Soltec Bioclimatic Pergola Agava SL Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation instructions
Bioclimatic Pergola
Agava SL
O UT DOOR LIVIN G
The document is valid from 1.12.2020 and replaces all previous editions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bioclimatic Pergola Agava SL and is the answer not in the manual?

Questions and answers

Related Manuals for Soltec Bioclimatic Pergola Agava SL

Summary of Contents for Soltec Bioclimatic Pergola Agava SL

  • Page 1 Installation instructions Bioclimatic Pergola Agava SL O UT DOOR LIVIN G The document is valid from 1.12.2020 and replaces all previous editions.
  • Page 2 Prefix This Installation Instructions manual offers you the know-how on assembling and mounting Soltec Pergola Agava SL System. Through reading process you will notice, that this quide is made through following the basic knowledge presented in Soltec's Training guide. This manual is focused on the first 14 points from the Training Guide.
  • Page 3 Index Configurations STEP 1 & STEP 2 Check received cargo STEP 2.1 Read the instructions STEP 2.2 Tools & Equipment STEP 2.3 Order Form STEP 2.4 Marking the location STEP 3 Positioning STEP 3.1 Parallelism of wall and profile STEP 4 The place needed for assembling the installation STEP 5 Inserting metal plates into wall mounting frame profile...
  • Page 4 Index STEP 9 Attachment of pedestals STEP 10 Laying frames on posts STEP 10.1 Screwing the post on position P2 STEP 10.2 Screwing the post on position P5 STEP 11 Attaching the frame to the wall STEP 12 Screwing the post and foot support STEP 13 Assembly of blades STEP 13.1...
  • Page 5 Configurations TYPE 1 TYPE 5 Self-standing Wall-mounted blades parallel to wall TYPE 2 TYPE 6 Wall-mounted blades Self-standing perpendicular to wall posts off-center TYPE 3 TYPE 7 Wall-mounted on Wall-mounted blades two sides blades perpendicular to wall perpendicular to wall TYPE 4 TYPE 8 Wall-mounted blades...
  • Page 6 STEP 2 Check received cargo Opening the box and inspection of the components on the basis of packing list and relevant documentation, preparation PACKING LIST Soltec d.o.o., Obrtna ulica 9 SI-8257 Dobova, Slovenia VAT ID: 48773867 Delivery adress Forwarder Page:...

  • Page 7: Before You Start

    STEP 2.1 Read the instructions Before beginning with installation, you MUST go through following points 1. The amount of pieces in the received assembly 2. The quality of the pieces in the received assembly 3. Installation Manual 4. User Manual 5.

  • Page 8: Tools And Equipment

    Standing Pads Ladder protecting glasses 1. Go to Google Play or AppStore Watch Soltec videos on Youtube channel: 2. Download QR Reader aplication 3. Open the aplication and scan QR Codes in this document 4. Watch installation instructions videos QR Code Reader Videos &...

  • Page 9: Order Form

    With signoff of this Order form the Stamp & signature Client declares, that the Client has read and accepts the General Terms and Conditions of Soltec d.o.o., which are published on www.soltec.si. Step 2 / Product information Type of pergola...
  • Page 10 Order Form Step 3 / Drawing with marked specifications Mark motor position, water exit and power supply on top view location of motor position Blades opening way location of power supply location of water exit · Water exit is possible on same pole as electricity, but only if Type P is ordered as special option of water evacuation.
  • Page 11 Order Form Step 4 / Options ZIP blinds Fabric Serge Fabric Soltis Motor + 10% 108101 grey-white standard 108108 grey Somfy Crystal full screen 108118 grey-black + 10% Colour of guides 116101 linen-white Crystal window Same as 117101 pearl-white pergola frame dim.

