Summary of Contents for Supermicro AOC-M25G-i2S
- Page 1 AOC-M25G-i2S AOC-M25G-i2SM User's Guide Revision 1.0a...
- Page 2 CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”. The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
- Page 3 Supermicro® Asset Management and thermal detection give the extra layer of controller health management and peace of mind. For customers who require faster and more reliable networking demands, the AOC-M25G-i2S/i2SM is an excellent choice to enhance network connectivity in data centers and enterprise environments.
- Page 4 Super AOC-M25G-i2S(M) Add-on Card User's Guide Conventions Used in the User's Guide Pay special attention to the following symbols for proper system installation and for safety instructions to prevent damage to the system or injury to yourself: Warning: Important information given to ensure proper system installation or to prevent damage to the components or injury to yourself.
- Page 5 Preface...
- Page 6 Super AOC-M25G-i2S(M) Add-on Card User's Guide Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
-
Page 7: Table Of Contents
Preface Table of Contents Preface Chapter 1 Overview Overview ......................1-1 Key Features ....................1-1 Technical Specifications .................. 1-2 Available SKUs ....................1-5 Optional Parts List ................... 1-5 Chapter 2 Hardware Components Add-On Card Image and Layout ..............2-1 Major Components ..................2-3 SFP28 Ethernet Connections................ -
Page 8: Chapter 1 Overview
Overview Congratulations on purchasing your add-on card from an acknowledged leader in the industry. Supermicro products are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. For product support and updates, please refer to our website at http://www.supermicro.com/ products/nfo/networking.cfm#adapter. -
Page 9: Technical Specifications
Super AOC-M25G-i2S(M) Add-on Card User's Guide 1-3 Technical Specifications General • Super I/O Module (SIOM) Form Factor • Intel XXV710 25GbE controller ® • Dual SFP28 connectors with speed up to 25Gbps per port • Time Sync (IEEE1588) I/O Features •... - Page 10 Chapter 1: Overview • NC-SI for remote management Advanced Software Features • Teaming support • IEEE 802.3ad (link aggregation control protocol) • IEEE 802.1Q VLANs • IEEE 802.3 2005 flow control support • IEEE 802.1p • Receive Side Scaling Operation System Support • Windows Server 2008 R2 / 2012 / 2012 R2 / 2016 •...
- Page 11 Super AOC-M25G-i2S(M) Add-on Card User's Guide • Storage temperature: -40°C to 70°C (-40°F to 158°F) • Storage humidity: 90% non-condensing relative humidity at 35ºC Physical Dimensions • Card PCB dimensions: 92mm (3.62in) x 87.1mm (3.43in) (W x D) Supported Platforms • Supermicro motherboards with Super I/O Module slot built-in ®...
-
Page 12: Available Skus
Chapter 1: Overview Available SKUs SKUs Bracket Included Description AOC-M25G-i2S BKT-0144L 2-port 25 Gigabit Ethernet Adapter with a swappable bracket for 2U+ chassis (Storage Servers) AOC-M25G-i2SM BKT-0143L 2-port 25 Gigabit Ethernet Adapter with an internal bracket for 1U chassis (Twin... -
Page 13: Chapter 2 Hardware Components
Chapter 2: Hardware Components Chapter 2 Hardware Components Add-On Card Image and Layout AOC-M25G-i2S(M) View... - Page 14 Super AOC-M25G-i2S(M) Add-on Card User's Guide LED3 SFP2 SFP1 JZSFP1 AOC-M25G-i2S(M) DESIGNED IN USA REV:1.01 AOC-M25G-i2S(M) Layout...
