capacity 2000 l – Device status Filter change 4 months – Filter status – Error messages WLAN WLAN 802.11 b/g/n Varies depending on the type of filter used. HYPRO WATER – 09.2020... -
Page 11: Assembly
Observe the documentation for your – If the device is used with the HYPRO water tap. app: A WLAN connection to the Documentation for the water tap. internet must be available at the installation site. HYPRO WATER – 09.2020... -
Page 12: Unpacking The Device
Remove the packaging material. ➡ “9.1 Disposing of the packaging” (page 30). As a result of the manufacturer’s quality inspection, the device may contain residual moisture, which may escape. This residual moisture does not reduce quality or functionality. HYPRO WATER – 09.2020... -
Page 13: Performing Assembly
– With connection to a 3-way water tap. – With assembly beneath the worktop. 3.4 / 1 Assemble all of the required tools and materials: – Bucket – Cutter knife – Pen – Spirit level – Screwdriver – Pipe wrench 20 cm 10 cm HYPRO WATER – 09.2020... - Page 14 Make sure that the T-piece valve is closed. Remove the bucket. Position a bucket beneath the angle valve on the cold water line. Unscrew the cold water connection to the water tap from the angle valve. HYPRO WATER – 09.2020...
- Page 15 Mark the four fastening points. The screws included in the scope of delivery are intended for mounting on Screw the wall bracket on with the four chipboard. small screws. When mounting on a wall, suitable fasteners must be selected. HYPRO WATER – 09.2020...
- Page 16 (5/16") as far as it will go. (3/ 8 ") as far as it will go. Secure the hose (5/16”) with the safety Secure the hose (3/ 8 ”) with the safety clip (5/16"). clip (3/ 8 "). HYPRO WATER – 09.2020...
- Page 17 Position the device on the wall bracket. 3.4 / 14 3.4 / 12 Screw the connection piece (water tap) onto the drinking water tap. Screw the knurled screw from below through the wall bracket into the device. HYPRO WATER – 09.2020...
- Page 18 Make sure the hoses are cut straight. Insert the hose (3/ 8 ") in the connector (water tap) as far as it will go. Secure the hose (3/ 8 ”) with the safety clip (3/ 8 "). HYPRO WATER – 09.2020...
- Page 19 3.4 / 21 3.4 / 19 Remove the protective film from the filter. Turn the shut-off valve in the “CLOSE” Insert the filter. direction. During insertion, carefully press the filter down until it latches into the device. HYPRO WATER – 09.2020...
-
Page 20: Completing Assembly
HYPRO app. When the device is connected to the WLAN, the LED continuously glows yellow. To search again: Unplug the mains plug and plug it in again. Wait until the LED lights up yellow. HYPRO WATER – 09.2020... - Page 21 3.5 / 2 3.5 / 4 Open the shut-off valve for the T-piece. Close the device cover. Open the angle valve on the cold water line. 3.5 / 3 Turn the shut-off valve in the “OPEN” direction. HYPRO WATER – 09.2020...
- Page 22 The particles will not affect your health. Open the drinking water tap and allow the water to run for approx. 60 seconds. Allow the drinking water to flow until particle emission has subsided, although for a minimum of 60 seconds. HYPRO WATER – 09.2020...
-
Page 23: Use
The LED flashes yellow: The device is ready for WLAN connection. LED lights up yellow continuously: The device is connected with the WLAN. LED lights up or flashes red: Fault or filter change. ➡ “7. Trouble-shooting” (page 27). HYPRO WATER – 09.2020... -
Page 24: Cleaning
Cleaning Information on cleaning: Clean the device surfaces with a non- linting, lightly dampened cloth. Wipe the device surfaces dry with a non-linting, dry cloth. HYPRO WATER – 09.2020... -
Page 25: Maintenance
Water can escape when the screw cap is opened and the filter is removed. The escaping water can cause material damage. Wipe up and collect any escaped water immediately. Unscrew the screw cap for the filter chamber. ➡ “3.4 / 20” (page 19). HYPRO WATER – 09.2020... -
Page 26: Checks
Fit the device cover. ➡ “3.5 / 4” (page 21). Turn on the drinking water faucet and let the water run for at least 60 seconds, until no more particles are coming out. ➡ “3.5 / 5” (page 22). HYPRO WATER – 09.2020... -
Page 27: Trouble-Shooting
Use the HYPRO app to get further carried out correctly, in accordance with details. the user manual. Contact customer service. Check that the water connections and drinking water tap are open. Check that the mains plug is plugged HYPRO WATER – 09.2020... - Page 28 – Screw-on cover to the filter chamber not closed properly. Make sure the screw-on cover to the filter chamber is screwed to the stop. If the fault persists: Close the angle valve on the cold water line. Contact your installation engineer. HYPRO WATER – 09.2020...
-
Page 29: Disassembly
Close the drinking water tap. Draw out the reducer piece. Unscrew the connection piece (water tap) from the drinking water tap. Unscrew the knurled screw below the wall bracket. Remove the device. Disassemble the wall bracket. HYPRO WATER – 09.2020... -
Page 30: Disposal
Disposing of used filters Spent adsorption media will not be regenerated and used. Dispose of used filters with residual waste. HYPRO WATER – 09.2020... -
Page 31: 10. Annex
Class B systems are not intended for treatment of contaminated water. Refer to the NSF performance data for details on which individual contaminants to remove. ➡ “10.7 NSF performance data” (page 36). HYPRO WATER – 09.2020... -
Page 32: Fcc/Ised Notes
– Connect the equipment into an outlet This equipment should be installed and on a circuit different from that to which operated with minimum distance 20 cm the receiver is connected. between the radiator and your body. HYPRO WATER – 09.2020... - Page 33 Cet équipement est conforme aux limites d'exposition aux rayonnements RSS-102 établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps. HYPRO WATER – 09.2020...
-
Page 34: List Of Replacement Parts
Replacement parts can be ordered from customer service. ➡ “10.1 Contact details for customer service” (page 31). Replacement part Item No. Illustration Wall bracket 1000014 Hose set 1001 Device cover 1000012 Screw cap for the filter 1000032 chamber Filter 1000035 HYPRO WATER – 09.2020... -
Page 35: Ce Declaration Of Conformity
10.6 CE declaration of conformity HYPRO WATER – 09.2020... -
Page 36: 10.7 Nsf Performance Data
10.7 NSF performance data HYPRO WATER – 09.2020... - Page 37 HYPRO WATER – 09.2020...
- Page 38 HYPRO WATER – 09.2020...
- Page 39 HYPRO WATER – 09.2020...
- Page 40 09.2020...
