AS-4
Audio Source DAB/FM/BT/USB
Item ref: 952.984UK
User Manual
Version 1.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Adastra AS-4

  • Page 1 AS-4 Audio Source DAB/FM/BT/USB Item ref: 952.984UK User Manual Version 1.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
  • Page 2 Introduction Thank you for choosing the Adastra AS-4 DAB/DAB+/FM tuner with Bluetooth and USB player as a professional audio source. This unit is designed to offer high quality audio for background music systems. Please read this manual to gain the best results from your product and avoid damage through misuse.
  • Page 3 Connect the output from the AS-4 to a mixer or amplifier line input using the RCA output connectors (18) Connect the supplied antenna lead (or suitable external aerial) to the DAB/FM Antenna connector (17)
  • Page 4 SW version [displays current software version] DAB Mode The AS-4 is compatible with DAB and DAB+ radio broadcasts. The display will show the current selected station Tune into the available DAB/DAB+ stations via the “Station scan” menu. Press the MENU button in DAB mode and the display will show as follows…...
  • Page 5 Up to 20 preset DAB/DAB+ stations can be stored for quick access. Press the PRESET button (11) and navigate to a preset via the +/- buttons or TUNING dial (12, 13, 14) Press and hold the TUNING dial to save the current tuned station to the selected preset.
  • Page 6 Open the Bluetooth menu on the sending device and search for a Bluetooth ID “adastra AS-4” Select to pair with this device and if successful, the AS-4 display will stop flashing and show “Connected” If a previously paired sending device is in range, the AS-4 will connect automatically.
  • Page 7 Remote Control The AS-4 is supplied with a handheld I.R. remote control, which has similar controls to the front panel with some extra features… POWER On/standby SOURCE Select DAB/FM/BT/USB/AUX PAIRING In Bluetooth mode, disconnects paired device 0 – 9 Direct preset selection (1 to 10)
