egnite Querx
Network thermometer, hygrometer,
barometer and data logger
User Guide
Querx TH
Querx WLAN TH
Querx THP
Querx WLAN THP
Querx PT
Querx WLAN PT
Handbook version 5.4.1
Firmware version 4.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Querx and is the answer not in the manual?

Questions and answers

Related Manuals for Egnite Querx

Summary of Contents for Egnite Querx

  • Page 1 Querx Network thermometer, hygrometer, barometer and data logger User Guide Querx TH Querx WLAN TH Querx THP Querx WLAN THP Querx PT Querx WLAN PT Handbook version 5.4.1 Firmware version 4.4...

  • Page 2: Table Of Contents

    Table of Contents Introduction Safety Notices Symbols About egnite Querx First Use Before Setup Mounting the Sensor Model PT: Connecting the Sensor Cable Establishing the Network Connection Power Supply Network Configuration Accessing the Web Interface Accessing the Configuration Area Initial Configuration...
  • Page 3 Configuring the Data Logger Advanced Sensor Configuration Temperature Sensor Humidity Sensor Air Pressure Sensor Calculated Dew Point 10 Configuring the Interfaces 10.1 The Web Interface 10.2 HTTP-Push with Templates 10.3 Modbus/TCP 10.4 Configuring SNMP 10.5 Syslog 10.6 Signalers 11 Maintenance 11.1 Reboot 11.2 Saving the Configuration 11.3 Resetting the Configuration...

  • Page 4: Introduction

    Please read this manual carefully and take note of the following safety notices, in order to minimize the risk of damage or injury. Querx is intended to monitor and analyze climate data Intended purpose and make this data available via various interfaces.

  • Page 5: Symbols

    1.2 Symbols The following symbols will be used throughout this manual: ⚠ Danger Indicates possible danger of injuries. ⚠ Attention Indicates issues that can damage the device. Information Points out helpful hints and tips.

  • Page 6: About Egnite Querx

    (SCADA). Querx can operate as a stand-alone device. A cloud service is not necessary, though it offers simpler, global and central access to all data. In addition to palamoa.de, which can be used free of charge, most...
  • Page 7 Querx TH egnite Querx THP egnite Querx PT Reset button Status LED Sensor-cable Micro-USB socket for power supply Link LED RJ45-socket for Ethernet connection Network-activity LED...
  • Page 8 Querx WLAN egnite Querx WLAN egnite Querx WLAN PT WiFi antenna Button (currently without function) Status LED Reset button Sensor-cable Micro-USB socket for power supply Link LED RJ45-socket for Ethernet connection Network-activity LED...
  • Page 9 Querx TH with integrated temperature- and  humidity-sensors egnite Querx TH Set (item number EGN600114) Like egnite Querx TH (item number EGN600214) but additionally includes USB power adapter with micro-USB cable and  interchangeable plugs for UK, EU, US and AU outlets Ethernet patch cable ...
  • Page 10 Wifi antenna  egnite Querx WLAN TH Set (item number EGN601115) Like egnite Querx WLAN TH (item number EGN601215) but additionally includes USB power adapter with micro-USB cable and  interchangeable plugs for UK, EU, US and AU outlets Ethernet patch cable ...
  • Page 11 Querx WLAN PT100 Set (item number EGN601315) Like egnite Querx WLAN PT100 (item number EGN601415) but additionally includes USB power adapter with micro-USB cable and  interchangeable plugs for UK, EU, US and AU outlets Ethernet patch cable ...
  • Page 12 1.3.3 Accessories The following accessories and spare parts can be purchased from the manufacturer egnite: WiFi antenna  Ethernet cable  Micro-USB cable  USB power adapter with interchangeable plugs for  UK, EU, US and AU outlets DakkS- (German Accreditation Body) or ISO- ...

  • Page 13: First Use

    2.2 Mounting the Sensor Querx sensors can be mounted using the latches on the case. They can alternatively be mounted using zip-ties to tie them to piping, for instance. Please take note of the following points when mounting the device: Querx is designed for indoor use.

  • Page 14: Model Pt: Connecting The Sensor Cable

    2.3 Model PT: Connecting the Sensor Cable The Querx PT models support 2-, 3- or 4- wire Pt100 or Pt1000 sensors. Their color coding may vary, depending on the underlying standards. Information Depending on the production standards your sensor conforms with, none of the diagrams displayed below may correspond to the colors of you sensor’s wire.
  • Page 15 The above illustrations tell you which switch position your sensor requires. Use a tool with a fine tip to set the DIP switches to the required position. If necessary, use a magnifying glass. Proceed to connect the individual cable cores to the terminals as displayed in the images.
  • Page 16 A biro  Possibly a magnifying glass  Two DIP switches located above the terminals for the cable cores are used to select whether the sensor is connected to Querx PT using two, three or four cable cores.
  • Page 17 4-core Sensor 3-core Sensor 2-core Sensor The above illustrations tell you which switch position your sensor requires. Use a tool with a fine tip to set the DIP switches to the required position. If necessary, use a magnifying glass. Proceed to connect the individual cable cores to the terminals as displayed in the images.

