INSTALLATION INSTRUCTIONS (optional)

Exhaust hose installation:

The exhaust hose and adaptor must be installed or removed
in accordance with the usage mode.
Fig.18 Fig.19
1. Install the window Exhaust adaptor B onto the exhaust
Fig.20
2. Push the Exhaust hose into the air outlet opening along
The exhaust hose can be installed into the wall
(Not applicable to the units without adaptor A, expansion
Fig.20
plugs and wooden screws of accessories).
1. Prepare a hole in the wall. Install the wall Exhaust adaptor A
Adaptor cap
Note:
Cover the hole using the adaptor cap when not in use.
max 120 cm
IMPORTANT:
min
DO NOT OVER BEND THE DUCT (SEE Fig.22)
30 cm
Fig.21
Make sure that there is no obstacle around the air outlet of
the exhaust hose (in the range of 500mm) in order to the
exhaust system works properly.
Fig.22
COOL, AUTO mode
FAN,DEHUMIDIIFY mode
hose as shown in Fig.18. or Fig.19. Refer to the previous
pages for window kit installation.
the arrow direction (See Fig.20).
onto the wall (outside) by using 4 expansion plugs and
wooden screws, be sure to fix thoroughly. (See Fig.21) to
wall Exhaust adaptor A.
The duct can be compressed or extended moderately
according to the installation requirement, but it is desirable
to keep the duct length to a minimum.
CAUTION:
12
Install it
Remove
it
Drain hose
INSTALLATION INSTRUCTIONS

Water drainage:

During dehumidifying modes, remove the drain
Remove the
plug from the back of the unit, install the drain
drain plug
connector (5/8 universal female mender) with 3
4 hose(locally purchased). For the models
without drain connector, just attach the drain
hose to the hole. Place the open end of the hose
Fig.23
directly over the drain area in your basement
floor. Please refer to Fig.23 & 24.
- When the water level of the bottom tray reaches
a predetermined level, the unit beeps 8 times,
the digital display area shows "P1". At this time
the air conditioning/dehumidification process will
immediately stop. However, the fan motor will
continue to operate (this is normal).
Carefully move the unit to a drain location,
remove the bottom drain plug and let the water
drain away (Fig.25). Re-install the bottom drain
plug and Restart the machine until the "P1"
symbol disappears. If the error repeats, call for
-
Fig.24
service.
NOTE: Be sure to reinstall the bottom drain plug
before using the unit.
Fig.25
