- Page 1 Shenzhen BIGTREE technology co., LTD. BIG TREE TECH BIGTREETECH SKR MINI E3 V1.2 User’s manual...
- Page 2 Shenzhen BIGTREE technology co., LTD. BIG TREE TECH Product Introduction BTT SKR MINI E3 V1.2 motherboard is a ultra-quiet, low-power, high-quality 3D printing machine control board. It is launched by the 3D printing team of Shenzhen BIGTREE technology co., LTD. This board is specially tailored for Ender 3 printer, perfectly replacing the original Ender3 printer motherboard.
- Page 3 Shenzhen BIGTREE technology co., LTD. BIG TREE TECH Installation size： This motherboard perfectly replaces the original Ender 3 motherboard, please refer to BTT SKR MINI E3 V1.2 SIZE for details Microprocessor： ARM Cortex-M3 CPU Power Voltage：12/24V Motor Driver：Integration of TMC2209 UART mode Motor drive interface：XM、YM、ZM、EM...
- Page 4 Shenzhen BIGTREE technology co., LTD. BIG TREE TECH Interface Instruction 1. Motherboard Size Diagram 2. Motherboard Wiring Diagram...
- Page 5 Insert SD card into the main board SD card slot, re-energize or press the reset key, wait for about 10S. After that, the update can be completed. For DIY motherboard firmware, please refer to BTT SKR MINI E3 V1.2 PIN data; Notes： ...
- Page 6 BTT SKR MINI E3 V1.2 is a motherboard designed specifically for the Ender 3 printer. If the user wants to use another machine, please refer to the corresponding electrical parameters of Ender3 (such as hot bed power, heating rod power, etc.).