  • Page 18: Establishing The Network Connection

    An audible click indicates that the connection has been made. Now connect Querx to the power adapter using a micro- USB cable and plug the power supply into a socket. The Querx status-LED will now light up yellow.

  • Page 19: Network Configuration

    2.6.1 Zeroconf Instead of connecting Querx to the local network, it can also be connected to a computer directly, via an Ethernet cable. Most operating systems support Zeroconf, facilitating such a direct connection.
  • Page 20 11.3.2 Performing a Hardware Reset, may help. 2.6.2 Manual Configuration If the automatic network configuration does not function as expected, or if this is not requested, Querx can alternatively be configured manually with a static IP address. Information The steps detailed in this section are not necessary for most users.
  • Page 21 Enter the IP address, the IP mask and the IP gate. Save the changes by clicking OK. Querx will apply the settings and then reboot. The status-LED will light up yellow. It will flash green as soon as the device is operational.

  • Page 22: Accessing The Web Interface

    Access via IP address Boot a web browser on your PC and enter the IP address of your Querx into the address bar, if you know it. Alternatively, Querx is accessible via its system name, if Access via system your PC supports Multicast DNS (mDNS or LLMNR).

  • Page 23: Accessing The Configuration Area

    The name can be changed later on. Additional info on this topic can be found in chapter 8 Advanced System Configuration. Querx can be accessed directly from the Safari web Access via Bonjour browser, using the Bonjour menu. 2.8 Accessing the Configuration Area Click the button Configuration in the upper right corner of the screen.

  • Page 24: Initial Configuration

    The section on the right of the screen displays short explanations of all the parameters that can be found on each page. 2.9 Initial Configuration The following sections will explain the individual steps that are required for Querx to function correctly. 2.9.1 Selecting the Language...
  • Page 25 8.1 General Settings. 2.9.2 Setting Date and Time Querx requires the current time, in order to track measurements. It is usually updated automatically via the net or a local time server. The time zone the device...
  • Page 26 Open the page System / Time. Select the correct time zone for your country from the drop down menu time zone. Now select the settings for daylight saving time: If your country uses daylight saving time and the time changes on the last Sundays of March and October, please activate auto in the section DST.
  • Page 27 Information The following settings are recommended for users in central Europe:Time zone: (GMT +01:00) Amsterdam, Berlin […] DST: automatic Please check that date and time are displayed correctly. If this is not the case, a problem occurred with the automatic update. In this case, click Set time manually. The values can be entered into the fields Date and Time manually.
  • Page 28 Are you sure? Click Yes. Please be patient, as this process may take a few minutes. Querx will reboot and begin logging new data once the process is completed. This concludes the initial setup.

  • Page 29: Configuring Alerts

    3 Configuring Alerts Querx can notify you of alerts via email, SNMP-trap and Syslog whenever defined value limits are exceeded. 3.1 Basic Alert Configuration Querx can notify you of the following critical ambient conditions: Temperature above upper limit value ...
  • Page 30 3.1.1 Alerts and Dead-band A dead-band value can be defined, in order to avoid the repetition of alerts that are based on limit transgressions. If the dead-band feature is activated, a value that has triggered an alert will have to return towards its normal state by the dead-band value, before a further alert can be triggered.
  • Page 31 3.1.2 Alert Delays A delay can be configured for alerts that are based on limit value transgressions, if you wish to accept short- term fluctuations. This can, for instance, be useful to allow for a tolerated decline in temperature during ventilation.
  • Page 32 3.1.3 Variation Alerts egnite Querx can notify you if values rise or drop more quickly than usual. In order to set this type of alert up, you will need to enter a value for the maximal accepted fluctuation between the highest and lowest values.