  • Page 12: Additional Comments

    To be filled by Soltec / manufacturer Value Shipping In total Offer number Project reference number Date SOLTEC d.o.o. • Obrtna ulica 9 • 8257 Dobova, Slovenia T +386 (0)7 45 27 126 • E info@soltec.si • www.soltec.si Installation instructions Bioclimatic Pergola Agava SL...
  • Page 13 STEP 2.4 Marking the location Marking the location on the floor or wall for mounting the structure and fixing the brackets is also the start of mounting process. There are practically 8 basic possibilities of mounting, which can be seen in the Configurations on page 5.
  • Page 14 STEP 3 Positioning Position of the wall mounted frame profile & foundation position Before starting to assemble the frame, it is post positions necessary to determine the position of the support lines for longitudinal frame profile on the wall and positioning foundation positions: width of profiles...
  • Page 15 Positioning Indicate wall positions EXAMPLE TYPE Top view Installation instructions Bioclimatic Pergola Agava SL...
  • Page 16 STEP 3.1 Parallelism of wall and profile BEFORE starting to assemble the frame, check the parallelism between the wall and the wall profile. If curvedness is too large, mounting the frame is not possible. The wall and the wall profile have to be parallel The wall and the wall profile have to be...
  • Page 17 STEP 4 The place needed for assembling the installation Put four pedestals on a suitable place, big enough for assembling. Pedestals MUST be coated to avoid damage on the profiles. Remove all unnecesary obstacles. Installation instructions Bioclimatic Pergola Agava SL...
  • Page 18 STEP 5 Inserting metal plates into wall mounting frame profile Metal plates (R) are inserted into the wall mounting profile The number of plates depends on the project (position P3 , P4) PHASE 1 Align plates with anchor bolt axis Corner P3 and P4 (on right side) Anchor bolts axis...
  • Page 19 STEP 5.1 Inserting metal plate for supporting post on position P5 Metal plate (Y) is inserted into the longitudal profile for supporting post on position P5. PHASE 1 (on left side) metal plate PHASE 2 Installation instructions Bioclimatic Pergola Agava SL...
  • Page 20 STEP 5.2 Screwing and inserting the L - angle upper (AA) into transverse frame profile L-angle upper (AA) is inserted into all 4 transverse frame profile corners PHASE 1 Corner P1, P3 , P4 and P2 L - angle upper (AA) PHASE 2 Corner P1, P3 , P4 and P2 L-angle upper (AA) is...
  • Page 21 STEP 5.3 Screwing and inserting the L - angle lower, connecting and with threads (AC) into transverse frame profile L-angle lower, connecting & with threads (AC) is inserted into 3 transverse frame profile corners. PHASE 1 Corners without post support need Corner P1, P3 , P4 and P4 L-angle lower, connecting and with threads (AC).
  • Page 22 STEP 5.4 Screwing and inserting the L - angle lower (AB) into transverse frame profile L-angle lower (AB) is inserted into transverse frame profile corner P2. Corners with a post support only need PHASE 1 L-angle lower (AB). Corner P2 (on right side) inserting L - angle lower (AB) Installation instructions...
  • Page 23 STEP 5.5 Metal plates, L - angles (AA), (AB), (AC) and screws (A) are in place Inserted L-angle upper (AA) are succesfully inserted into the corresponding places. Inserted L-angle lower, connecting L - angle upper (AA) & with threads (AC) are succesfully inserted into the corresponding places.
  • Page 24 STEP 6 Connection of electrical and signal cables through the profiles BEFORE Connection of cable connections is carried out when the frame pro- files are not screwed together. continuing the installation, all Blades motor unit and LED lights electrical and signal cables are preset in the factory.

  • Page 25: Led Light

    STEP 6.1 Connecting the cables and sockets 1. BLADE MOTOR UNIT Connect plug and socket on joint NOT CONNECTED CONNECTED 2. LED LIGHT POSITION 1 Connect plug and socket on joint AF joint is properly connected, if the inscription “ALTW” on the connectors is visible on the same side.
  • Page 26 STEP 6.2 Assembling of the frame and testing of cable connections 1. ASSEMBLING OF THE FRAME Both transverse frame profiles (W1, W2) are evenly and at the same time inserted into a longitudinal frame profile. CAUTION: The cables in frame must not be damaged. (W2) (W1) 2.

