- Page 1 2 Plus Battery charger Battery charger User manual Model Part No.: 1250527 Date: 09/25/2020 Version: v.1.01...
- Page 2 Original user manual, written in the English Language T T ennant Company 10400 Clean Street, Eden Prairie, MN 55344-2650 Telephone: (800) 553-8033 Internet: www.tennantco.com Model: i-charge 2 Plus Product code: 1250527...
-
Page 3: Preface
Become familiar with the correct operation and maintenance procedures. Store the manual in a safe place. The manual is an essential part of the i-charge 2 Plus and must be handed over to the new owner upon resale or exchange. Each i-charge 2 Plus has a unique serial number that can be found on the bottom of the body. -
Page 4: Reading Guide
Reading guide The following symbols and terms are used throughout this manual to alert the reader to safety issues and important information: S S ymbol T T erm E E xplanation W ARNING Indicates a hazardous situation which, if the safety instructions are not followed, can lead to injuries of the operator or bystanders, light and/or moderate damage to the product or the environment. -
Page 5: Table Of Contents
Content Preface..........................................3 Purpose of the user manual ..................................3 Target audience ........................................ 3 Operators of the i-charge 2 Plus ................................. 3 Reading guide ........................................4 Introduction ......................................6 Intended use of the product ..............................6 Non-intended use of the product ............................6 Modifications .................................... -
Page 6: Introduction
Non-intended use can have consequences for the safety of operators and bystanders and will void the warranty on the product. The i-charge 2 Plus is not intended for use outdoors or in a wet or closed environment. Do not charge non-original batteries or non-rechargeable batteries with the i-charge 2 Plus. -
Page 7: Specifications
1.4 Specifications Figure 1 Product size: 265 x 214 x 110 mm | 10.4" x 8.4" x 4.3" Weight: 1.2 kg | 2.6 lbs Battery capacity: 2 batteries Power supply: 100-240 V, 1A max 50/60 Hz per side Fuse 6.3 A / 300 ms Output voltage: DC 29.4 V per side Charge current:... -
Page 8: Warranty
2 Plus and may cause a risk to the operator. The use of alternative supplies voids manufacturer's warranty. 1.6 Identification Each i-charge 2 Plus has a unique serial number that can be found on the bottom of the body. Your i-team partner may need this number. Explanation type plate: Item number: S.72.0299.XXX... -
Page 9: Description
2 Description The compact i-charge® 2 Plus is designed to charge 2 batteries in parallel. The i-charge 2 Plus consists of: Figure 3 Legend The battery charge displays. The power cable. The main body. The ON/OFF switch. -
Page 10: Battery Charge Displays
2.1 Battery charge displays 1. When the batteries are charged, the number of colored bars will go up from one bar that blinks (which indicates that the batteries are almost empty) to three bars that burn continuously (which indicates that the batteries are full and ready to use). -
Page 11: Safety
3 Safety Safety comes first, therefore please take time to read and understand these safety instructions. Improper use can cause harm or void the manufacturer’s warranty. 3.1 General Safety Instructions WARNING D D O O NOT operate the i-charge® 2 Plus with wet or moist hands. 3.1.1 Batteries CAUTION During normal operation the 24 V batteries cause no safety hazard on their own. -
Page 12: Risks During Operation
2 Plus during usage; ensure that the main voltage is identical to that mentioned on the identification plate on the i-charge 2 Plus; only use the i-charge 2 Plus in an environment that is well ventilated and has a good heat dissipation. -
Page 13: Transport And Storage
4 Transport and storage CAUTION The storage environment should not contain corrosive gasses. There should be no magnetic fields. Vibrations should be avoided. -
Page 14: Assembly And Installation
5 Assembly and installation 5.1 Unboxing The i-charge® 2 Plus is packed in 1 box. Figure 5 Legend 1x power cable 1x i-charge 2 Plus battery charger 1x this user manual... -
Page 15: Assembly
5.2 Assembly Connect the power cable (Figure 6, pos 1) to the connector at the back side of the i- charge 2 Plus. Figure 6... -
Page 16: Operation
6 Operation 6.1 Before you start check the i-charge® 2 Plus for damage; check the battery for damage. 6.2 Operation 1. Plug the main power cable into the wall socket (Figure 7, pos 1). 2. Align each battery with the charging dock (Figure 7, pos 2) and insert each battery, until you hear a "click". -
Page 17: After Operation
2 Plus to reset. 6.3 Cleaning and storage 6.3.1 Cleaning It is recommended to clean the i-charge 2 Plus with a damp cloth every once in a while. 6.3.2 Storage store the i-charge 2 Plus in a dry environment;... -
Page 18: Maintenance
7 Maintenance Maintenance and repairs should only been done by manufacturer authorized personnel. -
Page 19: Troubleshooting
N N o display Bring the i-charge® 2 Plus to your i- team partner. B B attery not Potentially faulty battery Try with other battery first, if that one w w orking after full works, call your i-team partner. r r echarge... -
Page 20: Decommissioning And Disposal
It is the responsibility of the i-charge® 2 Plus owner to dispose of the product. At the end-of-life the i-charge 2 Plus still contains volatile materials and must be disposed of according to your local laws and regulations regarding recycling of electrical equipment.