  • Page 33: Configuring Alerts

    3.2 Configuring Alerts 3.2.1 Temperature Alerts Information Please be sure to use a decimal point to separate the decimal digits when entering all the following values. Open the page Sensors / Temperature. Alerts for limit transgressions Please enter the number of seconds after which an alert is triggered in the input field Alert delay, if you wish to allow for short-term transgressions.
  • Page 34 The configuration of variation alerts requires the specification of two values each for dropping and rising temperatures. First, activate variation alerts by clicking Enable. Enter the maximal Value by which the temperature is permitted to drop. Enter the maximal Time within which the temperature is permitted to drop by the value specified in the previous step.
  • Page 35 3.2.2 TH and THP Models: Humidity Alerts Open the page Sensors / Humidity in the configuration Alerts for limit area to configure humidity alerts. transgressions Please enter the number of seconds after which an alert is triggered in the input field Alert delay, if you wish to allow for short-term transgressions.
  • Page 36 The configuration of variation alerts requires the Variation alerts specification of two values each for dropping and rising humidity. First, activate variation alerts by clicking Enable. Enter the maximal Value by which the humidity is permitted to drop. Enter the maximal Time within which the humidity is permitted to drop by the value specified in the previous step.
  • Page 37 Here you can enter a name for the sensor. The resolution of the displayed values can be extended to two decimal places. If you activate the function Dew point spread, Querx will display the difference between the current temperature and the dew point, instead of the absolute dew point.
  • Page 38 3.2.4 THP Models: Pressure Alerts Information Please be sure to use a decimal point to separate the decimal digits when entering all the following values. Open the page Sensors / Pressure in the configuration Alerts for limit area to configure humidity alerts. transgressions Please enter the number of seconds after which an alert is triggered in the input field Alert delay, if you...
  • Page 39 The configuration of variation alerts requires the Variation alerts specification of two values each for dropping and rising humidity. First, activate variation alerts by clicking Enable. Enter the maxiamal Value by which the humidity is permitted to drop. Enter the maximal Time within which the humidity is permitted to drop by the previously specified value.

  • Page 40: The Email Interface

    4 The Email Interface Querx can inform up to four email recipients of occurring alerts. Two email accounts from which the notifications are sent can be set up. 4.1 Managing Email Accounts At least one email account needs to be set up, in order to send emails alerts.
  • Page 41 Click Save to apply your changes. Information Passwords are not encrypted on the device. Therefore, it is strongly advised that you do not use any email accounts that are used for sending confidential information or, if possible, to create a dedicated account for Querx.
  • Page 42 Open the page Interfaces / Email. Editing an email account In the section Email accounts, click the Edit symbol next to the account you wish to edit. Make the required changes on the following page. Click the button Test to check your settings. If the test is successful, the button will turn green.

  • Page 43: Managing Email Recipients

    Deleting an email Open the page Interfaces / Email in the configuration account area. Click the Delete button next to the account you wish to delete in the section Email accounts. Confirm that you want to remove the account by clicking Yes.
  • Page 44 Select which alerts the recipient is notified of in the Notify on section. Activate Attachment On Alarm, if you wish to add a CSV-file containing all data of the last 24 hours to any alert notification. In addition alert notifications, Querx can also transmit status reports in regular intervals.
  • Page 45 Click Test to check your settings. This will send a test email to the recipient. Click Save to apply your changes. Open the page Interfaces / Email in the configuration Editing email recipients area. In the Recipients section, click the Edit symbol next to the entry for the account you wish to edit.
  • Page 46 Click Save to apply your changes. Open the page Interfaces / Email in the configuration Deleting email area. recipients In the Recipients section, click the Remove symbol next to the entry for the account you wish to delete. Confirm that you want to remove the recipient by clicking Yes.

  • Page 47: Email Templates

    4.3 Email Templates egnite Querx sends email notifications when alerts occur and when the values return to their normal state. Open the page Interfaces / Email in the configuration area to configure the format of these email notifications. Enter a Subject for the email notifications in the section Alert notifications.

  • Page 48: Event Descriptions

    4.4 Event Descriptions You can enter descriptions of occurring events on the page Interfaces / Email. These descriptions are also used in the event table, as explained in chapter 5.4. Viewing Recent Sensor Events. Enter a description for the event that values fall below the lower limit.

  • Page 49: Accessing Data Via The Web Interface

    5 Accessing Data via the Web Interface egnite Querx offers various interfaces for manual and automated data access. The web interface displays current values and alerts. An interactive diagram on the home page additionally lets you view logged data. 5.1 Current Values 5.1.1 Values on the Main Page...

  • Page 50: Viewing Logged Data

    ↧ Lower threshold transgressed ↥ Upper threshold transgressed ↘ Value falling too quickly ↗ Value rising too quickly ✖ Sensor error 5.2 Viewing Logged Data The chart on the home page displays the tracked data. You can select between two display modes: Line Chart and Heatmap (2).
  • Page 51 Display settings The sidebar offers various display options. The following settings can be adjusted for each sensor: Display graph. If this option is deactivated, both the limit values and grid lines will also not be displayed. Display grid lines. Display limit values. These options let you customize the line chart to suit your specific requirements.
  • Page 52 Set the time frame to a week, month or year Select which week, month or year you want to view These arrows let you skip through the weeks, months or years. The second mode “Day → Day” lets you view the last 24 hours or set a very customized time frame.
  • Page 53 Auto-Update mode mode is activated and the graph will continuously display the current values. If the right slider does not touch the bar’s right edge, the sliders are grey and the graph will only display the exact time period that is selected.

