Summary of Contents for Altec Lansing IMT7012
- Page 2 IMT7012 EMERGENCY WIRELESS SPEAKER Adapter Quick Start Guide AUX. Audio cable USB-A to USB-C charging cable...
-
Page 3: General Functions
GENERAL FUNCTIONS • Bluetooth • 3.5mm AUX IN audio port • Speakerphone with integrated hands-free microphone • AM/ FM/ SW Radio with 5 presets per band • WB Radio with NOAA/NWS bands • Specific Area Message Encoding (SAME) alerts (for local area) •... - Page 4 FEATURES/CONTROLS 1. Flashlight 2. Flashlight button: Press brie y to ash light. Press and hold for 5 seconds to keep the light on 3. SOS button: Flashlight sends S-O-S message in Morse Code 4. Hazard button: Hazard indicators (front and back) ash on and o 5.
-
Page 5: Control Panel
CONTROL PANEL /AUX 1. Local Weather and Area Alert button/LED Press: Review alerts Press and hold: Alert Function On/O Green: Alerts Enabled Yellow: ‘Advisory’ Level Alert Received Orange: ‘Watch’ Level Alert Received Red: ‘Warning’ Level Alert Received 2. Power button Press: Standby/On Press and hold: Full O 3. -
Page 6: Menu Operation
MENU OPERATION Press MENU to access top level menus. MENU Repeatedly press the button or use the buttons at the top level to change to next available menu. Press SELECT to enter that menu. Press |< >| buttons to move forward/back selecting items to be changed. Press buttons to change the parameters of the selected item. - Page 7 MENU OPERATION (CONT.) Setting the Time 1. Press the Menu button until SET TIME appears on the display. Pressing Menu will move to the next menu, pressing + or – will also move back and forward to the next menu. 2.
- Page 8 SET WEATHER CHANNEL 1. Press the Menu button until appears on the display. 2. Press SELECT or >| to enter the menu, then press the + and - buttons to nd the desired weather channel (frequency). 3. Press SELECT or >| to save the channel and exit the menus . NOTE: When you exit this menu option, the Radio Alert function will automatically turn On.
- Page 9 Choosing Alert Display (How an Alert is displayed or presented) 1. Press the Menu button until ALERT DISPLAY appears on the display . 2. Press the Select or >| button to enter the menu . 3. Press the + and – buttons to toggle through the following 4 options, then press SELECT. 4.
- Page 10 ALL - Enables all alerts including test alerts DEFAULT - Enables all alerts except some advisory level test alerts MAJOR - Enables a xed list of all important alerts (see page 11). USER - Allows the user to set their preference. Various major alerts cannot be disabled as these are crucial to the operation of the NOAA/SAME service.
- Page 11 EVENT LISTINGS DEFAULT/MAJOR ONLY: - means event is disabled, * means event is enabled. USER: can select ON/OFF (ON: Enabled, OFF: Disabled), events that cannot be disabled (according to NOAA rules) are shown ON only. Not shown is ALL mode - all events are enabled NOTE: The Required Weekly/Monthly/Periodic/Silent Tests and Admin/Network/Demo Messages will not cause a siren to sound but can be displayed in ALL mode or in USER mode if enabled ENGLISH EVENT DESCRIPTION...
-
Page 12: Input/Output Ports
EVENT LISTINGS DEFAULT/MAJOR ONLY: - means event is disabled, * means event is enabled. USER: can select ON/OFF (ON: Enabled, OFF: Disabled), events that cannot be disabled (according to NOAA rules) are shown ON only. Not shown is ALL mode - all events are enabled NOTE: The Required Weekly/Monthly/Periodic/Silent Tests and Admin/Network/Demo Messages will not cause a siren to sound but can be displayed in ALL mode or in USER mode if enabled ENGLISH EVENT DESCRIPTION... - Page 13 Bluetooth Connection Go to the Bluetooth settings menu on your phone. Make sure Bluetooth is on before connecting to the available device “AL Storm Chaser”. AL Storm Chaser *Press to select BT mode, speaker will go to pairing mode and auto-reconnect if already paired. *Press and hold to drop an already paired BT connection if you want to change device POWER Audio: 15W (RMS), 50W (Peak)
-
Page 14: Safety Precautions
SAFETY PRECAUTIONS... -
Page 15: Fcc Statement
FCC STATEMENT Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identi er Trade Name: Altec Lansing Model No.: IMT7012 Responsible Party – U.S. Contact Information US Company Name: SAKAR INTERNATIONAL INC. Address: Edison, NJ 08817 Telephone number or internet contact information: 855-292-4087... -
Page 16: Warranty Card
WARRANTY CARD... - Page 17 IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions – All the safety and operating instructions should be read before this product is operated. 2.Keep these instructions – The safety and operating instructions should be retained for future reference. 3.Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.
- Page 18 RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR ATTENTION: - This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
