Before Voyage
Set Voyage Related Parameters
Voyage related parameters, are set from the AIS Voyage Settings view accessed
by pressing the MODE key followed by function keys PLAN VOYAGE and
then AIS VOYAGE.
Change Ship/Convoy Dimensions - Length and beam
To set ship/convoy length and beam, go to the Ship Static Configuration
view by pressing the
and then
Config
Ship Static
parameters. Convoy dimensions are set as parameters Length and Beam.
Change Ship/Convoy Dimensions - GNSS antenna parameters
Ship/Convoy dimensions derived from the GNSS antenna parameters must be
equal to length and beam (rounded upwards).
Go to the GNSS Antenna, Internal GNSS view by pressing the MODE key
followed by function keys CONFIG, AIS Config and then GNSS Antennas.
Use the ARROW KEYPAD to step in the list of parameters. All lengths are
referenced to the position of the GPS antenna.
During Voyage
Set Navigational Status
In order to set Navigational Status, press the STATUS key.
Two sets of function keys for different navigational status are available by
toggling with the PAGE key.
Press the function key corresponding to the navigational status that is to be used.
Press the ESC key in order to leave the Navigational Status view.
View own ship data
To view current transmitted information about the own ship, press the MODE
key followed by function keys NAVIGATE and then Own Ship Data.
Three different sub views are available by toggling with function key Show
Next. If you want to leave the menu press the ESC key.
View List and Plot of AIS Targets
To view a list of received AIS targets, press the MODE key followed by
function keys NAVIGATE and then Target List.
To view information about a specific target, highlight it in the list using the
ARROW KEYPAD and press function key Extended Info. Three different
subviews are available by toggling with function key Show Next.
It is also possible to view a plot of received AIS targets with respect to the own
ship position by pressing the MODE key followed by function keys
NAVIGATE and then Plot. The plot can be zoomed with function keys Zoom
In and Zoom Out. Use the ARROW KEYPAD to step between the targets in the
plot and display information related to the selected target.
key followed by function keys
MODE
.
Use the ARROW KEYPAD to step in the list of
7000 108-311 B