  • Page 54: Device Information

    You can select which sensor’s values you want to view by clicking the corresponding crosshair button the sidebar. The display of alerts that were recorded by the respective sensor can be toggled via the bell buttons (5). If this feature is active, all dates on which alerts were triggered are highlighted by a yellow border (6).

  • Page 55: Viewing Recent Sensor Events

    The first section displays the device’s name, type and the active firmware. The device name can be changed in the configuration area. In default settings, the system name is querx000000, where the six zeros are placeholders for the last six digits of the device’s MAC-address. The second section displays the time that has elapsed between the first and last entries in the data logger, as well as the percentage of its memory that has been...
  • Page 56 In default settings, the events are displayed in English and correspond to the texts specified for emails, as described in chapter 4.4 Event Descriptions.

  • Page 57: Exporting Data

    5.5 Exporting Data The values measured by Querx can be exported via the web interface. egnite Querx supports three formats for data export:  Data that is exported in the CSV format can be further processed in spreadsheet applications. ...
  • Page 58 The exported files include the specified time frame’s date and starting time, the average-, minimum- and maximum-values, as well as a timestamp for each measurement of the selected time frame.

  • Page 59: Embedding Graphs Into Other Sites

    5.6 Embedding Graphs Into Other Sites Wherever Querx can be reached via a network, Iframe can be used to embed the graph from the Querx home page into any other site, for instance on your local network. Open the Querx home page.

  • Page 60: The Http Interface

    Returns the current values in the XML format. json Returns the current values in the JSON format. fname Filename Sets the returned file’s name. Example: Exporting current values in the XML format (Querx PT) http://192.168.1.100/tpl/document.cgi? tpl/j/current.tpl&format=xml Output <?xml version="1.0" encoding="UTF-8"?> <!DOCTYPE querx PUBLIC "-//egnite//DTD Querx 1.0//EN"...
  • Page 61 <record> <entry sensorid="sensor_1" name="value" value="23.7" trend="0"/> <entry sensorid="sensor_2" name="value" value="29" trend="0"/> <entry sensorid="sensor_3" name="value" value="23.7" trend="0"/> </record> </data> </querx> Example: Exporting current values in the JSON format (Querx TH) http://192.168.1.100/tpl/document.cgi?tpl/j/current.tpl&format=json Output "querx": "version": 1.0, "hostname": "querx011f30", "ip": "192.168.1.100", "port": 80, "date_gmt": "Tue, 26 Apr 2016 12:54:50",...
  • Page 62 {"sensor": "id": "sensor_1", "name": "Temperature", "unit": "&deg;C", "status":"0", "uplim":"85.0", "lolim":"-40.0" {"sensor": "id": "sensor_1", "name": "Humidity", "unit": "%RH", "status":"0", "uplim":"100", "lolim":"0" {"sensor": "id": "sensor_1", "name": "Dew point", "unit": "&deg;C", "status":"0", "uplim":"26.0", "lolim":"0.0" "data": {"record": { "timestamp": "1461675290", "date": "26.04.2016", "time": "13:54:50", "entry": [ { "sensorid": "sensor_1",...

  • Page 63: Exporting Logged Data

    "name": "value", "value": 23.7, "trend":0 { "sensorid": "sensor_2", "name": "value", "value": 33, "trend":0 { "sensorid": "sensor_3", "name": "value", "value": 23.7, "trend":0 6.2 Exporting Logged Data http://<IP>/tpl/document.cgi?tpl/j/datalogger.tpl URL parameters: format Returns logged values in the XML format. json Returns logged values in the JSON format. Returns logged values in the CSV format.
  • Page 64 14.04.2016 06:00:00;24.1;24.2;24.2;33;33;33 14.04.2016 08:00:00;23.8;24.1;24.2;33;33;34 14.04.2016 10:00:00;23.7;23.8;23.9;32;33;33 14.04.2016 12:00:00;24.1;24.2;24.3;31;32;33 14.04.2016 14:00:00;24.2;24.4;24.7;30;30;31 Example: Exporting the values from the 5 of April 2016 with an interval of one hour in the XML format (Querx PT) http://192.168.1.100/tpl/document.cgi?tpl/j/datalogger.tpl &format=xml &start=1459854000 &end=1459864800 &step=3600 Output <?xml version="1.0" encoding="UTF-8"?>...