  • Page 27: Disconnecting Power

    3. TESTING ZIP ROLLER BLIND Check the rolo movement UP and DOWN. The final setting is done when the frame is set on location. Use remote control, follow instruction in OPTIONS chapter. The image is symbolic because the ZIP roller is just mounted on the profile on the assembled frame but the structure has not yet been mounted.
  • Page 28 STEP 7 Screwing a longitudal frame profile and L - angles STEP 7.1 Screwing a longitudal frame profile and upper L - angle (positions P1, P3, P4) Through openings on longitudinal profiles, profile and upper L-angle are screwed together with A screws. screw in the A screws P1, P3, P4, P5 STEP 7.2...
  • Page 29 STEP 7.3 Longitudinal frame profile and lower L - angle (position P2 - with post) Through the middle oval hole in the lower part of the frame the lower L-angle is attaching to the frame with C screws from below to prevent the L-angle from moving before screwing the post.
  • Page 30 STEP 8 Position of foot support (EXAMPLE TYPE frame) T1, T2 - Position of foundations (AD) under posts NOTE: D1 = D2 Use a laser gauge. Tighten the screws of assembled frame, when the diagonals are properly set. EXAMPLE TYPE Top view STEP 8.1 Inclination of the frame...
  • Page 31 STEP 8.2 Tabel info Use this list for height differences. Respect the values for different Pergola models and Type of Installations. FRAME INCLINATION (in mm) has to be performed by installer WIDTH OF PERGOLA Blade 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 incl .
  • Page 32 STEP 9 Attachment of pedestals DRILLING AND INSERTING SCREW E Drill into the foundation through the diagonal pair of holes. Use a drill for concrete with a diameter of 12 mm. Insert screw E into the foundation holes. NOTE: Rotate the pedestal according to posts drainage opening.
  • Page 33 STEP 10 Laying frames on posts LIFTING POSTS Lift the composite profiles using lifting pads. Place the posts on their position and screw them. Do not forget to use your protective equipment. It is necessary to pay attention to the correct position and orientation of the posts.
  • Page 34 STEP 10.1 Screwing the post on position P2 SCREWING THE LOWER L - ANGLE WITH A SUPPORTIVE POST (P2) Use the screws B and screw the lower L - angle with post. It is necessary to have a hexagonal key, 20 cm long to be long at least 20 cm.
  • Page 35 STEP 10.2 Screwing the post on position P5 SCREWING THE PLATE FOR POST OUT OF THE CORNER WITH A SUPPORTIVE POST (P5) Place the post on its position and screw it with screws B. Screw the screws A in the gutter with rubber washer under 20 cm long them.
  • Page 36 STEP 11 Attaching the frame to the wall The frame is raised and leaned to the wall, then the profile of the frame is fastened (P3, P4). Do not forget to use your protective equipment. The frame must be supported by the pedestals until the fixing to the wall is completed.
  • Page 37 STEP 12 Screwing the post and foot support The post is placed on foot support AD. There are two holes M10 in the foot support. Two holes must be drilled into the post. The positions of the holes are adjusted to the conditions at the installation site.
  • Page 38 STEP 13 Assembly of blades The blades are inserted into a structure and standing frame. First, insert the blades at both ends of the structure. Installation instructions Bioclimatic Pergola Agava SL...
  • Page 39 STEP 13.1 Inserting the blades The long axis of the blade is inserted into the profile with motor drive. The long axis of the blade is on the side of the blade where the cover with "ear" is located. Inserting the blade POSITION 2 Position after installing the longer axis (kingpin) J in in the motor drive frame.
  • Page 40 POSITION 2 Position 2 of the blade when both axis are inserted into the frame. Place a distance plastic bush N around the longer axis (kingpin) J. direction of movement POSITION 3 After installing the distance plastic bush, move the blade in the direction of the longer axis.
  • Page 41 STEP 13.2 Inserting the blades with connecting wire rope If the frame is longer than 4 m, some blades have reinforcement bindings inserted into their axis. Number of those blades depends on the lenght of L1, L2 profiles. Positions of these blades are determined by service holes (1) on the top of the longitudinal frame profile.
  • Page 42 STEP 13.3 Inclination of blades For water to outflow properly, the blades must have a certain inclination. The inclination of the blades differs between different Pergola Agava models. 160/28 The difference in blades position height is 0 mm. The inclination of the blades can be achieved by inclining the frame (STEP 8.1 and 8.2) 0 mm...
  • Page 43 170/36 The difference in blades position height is 4,5 mm. The blade is declining from Drive unit side. 4,5 mm 240/36 The difference in blades position height is 5 mm. The blade is declining from Drive unit side. 5 mm Installation instructions Bioclimatic Pergola Agava SL...
  • Page 44 STEP 14 Connection of blades to drive bar Fix the blades to driving bar with special step screw (L) inox profile STEP 14.1 Adjustment of closing of the blades On the side where the blades are still open, unscrew the blades. Move the inox profile 1 mm from the center towards the corner of the pergola, where the blades are not fully closed.
  • Page 45 STEP 14.2 Self test - Self learning of limit switches When you fix screws, make a "self-test" on Remote Control. Press P and hold it about 10s until it's signalled by a sound. DO NOT change the DIP configuration. This change would be signalled by a new intermittent sound and flashing of L3 on Teleco driver and would require a new...
  • Page 46 If the "self-test" failed and blades dont open and close correctly, you have to set them manually. Move the rotating lever to the both positions Follow the instructions for driving the drive (Chapter G). Finally leave your lever in a vertical position. side position side position vertical position...
  • Page 47 STEP 14.3 Remote control, settings and management Installation instructions Bioclimatic Pergola Agava SL...
  • Page 48 STEP 14.4 Connecting the sockets and testing integrated LED lights LED LIGHT Connecting of plug and socket on joint. TESTING LED LIGHTS Use the remote control and follow the instructions, OPTIONS chapter. Check if all LEDs are ON and OFF. When testing is complete, disconnect the connectors (AF).
  • Page 49 OPTIONS ZIP ROLLER BLIND Front view Guides of the roller (1), left and right, must be fixed on the posts (2). Use self-tapping screw. The outer side of the post and the outer side of the guide must be in the same plane. Section view A-A Section view B-B Installation instructions...
  • Page 50 OPTIONS ZIP ROLLER BLIND Open ZIP roller blind Cassette, that is mounted on the profile. Locate the setting tool with - and + point. TOP AND BOTTOM LIMIT SETTINGS: ZIP Rolo setting stick is used with electric drill machine to adjust TOP and BOTTOM Points. Use the remote control to lower ZIP roller to its available highest Point.

