USER GUIDE
ATTENTION!
SMARTSCORE requires SMARTSPEED, SMARTSPEED LITE or SMARTJUMP PDA software
version 2.96 or greater. Please check our software version, and download any required upgrades free
from the Fusion Sport website.
© Fusion Sport 2011, All Rights Reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fusion Sport Smartscore
Summary of Contents for Fusion Sport Smartscore
- Page 1 USER GUIDE ATTENTION! SMARTSCORE requires SMARTSPEED, SMARTSPEED LITE or SMARTJUMP PDA software version 2.96 or greater. Please check our software version, and download any required upgrades free from the Fusion Sport website. © Fusion Sport 2011, All Rights Reserved ...
- Page 2 SMARTSCORE User Guide 2 PREPARING YOUR SYSTEM FOR USE WITH SMARTSCORE Like your SMARTSPEED or SMARTSPEED Lite units, SMARTSCORE units are wireless and come pre‐ programmed with their own unique unit ID. The IDs used for SMARTSCORE units are higher than for other gates (usually greater than 10), and you need to ensure that your system settings permit units of this high ID. In order to ensure that you system is ready, please follow these simple steps – Start SMARTSPEED software on PDA Go to Options ‐ General Set the “Max ID” to include your SMARTSCORE unit ID (16 is usually sufficient). Press “Apply” and return to the main screen. Your SMARTSCORE unit is now ready to use. Please ensure the unit is charged prior to use. QUICK START GUIDE 1. Turn on your SMARTSCORE unit by flicking the switch located on the bottom of the unit. Once turned on, the words “Fusion Sport” will scroll across the screen. 2. Turn on the gates and other devices that you will use for the session 3. Start your SMARTSPEED software with Grabba Sleeve connected (as for a normal session) and Press “Start New Session” 4. Press Scan 5. Your SMARTSCORE units will appear in the scan list. If the units do not appear, please refer to the troubleshooting section below. © Fusion Sport Pty Ltd, 2011, All Rights Reserved ...
- Page 3 7. Press OK and then proceed to run your session as usual. 8. When your session is finished turn the unit off and recharge prior to next session. SMARTSCORE CONFIGURATION SCREEN After selecting your team the SMARTSCORE configuration box will be displayed. When only one SMARTSCORE unit is being used in the session, (pictured left below), simply choose the result you would like the SMARTSCORE to display during the session, and press OK. If multiple SMARTSCORE units are being used, and you are using multiple tracks, you need to configure which display is in which track. 1. Press the “Show ID” button 2. The SMARTSCORE units will now display their unit ID on their screens 3. Choose which track you would like each unit ID to work with by adjusting the “track” value. If you are using multiple SMARTSCORE units in only one track, you do not need to adjust the track value. 4. Choose which result you would like each unit to display 5. Press OK and proceed with the session Single SMARTSCORE unit detected Multiple SMARTSCORE units detected © Fusion Sport Pty Ltd, 2011, All Rights Reserved ...
- Page 4 SMARTSCORE User Guide 4 CHARGING & MAINTENANCE SMARTSCORE should be expected to operate for up to 15 hours per charge under normal use. It is however recommended that it be charged prior to each use, and this will not develop any kind of battery memory. When connected to the supplied 12V charger, a RED light on the bottom of the unit will indicate that it is charging. When fully charged, this light will turn green. IMPORTANT NOTE – USING SMARTSCORE IN WINDY CONDITIONS The SMARTSCORE is susceptible to wind and care must be taken when using the units in even moderately windy conditions. Please note that damage to the unit as a result of falling over is NOT covered by the included warranty. If you are using SMARTSCORE outdoors and wind is a possibility, we recommend securing the unit using one of the following techniques – 1. Set the tripod to only one height extension, and angle the display up towards the athlete (picture below); 2. If on grass, use a tent peg to secure the tripod to the ground through the hole located on the tripod leg; or 3. Use sandbags or other weights to anchor the tripod to prevent it from tipping. © Fusion Sport Pty Ltd, 2011, All Rights Reserved ...
-
Page 5: Troubleshooting
SMARTSCORE User Guide 5 TROUBLESHOOTING Problem Possible Cause Solution Check channel of SMARTSCORE unit using SMARTSCORE unit does not Unit is on different SMARTSETUP (tutorial available on website support appear in Scan list channel to base unit page) Unit is not charged Recharge unit using the 5V charger provided System Max ID is too Check system Max ID as per the first section of this low to discover unit manual SMARTSCORE unit stops Unit battery is too Recharge unit using the 5V charger provided (rescan working during session low of system is not necessary) SMARTSCORE battery voltage SMARTSPEED PDA Please visit the Fusion Sport website support page to is shown as critically low in software is out of download the latest version of SMARTSPEED or SCAN page, despite it being date SMARTSPEED LITE for your system. charged If you require any assistance please contact support@fusionsport.com ...