  • Page 65: Tls And User-Login

    <!DOCTYPE querx PUBLIC "-//egnite//DTD Querx 1.0//EN" "http://www.egnite.de/dtds/querx.dtd"> <querx version="1.0"> <hostname>querxwlan</hostname> <ip>192.168.1.100</ip> <port>80</port> <date_gmt>Tue, 26 Apr 2016 10:48:41</date_gmt> <date_local>Tue, 26 Apr 2016 11:48:41</date_local> <contact></contact> <location></location> <sensors> <sensor id="sensor_1" name="Temperature" unit="&deg;C"></sensor> </sensors> <data> <record timestamp="1459857600" date="05.04.2016" time="13:00:00"> <entry sensorid="sensor_1" name="minimum" value="25.3"/> <entry sensorid="sensor_1" name="average" value="25.4"/>...

  • Page 66: Application Examples

    Example: User registration https://192.168.1.100/login.cgi Postdata login_user: querx login_pass: verysecure Output Ignore the output but save the session! 6.4 Application Examples Examples for the application with various coding languages can be found in the tutorials section on the support page at egnite.de.

  • Page 67: Access Privileges

    Querx and the device’s settings. Read data / Write config: The user can read the data  tracked by Querx and the device’s settings. They can also change the settings. 7.1 User Administration The factory settings do not include a password- protected user, making the device’s settings accessible...
  • Page 68 7.1.1 Creating a New User Account Open the page System / Users in the configuration area to change the user settings. Click the Add button next to an empty line in the section Users. On the following page, enter a user name into the input field User name and a password into the input field Password.
  • Page 69 7.1.2 Editing a User Account Open the page System / Users in the configuration area. Click the Edit symbol in the section Users. Make the required changes. Click Save to apply your changes. Information The access rights can only be edited if at least one further user with writing access has been set up.
  • Page 70 7.1.3 Removing a User Open the page System / Users in the configuration area. Click the Remove button next to the user you wish to remove. Confirm that you wish to remove this user by clicking Yes. Information A user with access rights can only be removed if at least one further user with writing access has been set up.
  • Page 71 In order to restrict anonymous access to Querx entirely, assign the group of access rights Disabled to the user. To allow all network members restricted access to Querx, select the required group of access rights. Click Save to apply your changes.

  • Page 72: Logging In

    7.2 Logging in If you have set up users and assigned access rights to them, you will first need to log into the device. The buttons that let you log in and access the configuration area are located in upper right corner of the home page.

  • Page 73: Advanced System Configuration

    M2M interfaces. It also serves as the host name that can be used to access Querx via a web browser (cf. Section 2.7 Accessing the Web Interface). You can use up to 15 letters and digits, but you should refrain from using special characters, in order to ensure compatibility with other systems.

  • Page 74: Setting Date And Time

    Querx requires this data, in order to track measurements. It is usually updated automatically via the net or a local time server. Querx also features an internal clock that enables the device to continue tracking data if the network connection fails. The integrated buffer battery can bridge even longer power shortages.
  • Page 75 Now select the settings for daylight saving time: If your country uses daylight saving time and the time changes on the last Sundays of March and October, please activate auto in the section DST. If your country uses daylight saving time, but the time does not change on the last Sundays of March and October, please deactivate auto in the section DST.

  • Page 76: Network Configuration

    PC. In order to do this, click Sync PC. Click Save to apply your changes. 8.3 Network Configuration Querx can be connected to a network via an Ethernet LAN cable. The WLAN models can alternatively be connected to WiFi networks.
  • Page 77 8.3.2 Dynamic Network Configuration Open the page System / Network in the configuration area to select the dynamic network configuration using DHCP or Zeroconf. Click the Edit symbol next to the entry Ethernet to access the settings for this interface. Select Obtain IP address automatically.
  • Page 78 8.3.3 WLAN Models: WiFi Interface Open the page System / WiFi in the configuration area to configure the WiFi interface. Click Enable, in order to activate the WiFi interface. Select your network. Enter your network’s SSID manually in the input field SSID or click the button Select network to select the network from a list of available wireless networks.
  • Page 79 Querx WLAN switches between the Ethernet and WiFi interfaces according to whether it can detect a wired Ethernet connection. If a wired network connection is detected, Querx WLAN activates the Ethernet interface. If no wired connection is detected or an existing connection is disrupted, the device will activate the WiFi interface.