  • Page 51: Rain Sensor

    OPTIONS RAIN SENSOR The rain sensor set contains a sensor with wiring (1) and fastening elements (2). Rain Sensor is mounted on a suitable surface that is completely exposed to rain (for example, the upper surface of the frame for the blades). Signal cable in the sensor (3) is connected to the control unit (4) located in the W - profile.

  • Page 52: Wind Sensor

    OPTIONS WIND SENSOR The wind sensor set contains a sensor with wiring (1) and fastening elements (2). Wind Sensor is mounted on a verticale surface. The location of the accommodation must not be in the shelter. Signal cable in the sensor (3) is connected to the control unit (4) located in the W profile.
  • Page 53 OPTIONS WIND SENSOR Installation instructions Bioclimatic Pergola Agava SL...

  • Page 54: Temperature Sensor

    OPTIONS TEMPERATURE SENSOR with wiring - Mounting The sensor is placed in a suitable place. It can be inserted into the profile from the frame. The location of the accommodation must not be in the shelter. The sensor is designed to alert you to low temperatures.
  • Page 55 OPTIONS SLIDING PANELS Glass, Aluminium & Wooden slats Detailed assembly of Sliding panels is explained in a separate Manufacturing Guide. Installation instructions Bioclimatic Pergola Agava SL...
  • Page 56 ITEM TYPE LIST 2 Number of Mark on the pieces sketch Longitudinal frame profile with motor and holes for blades length = L with components: - motor unit, - drive unit inside the profile, - drive batten with screws Ø10/M6 x 19 and washers M6 - cover plates for service holes for motor &...
  • Page 57 Number of Mark on the pieces sketch Blade with components: - kingpin long and short - blade covers - sealing rubber Blade with LED light with components: - kingpin long with holes for cable - kingpin short - blade covers - sealing rubber - LED light, cable and connector Blade with connecting wire...
  • Page 58 Number of Mark on the pieces sketch Screw M10 x 20 inbus round head with collar Screw M10 x 35 inbus socket head cap Screw M6 x 16 inbus round head with collar Anchor bolt M12 x 135 4 + m Distance plastic bush Rubber washer Plastic caps Ø18 for screw...
  • Page 59 Number of pieces Remote control Rain sensor Wind sensor Temperature sensor Installation instructions Bioclimatic Pergola Agava SL...
  • Page 60 ATTACHMENTS Electric plans Pergola SL Motor DC24V Installation instructions Bioclimatic Pergola Agava SL...
  • Page 61 ATTACHMENTS Electric plans Motor DC24V Installation instructions Bioclimatic Pergola Agava SL...
  • Page 62 ATTACHMENTS Electric plans Motor DC24V Installation instructions Bioclimatic Pergola Agava SL...
  • Page 63 ATTACHMENTS Electric plans Motor DC24V ZIP Somfy Motor Installation instructions Bioclimatic Pergola Agava SL...
  • Page 64 ATTACHMENTS Electric plans Pergola SL Heater Installation instructions Bioclimatic Pergola Agava SL...
  • Page 65 LIST OF SERVICE INSPECTIONS Type of product Date of service inspection Signature, Stamp Type of product Date of service inspection Signature, Stamp Type of product Date of service inspection Signature, Stamp Type of product Date of service inspection Signature, Stamp Type of product Date of service inspection Signature, Stamp...
  • Page 66 Installation instructions Bioclimatic Pergola Agava SL...
  • Page 67 Installation instructions Bioclimatic Pergola Agava SL...
  • Page 68 EU, fully certified INOX STAINLESS STEEL To ensure optimal quality, Pergola Agava is in accordance with the following EN standards: SOLTEC d.o.o. Basis of Structural Design EN 1990: Obrtna ulica 9 EN 1991: Actions on structures General actions - Densities, self-weight, imposed loads for...
