APW Wyott HDD-1 Specifications

PRODUCT:
Designed Smart
Developed for High Performance!
• APW Wyott Holding Drawers are designed to hold everything
from crispy foods to moist foods at required NSF temperatures.
• Heating system is designed to provide fast start-ups and heat
recoveries when drawers are open and closed.
• Thermostatic controls in each drawer precisely regulate
temperatures between 110 degrees and 200 degress.
• Perimeter heating elements distribute heat evenly through the
drawer area, promoting consistent food temperatures throughout
the food pan while avoiding scalding due to warmer "hot spots".
• The only Holding Drawer built with "extra deep" holding pan
(6 ¼" deep). Deeper pan holds 6" deep food pans without
resting on the bottom of the holding area. This avoids scalding
on the bottom of food pans.
• Deep Holding Pan is perfect for using with ¼" of water at the
bottom, promoting a more effective heat transfer and higher
humidity level.
• Vent Slides in each Drawer Front allow operator to control the
amount of humidity in each compartment.
Energy Efficient!
• The complete Drawer Compartment is protected with 1-inch
fiberglass insulation, including the Drawer Front Panels.
Insulation focuses heat into the food and keeps exterior panels
"cool to the touch."
Easy to Maintain and Service!
• Holding Pan lifts directly out of Drawer, allowing for quick
cleaning and maintenance.
Built Solid
Built to Last
• Frame, interior and exterior construction is made with stainless steel.
• Drawers are constructed with reinforced 14 gauge stainless steel
drawer slides that ride on two reinforced 16 gauge stainless steel
slide brackets. (Will not bend or warp drawer tracking system.)
• Each Drawer Slide rides on 4 self lubricated, stainless steel rollers
that are secured to the interior walls with a reinforced bolt system.
• APW Wyott Drawer Slides feature a unique "jam-free" side roller,
a design that facilitates the smoothest closing action in the
industry from any angle in which the operator pushes the drawer.
• Drawers have built-on horizontal stainless steel handles.
Reliability backed by APW Wyott's Warranty
• All APW Wyott holding drawers are backed by a 1-year parts
and labor warranty, including on-site service calls within 50
miles of authorized service technicians.
• Certified by the following agencies:
APW Wyott Foodservice Equipment Company · 729 Third Ave., Dallas, TX 75226
(800) 527-2100 · (214) 421-7366 · Fax (214) 565-0976 · www.apwwyott.com · info@apwwyott.com
Standard Models:
QUANTITY: ITEM #:
Standard & Slimline
Countertop Holding Drawers
HDD-1 HDD-2 HDD-3
MODEL HDD-1 COUNTERTOP HOLDING DRAWER
APW Wyott Design Features
• Heavy-duty stainless steel construction for the frame,
exterior and interior.
• Fully insulated compartments with 1" thick fiberglass sheets
on top, sides and drawer fronts.
• 14 gauge stainless steel drawer slides with reinforced 16
gauge Slide Brackets
• Side "Jam-free" Roller design on the Drawer slide
• Each drawer individually controlled by a protected
thermostat, indicator lamp and rolling read-out thermometer.
• Temperature range of 100° - 200°F (38°C - 93°C).
• Adjustable Vent Controls on each drawer.
• Each drawer has removable 12"x20"x6 1/4" deep stainless
steel liner pan.
• Built-on Stainless steel handles
Options
• Perforated well-pan bottom
• 2" swivel casters
• 6" Stainless Steel Legs
• Color Drawer Fronts (call factory for color availability and cost)
Consultant Specifications
The Holding Drawer Warmers shall be a APW Wyott Model ...., as
manufactured by the APW Wyott, Dallas, TX, U.S.A. The unit shall
have ....drawer(s) and be rated at ....watts, ....amps. Freestanding
model shall be equipped with a cord and plug. The Drawer Warmer
shall have a stainless steel exterior, interior, drawer slides, and
assembly. Drawer rollers shall be self lubricated, stainless steel. The
drawer slide shall have the "jam-free" side roller system. The unit
shall be insulated in the top, sides and drawer fronts of each com-
partment and have individual power switch, thermostat and temper-
ature monitor for each drawer.
See reverse side for product specifications.
Slimline Models: HDDS-1 HDDS-2 HDDS-3
Rev. 6/9/2005