  • Page 80: Configuring The Data Logger

    4 million entries. This means that Querx THP can store data for 25 days when logging one entry per minute. Querx TH and PT can track data for 51 days and the WLAN models can record data for 7.5 years, when using the same settings.
  • Page 81 Set the interval between logged entries by entering the required number of minutes in the input field Logging interval. If required, activate data Compression. Click Save to apply your changes. Information Data compression can lead to noncritical display errors in the representation of measurements in the diagram.

  • Page 82: Advanced Sensor Configuration

    Set the Filter to the mains frequency used in your country. In Europe this is 50 Hz. Select the physical Unit that you want Querx to use. Activate Extended Resolution in order to display measurements with two decimal places instead of one.

  • Page 83: Humidity Sensor

    Click Save to apply your changes. 9.2 Humidity Sensor Activate Extended Resolution in order to extend the display measurements by one decimal place. Keep in mind that this does not increase the accuracy of measurements and that data will still be logged with one decimal place.

  • Page 84: Air Pressure Sensor

    9.3 Air Pressure Sensor Select the physical Unit that you want Querx to use. Querx usually displays the absolute air pressure at its location. If you need to monitor the relative air pressure, you will require the location’s elevation above sea level.
  • Page 85 Activate Extended Resolution in order to extend the display measurements by one decimal place. This does not increase the measurements’ accuracy. If you activate Dew point spread, Querx will display the difference between the current temperature and the calculated dew point.

  • Page 86: Configuring The Interfaces

    10 Configuring the Interfaces Querx offers a number of different interfaces that can be used to access all measured data and notify you of alerts. 10.1 The Web Interface This section explains the basic configuration of the web interface and the diagram on the home page.
  • Page 87 10.1.2 Visualization Select a Color for the temperature chart. Select the value range displayed in the diagram: Enable Auto zoom to let Querx automatically adjust the displayed range to the tracked values. Alternatively, static Minimal and Maximal values can be assigned to the displayed value range.

  • Page 88: Http-Push With Templates

    HTTP-Push with Templates The page HTTP-Push in the configuration area lets you set up up to two cloud services to which Querx can transmit the data it tracks simultaneously. The structure in which data needs to be sent to any cloud service depends on the provider.
  • Page 89 Enter the Update rate. This value determines how often Querx sends new data to the cloud service (in minutes). If this value is set to 0, Querx will transmit data whenever any values have changed. Click Save to apply your configuration and begin data...

  • Page 90: Modbus/Tcp

    Click Save to apply your changes. Information Please note that Querx only supports a single Modbus connection. If you intend to use Querx with several masters, the connection to one master needs to be interrupted, in order to vacate the connection for the other masters.
  • Page 91 10.3.2 Modbus Registers Read Registers Address Offset Format Contents 30011 int16 Temperature Celsius * 10 30012 int16 Relative humidity % 30013 int16 Temperature Fahrenheit * 10 30014 int16 Temperature Kelvin * 10 30015 int16 Dew point Celsius * 10 30016 int16 Dew point Fahrenheit * 10 30017...

  • Page 92: Configuring Snmp

    Click Save at the bottom of the screen to apply your changes. Restart the device via the web interface as detailed in chapter 11.1.1 Soft Boot. Information Please note that Querx needs to reboot after enabling or deactivating the SNMP-agent.
  • Page 93 10.4.3 Activating SNMP Traps Open the page Interfaces / SNMP in the configuration area. Enter the IP-address or hostname for the host who is to receive the SNMP traps in the input field Trap receiver in the SNMP section. Check the Trap community and make any required changes.

  • Page 94: Syslog

    10.4.4 SNMP MIB The main SNMP Object Identifiers defined by Querx are: Description 1.3.6.1.4.1.3444.1.14.1.2.1.5.1 Temperature sensor 1.3.6.1.4.1.3444.1.14.1.2.1.5.2 Humidity sensor 1.3.6.1.4.1.3444.1.14.1.2.1.5.3 Calculated dew point 1.3.6.1.4.1.3444.1.14.2.0.101 Trap-code for normal conditions 1.3.6.1.4.1.3444.1.14.2.0.102 Trap-code for alerts Please refer to the MIB that is saved on the device for a complete list.

  • Page 95: Signalers

    10.6 Signalers egnite Querx is fitted with an LED that can notify you of occurring alerts. 10.6.1 Optical Signals Open the page Interfaces / Signalers to configure alerts displayed on the device itself. Set the number of seconds for the Rate at which egnite Querx blinks under normal conditions.
  • Page 97 10.6.2 WLAN Models: Acoustic Signals Acoustic signals are only available on WLAN models. Select a Startup signal sound. Select an Alert signal sound. Specify whether the signal for alerts is to be Repeated. Select a sound to signal that the values are Back to normal.

