Tempest MVU-60 Operation Manual

Mobile ventilation unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
60" Mobile Ventilation Unit
Operation Manual
Read and understand all information in this manual before operating the MVU.
For questions and additional information, contact the Tempest Technology
factory at:
Tempest Technology Corporation
4708 N. Blythe Avenue
Fresno, California 93722
United States of America
Tel. +559-277-7577
Fax. +559-277-7579
Email
response@tempest.us.com
Internet
www.tempest.us.com
Copyright20 Tempest Technology Corporation
(Rev: 8.10.2020.1)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVU-60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tempest MVU-60

Summary of Contents for Tempest MVU-60

  • Page 1 60” Mobile Ventilation Unit Operation Manual Read and understand all information in this manual before operating the MVU. For questions and additional information, contact the Tempest Technology factory at: Tempest Technology Corporation 4708 N. Blythe Avenue Fresno, California 93722 United States of America Tel.

  • Page 2: Table Of Contents

    Water Misting System…………………………………...……………... MVU Systems ……………………………………………...……...……. Control Panel Features and Operation ………………………………. Starting and Stopping Instructions ……………………………...…... Fluids and Filters……………………………………………...……...… MVU Maintenance Schedule …………………………………...…… MVU Troubleshooting Guide ………………………………………... Spare Parts List ……………………………………….…………………. Electrical Wiring Diagrams …………………………….………………. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 3 The information contained in this operation manual, images, and data correspond to the product as of the date it was written. The Tempest MVU is in a continuous cycle of development and improvement. We reserve the right to make any changes or improvements that we consider to be appropriate.
  • Page 4 If your device should be equipped with different equipment that is not itemized or described in these operating instructions, please notify Tempest Technology. You will be informed by our technical staff about the correct operation and maintenance.

  • Page 5: General Information

    The MVU may only be serviced by personnel who have been properly trained in the hydraulic and operating systems maintenance. Ongoing training with the MVU as well as education through specialty training will guarantee proper performance and reliability. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 6: Warning Signs And Symbols

    It means that injury potential exists. Follow all security warnings as well as the accident prevention instructions! Meaning Indicated prevent personnel DANGER! extensive property damage. Injury Danger! Special statement to prevent property damage and promote general cautious ATTENTION! measures. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 7: Safety Measures

    Duration Sound Exhaust fumes can cause severe Pressure health damage! Level Do not operate the ventilator in a closed, unventilated room! Dangerous Exhaust exposure to carbon monoxide (CO) can Fumes result! Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 8 Protection Only operate the ventilator if all Devices protection devices and safety guards are in place! Always disconnect the battery cables before removing any protection devices during inspection periodic maintenance. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 9 MVU. Maintenance Maintenance and service should only be conducted by persons who are properly trained and know the safety precautions and accident-prevention procedures. Disengage the battery cable prior to performing any service or maintenance. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 10 When connecting of the battery, – first install the cable to the positive terminal, and then the cable to the negative terminal. No metal objects should be placed on the battery – this creates the danger of a short circuit. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 11 Battery acid is extremely corrosive, therefore:  Wear hand protection.  Wear eye protection. unloaded battery freeze, therefore store it where it will not freeze! Disposal Properly recycle old batteries in an authorized recycling facility. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 12 Tempest Technology Corporation may be used. The use of spare parts and accessories that do not come from Tempest Technology Corporation or are not tested and approved by Tempest, can adversely affect the durability and...
  • Page 13 Maintenance problems occur during Support and maintenance service Service ventilator, please contact: Tempest Technology Corporation 4708 N. Blythe Avenue Fresno, CA 93722 Tel: +559-277-7577 Fax: +559-277-7579 E-Mail: response@tempest.us.com Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 14: Mvu Specifications

    Shroud Diameter: 60 inches Shroud Material: Steel Impeller: 7-blades, aluminum Blower Performance Impeller Speed: 1,160 RPM maximum Output at fan outlet: 129,000 CFM at the outlet Total Air Output: 150,000 CFM with entrained air Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 15 Safety Features  Emergency shut-down switch (entire system).  Steel fence running along both sides and end of the scissors platform.  Acoustic warning during lowering of fan unit. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 16: Water Misting System

    The finely dispersed droplets of the water vapor absorbe heat, inert fumes, and wash- down hazardous vapors. Flow rates may be decreased or increased if so desired. The heat absorption capacity amounts to 23,500 BTU/sec. Water line connection, 1¼” FPT ball valve. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 17: Mvu Systems

    The Master Disconnect turns off all power to the control panel. It is located on the right hand side of the MVU control panel. The Master Disconnect Switch should be OFF during storage of MVU. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 18 The locking pin must be released prior to operating the MVU. The locking pin is located on the operator side of the MVU at the top of the scissors lift platform. Locking Pin Engaged Locking Pin Released Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 19: Control Panel Features And Operation