-
Page 15: Major Components
Chapter 2: Hardware Components Major Components The following components are on the AOC-M25G-i2S(M): AOC-M25G-i2S(M) Major Components Component Name Definition PCIE 3.0 x16 Intel XXV710 25GbE Ethernet controller ® Connector Cage Connector Cage SFP1 SFP28 Port1 SFP2 SFP28 Port2 LED1 Port 1 LED Indicators... -
Page 16: Sfp28 Ethernet Connections
Super AOC-M25G-i2S(M) Add-on Card User's Guide SFP28 Ethernet Connections SFP28 (SFP1/SFP2) Connectors Two small form-factor pluggable (SFP28) optical transceiver connectors (SFP1 and SFP2) are located on the add-on card. These SFP28 ports provide Ethernet connections of up to 25GbE. See the layout next page for the locations. - Page 17 LED1 SFP28 Port 1 Active Amber 10 Gbps LED2 SFP28 Port 2 Active Green 25 Gbps Green SFP28 LAN Port Active SFP28 Port LED Indicator 1 SFP28 Port LED Indicator 2 LED3 SFP2 SFP1 JZSFP1 AOC-M25G-i2S(M) DESIGNED IN USA REV:1.01...
-
Page 18: Chapter 3 Installation
Chapter 3: Installation Chapter 3 Installation Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam- aging your add-on card, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. Precautions •... -
Page 19: Before Installation
Super AOC-M25G-i2S(M) Add-on Card User's Guide Before Installation Before you install the add-on card, follow the instructions below. 1. Power down the system. 2. Unplug the power cord. 3. Use industry-standard anti-static equipment such as gloves or a wrist strap and follow the precautions on previous page to avoid damage caused by ESD. -
Page 20: Installing The Add-On Card
Chapter 3: Installation Installing the Add-on Card Follow the steps below to install the add-on card into your system. 1. Remove the server cover, if any, and set aside any screws for later use. 2. Remove the add-on card slot cover. If the slot cover has a screw, place it aside for later use. - Page 21 Super AOC-M25G-i2S(M) Add-on Card User's Guide Follow the steps below to install the add-on card into your system that supports a swappable bracket. The add-on card must be installed in the swappable bracket before it can be installed in the your system.
- Page 22 Chapter 3: Installation Follow this step to install the add-on card if your system does not support a swap- pable bracket. Insert the SIOM card in the motherboard and then install the mother- board in the chassis. An internal bracket comes with the AOC-M25G-i2SM controller which needs to be installed into the chassis before the motherboard is inserted.
-
Page 23: Installing Windows Drivers (For Intel Fortville-25 Xxv710)
Intel Download Center or from the Supermicro FTP site at ftp://ftp.supermicro.com/ Networking_Drivers/. 1. Run the CDR-NIC. 2. When the SUPERMICRO window appears, click on the computer icon next to the product model. Note: If the FOUND NEW HARDWARE WIZARD screen displays on your system, click CANCEL. -
Page 24: Installing Linux Drivers (For Intel Fortville-25 Xxv710)
Chapter 3: Installation Installing Linux Drivers (for Intel Fortville-25 XXV710) ® Follow the steps below to install the driver to a Linux system. 1. Build a binary RPM package by running this command: rpmbuild -tb <filename.tar.gz> 2. Be sure to replace <filename.tar.gz> in the above step (#1) with the spe- cific filename of the driver. - Page 25 Super AOC-M25G-i2S(M) Add-on Card User's Guide insmod /lib/modules/[KERNEL_VERSION]/kernel/drivers/ net/ethernet/intel/i40e.[k]o In addition, when using 2.6-based kernels, make sure that older i40e drivers are removed from the kernel before loading the new module. To do this, use: rmmod i40e; modprobe i40e 8. Assign an IP address to the interface by entering the following command where "x"...
-
Page 26: Configuring Efi Mode From System Setup
Chapter 3: Installation 3-6 Configuring EFI Mode from System Setup During the host boot process, EFI mode configuration can be modified through BIOS setup. 1. From the top of the tool bar, select Advanced to enter the submenu. Choose PCIe/PCI/PnP Configuration and press <Enter> to see the contents of PCI devices settings. - Page 27 Super AOC-M25G-i2S(M) Add-on Card User's Guide 3. To see the available boot options of the UEFI Network Drive, select Boot to enter the submenu. When the following screen appears, use the arrow keys to select UEFI NETWORK Drive BBS Priorities and press <Enter>.
- Page 28 Chapter 3: Installation 5. After the system configuration is completed, select Save Changes and Reset from the Save & Exit menu and press <Enter> to save the changes made. Note: All screenshots shown are for illustration purpose only and may not match the screens that you see on your system.
- Page 29 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