  • Page 98: Maintenance

    Reboot Certain changes to the configuration are only applied after the device has rebooted. There are two different ways of rebooting egnite Querx – via the web interface (soft boot) or by interrupting the power supply (cold boot). 11.1.1 Soft Boot It is sometimes required to reboot the device after changing settings.

  • Page 99: Saving The Configuration

    Click the Choose File button labelled Backup file in the Restore configuration section and select the configuration file that you intend to activate in the dialog box. Click Upload. Finally, restart Querx via the web interface as detailed in section 11.1.1 Soft Boot.

  • Page 100: Resetting The Configuration

    When the configuration is reset via the reset button, all settings, including the network configuration, are reset and the device is returned to factory settings entirely. This function is primarily used if Querx is no longer accessible via the network. 11.3.1 Resetting the Configuration Via the Web Interface Open the page Maintenance / Reset in the configuration area.
  • Page 101 11.3.2 Performing a Hardware Reset Querx can be returned to the factory settings via a hardware reset, if you can not enter the configuration area, for instance because you do not have the access data at hand. You will need: a biro ...

  • Page 102: Firmware-Updates

    Querx product range. If required, these firmware updates can be saved on your device and activated. https://www.egnite.de/support-en/firmware/ Querx can store two firmware images in two separate buffers. The software is copied into the internal memory and implemented when one of the buffers is activated.
  • Page 103 Select the Buffer containing the firmware image you want to activate in the section Activate firmware. Click the button Activate to activate the new firmware. Querx will now copy the buffer's contents into its internal memory and then reboot. ⚠ Attention Do not disconnect Querx from the power supply while a firmware image is being activated.

  • Page 104: Changing The Battery

    11.5 Changing the Battery Querx is fitted with a battery that is used to operate the internal clock in the case of a power shortage. A...
  • Page 105 However, we recommend sending the device in for maintenance. Information egnite Querx is operational without a battery. The battery does not need to be changed if the device is in ongoing operation under normal operating conditions (at a temperature of approx. 23 degrees centigrade).
  • Page 106 In order to change the battery you will need: Two Phillips screwdrivers, sizes PH0 and PH1  A replacement battery, type Renata CR1225  ⚠ Attention Take care not to touch any electrical contacts while changing the battery. Electrostatic discharges (ESD) can damage the device immediately or in the long run.

  • Page 108: Resetting The Internal Memory

    11.6 Resetting the Internal Memory egnite Querx starts logging data as soon as the device is taken into operation. The previously logged data needs to be deleted, in order to begin logging data according to the basic settings you have configured.

  • Page 109: Adjustment And Calibration

    Querx offers the possibility of calibrating the sensor’s measurements, as well as adjusting them, if required. In common practice, it may occur that Querx does not display the true, current values but diverges from them within certain limits. The feature Adjustment and...
  • Page 110 Querx to that measured by the reference device and generating the difference between the two values (actual value – value displayed by Querx). Open the page for the corresponding sensor in the Querx configuration area: Sensors > Temperature / Humidity / Pressure.
  • Page 111 (see above), are known. The device applies the same formulas as detailed in the section Manual Adjustment with Offset and Gain. In order to let Querx adjust offset and gain automatically, please proceed as follows: Open the page Sensors > Temperature / Humidity / Air...
  • Page 112 Enter the measured value into the input field Lower reference value. Click the button Measure. Raise the value measured by Querx to a higher level by increasing the measured parameter (i.e. temperature, humidity or air pressure) and measure it with the reference device.
  • Page 113 Calibration history by entering any string of text into the input field Annotation before clicking Save. Since Querx can only save the data of up to 30 calibration processes, and it can not be deleted once saved, it is recommended to only use this feature after making sure that you will really require the data in the history permanently.

  • Page 114: Troubleshooting

    If you encounter any problems not discussed in this manual, please contact the manufacturer egnite directly. The contact details can be found in chapter 12.9 Manufacturer and Contact Details. Furthermore, a tutorial that will help you narrow down...