    Hydraulic Filter Warning Light Emergency Stop Warning Light Hydraulic Level Warning Light Compartment Light Switch Hydraulic Temperature Warning Light Fan Start/Stop Switch Scissors Lift Up/Down Fan Tilt Forward/Backward Fan Rotate Left/Right Fan Speed Control Local/Remote Control Switch Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 20 DO NOT rotate ventilator while operating at high fan RPM. Reduce fan speed before rotating. Local/Remote Control Set switch to LOCAL if using the control panel to operate MVU. Switch Set to REMOTE if using the remote control. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 21 4 Fan Unit Rotate LEFT = Rotate Left / RIGHT = Rotate Right 5 Fan Speed INC = Faster Speed / DEC = Slower Speed 6 Emergency Shut-Down Shuts Down Hydraulic System and Fan Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 22: Starting And Stopping Instructions

    You can decrease the fan speed to the desired speed rate by momentarily turning the fan speed switch to the decrease position. With each momentary turn of the switch to decrease, the fan speed will decrease until minimum is achieved. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 23 Panel is set to display engine RPM, engine temperature, volts, engine oil pressure, DEF tank fluid level %, and soot % in exhaust treatment system. Note; see the MCP-20-R2 operations manual for additional engine control panel information. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 24: Fluids And Filters

    Fuel, DEF, and Hydraulic Fluid Diesel tank filler cap DEF tank filler cap Hydraulic fluid tank filler cap In-tank hydraulic filter Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 25 From under the trailer, connect a hose from the drain valve on the engine oil pan and into a waist container. Open valve to drain the oil. Close the valve and remove the hose when finished. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 26: Mvu Maintenance Schedule

    7. Lubricate yoke lift cylinders (4 places) (See next page) Every 1,000 Hours or 1 Year 1. Replace In-Tank Hydraulic Oil Filter Element Every 2,000 Hours or 2 Years 1. Replace Hydraulic Air Intake Filter Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 27 C. Rotation Bearing Zerk x 2 D. Fan Tilt Bearings (X2) IMPORTANT: Lubricate with a high NLGI no. @ Lithium-base grease having rust inhibitors and antioxidant additives, and a minimum oil viscosity of 500 SUS at 38°C (100°F) Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 28: Mvu Troubleshooting Guide

    Troubleshooting Guide Follow these instructions if any of the systems on the MVU are not working properly. If the problem cannot be resolved, please contact Tempest Technical Support at (559) 277-7577 (M-F 8 a.m. – 5 p.m. PST). PROBLEM: The rotation system does not turn The rotation system is electrical and operates via the control panel or remote switch.
  • Page 29 YELLOW LIGHT: Hydraulic Oil Level 1. Oil level is low (below sight glass). 2. Gauge is malfunctioning. RED LIGHT: Emergency Fan Stop 1. Emergency switch at cabinet or remote control is activated (Pushed IN). 2. Relay malfunction. Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 30: Spare Parts List

    Switch Keyed Start Tempest 582-003 3 Position Green Light Tempest 582-004 MVU Filters and Fluids Hydraulic System Brand Part Number In-Tank Filter Schroeder #K10 Hydro Pump Filter Brueninghaus Hydro. #91530/02601380 Air Intake Filter Schroeder #ABF-3/10-F Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)

  • Page 31: Electrical Wiring Diagrams

    X3:2 ROTATE X4:1 X4:2 X4:3 FIELD X4:4 C1-1/20 C1-2/21 C1-3/22 C1-4/23 SV1A X2-1 X2-24 SV2A C1-5 C1-6 X2-2 RED./WHT C1-7 SV2B X2-3 RED/BLK SV3A C1-5 C1-8 X2-4 WHT/BLK C1-9 SV3B X2-5 C1-5 C1-16 C1-17 Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 32 POWER PUMP COIL + V FAN ENABLE (ON) X2-14 PUMP COIL - V CAN HIGH X2-15 ORA/BLK CAN LOW SS11 FAN DECREASE C1-13 C1-14 ECU-0809 CONTROLLER C1-15 SS12 FAN INCREASE MURPHY MURPHY C1-XX JP-46 Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 33 Hydraulic Panel Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
  • Page 34       Manufacturer  Tempest Technology Corporation  4708 N. Blythe Avenue, Fresno, CA 93722  USA      t: +1.559.277.7577   •   f: +1.559.277.7579   •   response@tempest.us.co m    www.tempest.us.com  All information provided in this operations manual is subject to change without notice.   Note: Unauthorized repair or modification of the factory assembly or parts voids the warranty.  Copyright20 Tempest Technology Corporation (Rev: 8.10.2020.1)
