COCINA CERRADA CALEFACTORA Mod. L-05 C.C.E. INSTRUCCIONES PARA LA INSTALACION, USO Y MANTENIMIENTO INSTALLATION, USE AND MAINTENANCE INSTRUCTIONS INSTRUÇÕES PARA A INSTALAÇÃO, UTILIZAÇÃO E MANUTENÇÃO Fecha de edición: 27/11/2013 CODIGO: C0004_2...
Page 2
Hergóm WELCOME to the range. We would like to thank you for choosing our Hergóm L-05 cookers, which represent, in technique and style, a significant improvement in classical coal and wood cookers. We are sure that your new cooker will prove fully satisfactory, which is the most outstanding feature of our equipment.
Page 3
I.- FEATURES - Top. Robust and carefully sanded grey cast hob – polished, framed by an enamelled cast iron frame. - Grate rising mechanism. The capacity of the hearth is achieved, in this model, by changing the height of the grate, operating an endless screw. Access is via the ash cover, where the relevant handle will be found on the inside of the said cover.
Page 4
Installing draw regulation valve and cleaning cover Although the closed cookers have been provided with a system to regulate the input of fresh air required for combustion, it is advisable, mainly for installations with high draw systems of over five metres, good construction, insulation... to place a regulator on the wall, near the cooker output, to help control chimney draw, heat power and fuel consumption.
III.- OPTIONAL ACCESSORIES Hergóm offers the following accessories for this cooker: Steel vitreous enamel pipes. Stainless steel pipes. Elbow joints and covers for chimney construction. 30 l. closed expansion vessel. IV.- TECHNICAL DATA Model Cooker Dimensions Fireplace Dimensions Weight Min.
V.- INSTRUCTIONS OF USE Do not use as fuel wood from the sea; salts contained in it react in the combustion releasing acids that damage the cast iron and the steel plate. Every cooker comes with a number of utensils, such as a poker and a scraper to clean the ash pan and the smoke outlet via the soot cover.
Regulating draw The cooker is supplied with a sliding valve that can be installed in the wall to increase and reduce the diameter of the chimney and, hence, regulate draw (fig. 11). The log door and the ash cover are provided with sliding valves that regulate secondary and primary air intake, respectively.
VII.- SAFETY. A number of possible risks are present when operating your solid fuel cooker with fuel of any brand. The said risks can be minimised if the instructions and recommendations included in this manual are followed. Below, we shall recommend some rules and advice but, above all else, we recommend common sense.
Page 11
INDUSTRIAS HERGÓM S.A. Apartado de Correos, 208 de Santander SOTO DE LA MARINA - Cantabria Tel.: (942) 587000* Fax: (942) 587001 e-mail: hergom@hergom.com web: www.hergom.com Santander (España) Fecha de edición: 27/11/2013 CODIGO: C0004_2...
