Vislink ARTR Manual

Antenna retractor unit

Hide thumbs

page of 38

/ 38
Bookmarks

Quick Links

Download this manual

Vislink, Waterside House, Earls Colne Business Park, Colchester, Essex, CO6 2NS, UK

Telephone: +44 (0)1442 431300 ● Facsimile: +44 (0) 1494 775356 ● Email: sales@vislink.com ● Website: www.vislink.com

Company Registered in England & Wales no. 10523708 ● VAT registration no. GB 260 012 169

Registered Office: Waterside House, Earls Colne Business Park, Colchester, Essex, CO6 2NS, UK

Need help?

Do you have a question about the ARTR and is the answer not in the manual?

Questions and answers

Summary of Contents for Vislink ARTR

Page 1 Vislink, Waterside House, Earls Colne Business Park, Colchester, Essex, CO6 2NS, UK Telephone: +44 (0)1442 431300 ● Facsimile: +44 (0) 1494 775356 ● Email: sales@vislink.com ● Website: www.vislink.com Company Registered in England & Wales no. 10523708 ● VAT registration no. GB 260 012 169...
Page 2 The information contained in this manual remains the property of Vislink and may not be used, disclosed or reproduced in any other form whatsoever without the prior written permission of Vislink. Vislink reserves the right to alter the equipment and specification appertaining to the equipment described in this manual without notification.
Page 3 05/2016 No technical changes. Added new Figure 2-3 to included extended length version actuator arm specification ARTR-ASSY-7011. 11/2017 Updated company information. Included standard safety section. Issue No: C Page: iii Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
Page 4 AARTR-ASSY-5003 Actuator Arm Remote Control Unit ..........10 Figure 3-3 ARTR-ASSY-5002 Terminal Box ..................10 Figure 4-1 ARTR - Remote Unit Cable Assembly ................12 Figure 4-2 ARTR - Remote Unit Cable Assembly ................13 Figure 4-3 ARTR - Remote Power Cable Assembly ............... 14 Figure 4-4 Actuator Sensor Cable Assembly ................
Page 5 (council/authority) environmental waste site. For details, contact your local authority/recycling center. NOTE: In Europe dispose of all equipment in accordance with the European Environmental directive. Issue No: C Page: 1 Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
Page 6 It is important to note that the guidelines adopted differ throughout the world and are from time-to-time re-issued with revised guidelines. For Vislink use, a maximum power density limit (w) of 1w/m² is to be applied when calculating minimum safe working distances.
Page 7 Different power density / frequency characteristics are presented in the two documents. To avoid complexity and to avoid areas of uncertainty, Vislink recommends the use of a single power density limit across the frequency range 100 kHz to 300 GHz. The 1w/m² power density limit we recommend satisfies the most stringent of the guidelines published to date.
Page 9 Refer to Figure 2-1. The retractor unit weighs 5.5kgs (12.1lbs) excluding the weight of the microwave antenna, looms and remote control. Issue No: C Page: 5 Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
Page 15 ASTM D-2000 classification CH, DK, DJ Retractor Cover:  Carbon Fibre Pre-Preg Resin MTM58B  Service Temperature up to 120°C  MTM58B is self-extinguishing when tested to FMV5302/ISO3795 Issue No: C Page: 11 Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
Page 23 The effect of the retractor unit on the structure of the helicopter is negligible, since the retractor unit is lightweight 5.5kg and is mounted externally on the skid of the helicopter. Issue No: C Page: 19 Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
Page 25 No customer serviceable items or components are supplied for the antenna retractor unit, looms or remote control b. The retractor actuator can be replaced as a unit Issue No: C Page: 21 Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
Page 27 WARNING: To avoid personal injury, ensure all moving parts are suitably secured before attempting to transport the assembly. WARNING: Ensure you take all necessary precautions while lifting and carrying the assembly. Figure 7-1 Assembly Handling Diagram Issue No: C Page: 23 Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
Page 35 For 6W Connector pinout please refer to table above. The interconnecting loom has pin to pin connectivity. PINOUTS FUNCTION COMMENTS +28V DC Aircraft supply, internally fused and reverse polarity protected Not Connected Table B-2 Hand Control Unit Pinout Table Issue No: C Page: 31 Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
Page 36 NOTE: You must provide adequate +28vdc protection if the hand controller is not being used. Figure B-1 Hand Control Wiring Diagram Issue No: C Page: 32 Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
Page 37 ARTU Antenna Retractor Unit BCAR British Civil Airworthiness Requirements LEDs Light-Emitting Diodes Ministry of Defence EASA European Aviation Safety Agency DCIS Design Change Instruction Sheet Issue No: C Page: 33 Ref: ARTR-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink...