  • Page 115: Appendix

    12 Appendix 12.1 Specifications 12.1.1 egnite Querx TH Specifications Temperature sensor -40 °C to 85 °C Measurement range -40 °F to 185 °F ±0,4°C (10 to 85°C) / ±1,0°C ( -40 to -10°C) Accuracy ±0,7°F (14 to 185°F) / ±1,8°F (40°F to 14°F) 0,1 °C...
  • Page 116 European Union CE-compliant UL, USA / Canada UL94V-0 Protection class IP20 12.1.2 egnite Querx THP Specifications Temperature sensor -40 °C to 85 °C Measurement range -40 °F to 185 °F ±0,4°C (10 to 85°C) / ±1,0°C ( -40 to -10°C) Accuracy ±0,7°F (14 to 185°F) / ±1,8°F (40°F to 14°F)
  • Page 117 Pressure sensor Measurement range 300 – 1100 hPa Absolute accuracy ±1 hPa Relative accuracy ±0,12 hPa Resolution 0,18 Pa Long-term stability ±1 hPa / Jahr Hardware and interfaces Interval between 1 second measurements Factory-calibrated, DakkS certificate available (German Calibration Accreditation Body) Sensor heater Integrated 10/100 Mbit RJ45, HP Auto-MDIX...
  • Page 118 Sockets RJ45 (Ethernet), Micro-USB Mounting Wall mounting Conformity European Union CE-compliant UL, USA / Canada UL94V-0 Protection class IP20...
  • Page 119 12.1.3 egnite Querx WLAN TH Specifications Temperature sensor -40 °C to 85 °C Measurement range -40 °F to 185 °F ±0,4°C (10 to 85°C) / ±1,0°C ( -40 to -10°C) Accuracy ±0,7°F (14 to 185°F) / ±1,8°F (40°F to 14°F) 0,1 °C...
  • Page 120 Power supply 5 V DC to 5.5 V DC Power consumption 200 mA 1 W (typically) / 300 mA 1,5 W (maximally) Ambient conditions -40 °C to 85 °C, max. 95 % rF Operation -40 °F to 185 °F, max. 95 % rF -40 °C to 85 °C, max.
  • Page 121 12.1.4 egnite Querx PT100 / egnite Querx PT1000 Specifications Temperature sensor Sensor-dependent Measuring range -200 °C to 750 °C -328 °F to 1382 °F Sensor-dependent Accuracy 0,5 °C 0.9 °F 0,1 °C Resolution 0.2 °F Pt Pt100/Pt1000-connection 2-, 3- and 4-core...
  • Page 122 Wall mounting Conformity European Union CE-compliant UL, USA / Canada UL94V-0 Protection class IP20 12.1.5 egnite Querx WLAN PT100 / egnite Querx WLAN PT1000 Specifications Temperature sensor Sensor-dependent Measuring range -200 °C bis 750 °C -328 °F bis 1382 °F Sensor-dependent Accuracy 0,5 °C...
  • Page 123 Power consumption 200 mA 1 W (typically) / 300 mA 1,5 W (maximally) Ambient conditions -40 °F bis 185 °F, max. 95 % rF Operation -40 °C bis 85 °C, max. 95 % rF -40 °C bis 85 °C, max. 95 % rF Storage -40 °F bis 185 °F, max.
  • Page 124 12.1.6.2 THP Models: Temperature Sensor Measuring range Typical Unit Accuracy ± 0.5 °C 0 – 65 ± 1.0 °C...
  • Page 125 12.1.6.3 TH Models: Humidity Sensor Measuring range Typical Maximal Unit Accuracy 0 – 80 ± 2 ± 3 80 – 100 See illustration Long-term ≤ 0.25 % / year stability 12.1.6.4 THP Models: Humidity Sensor Measuring range Typical Unit Accuracy 20 –...

  • Page 126: Inaccuracies In Extreme Conditions

    12.2 Inaccuracies in Extreme Conditions The capacitive humidity sensor is made of a thin polymer film that is located between two electrodes. Depending on the humidity, the polymer absorbs or releases vapor contained in the surrounding air. This changes the polymer film's dielectric properties and thus the sensor's capacitance.

  • Page 127: Conformity

    Technical Support If you encounter any problems with one of our products, the team at egnite will be glad to assist and advise you. Please keep the following information at hand when contacting us, in order to make it as easy as possible for...

  • Page 128: Notes On Storage

    You can also find instructions that will help you narrow down the causes for your problem using a Syslog application in the Querx Tutorials section at egnite.de. Please work through this manual and send us the recorded log files.

  • Page 129: Drill Templates

    12.8 Drill Templates egnite Querx TH egnite Querx THP egnite Querx PT egnite Querx WLAN egnite Querx WLAN egnite Querx WLAN PT...

  • Page 130: Manufacturer And Contact Information

    Fax +49 (0)2305 441487 www.egnite.de 12.10 Disclaimer egnite can not be held responsible for technical or typographical mistakes. We reserve the right to alter the documentation without further announcements. © 2019 egnite GmbH, Germany. All rights reserved. All trademarks used are the property of the respective...

This manual is also suitable for:

Querx thQuerx wlan thQuerx thpQuerx wlan thpQuerx ptQuerx wlan pt ... Show all

Table of Contents
