Lab 12 gordian Owner's Manual page 6

6 Voltage FFT
7
Current FFT
8
Power factor
correction
configuration
9
EMI filter
effectiveness
configuration
10
EMI filter
topology
configuration
11
Standby current
setup
Lab12 gordian - Multifunctional Power Distributor / Conditioner
Frequency analysis of your line's
voltage. Inspect here the frequency
content of your AC voltage signal
(frequency range 50Hz-7kHz).
Frequency analysis of your system's
current. Inspect here the frequency
content of your AC current signal
(frequency range 50Hz-7kHz).
Configures the power
correction that your filter performs.
Configures the
effectiveness.
Configures the EMI filter topology.
Configures the standby current of
your system.
Push the rotary knob to inspect the frequency
content of your voltage signal. You can see the
gain of each frequency band by rotating the
knob.
Push again to go back to the main menu
navigation.
Push the rotary knob to inspect the current
content of your current signal. You can see the
gain of each frequency band by rotating the
knob.
Push again to go back to the main menu
navigation.
factor Push the rotary knob to select among the
available power factor configurations. See
paragraph
configuration' below for more detailed
information.
Push the button again to lock your selection.
EMI filter Push the rotary knob to select among the
available effectiveness levels. Read paragraph
'Emi filter configuration' below for more
detailed information.
Push the button again to lock your selection.
Push the rotary knob to select among the
available filter topologies. Read paragraph
'EMI filter configuration' below for more
detailed information.
Push the button again to lock your selection.
Press and hold the rotary knob to update the
standby current of your system. See paragraph
'Operation modes' below for more detailed
information.
'Power factor correction
Page 6 of 10
