ADS Technologies USBX-2020 Technical Specifications

USB Turbo 2.0 Web Cam
Technical Specification Sheet
USB 2.0 offers a 480 Mb/sec connection speed. This fast data transfer speed
means the Turbo 2.0 camera transfers the video from the camera to your PC
without any video compression. No video compression coupled with a high
quality CMOS and a commercial grade glass lens all combine to bring you the
highest quality video from a desktop camera.
Features:
- USB 2.0 Desktop Camera
- Capture Motion video at up to 640 x 480 @ 30 fps
- Backward compatible to USB 1.1 (160 x 120 resolution)
- SnapShot button for Still Image capture
- Durable metal Tri-pod Mount – mount to any standard tripod
- Includes adjustable desktop tripod with extendible legs for stable
positioning of camera
- Compatible with Microsoft NetMeeting, Windows Media Encoder, Movie
Maker, Yahoo Messenger, IVisit, Video Studio 6 and many other video
conferencing and editing applications.
CMOS Image Sensor
- Hynix HV7131E1
- Single chip color image sensor with 8 bit ADC
- 640 x 480 @ 30 frames per second
- 644 x 484 effective pixel array
- 1/3 Inch optical format
- High efficiency R/G/B color photo sensor
- Clock speed up to 15 MHz
- Low light sensitivity: 1.7V/ LUX.
- Automatic Gain control
- Anti-color blooming circuit
- Auto or manual White Balance
Lens:
- Glass commercial grade lens
Wavelength: λ - 400-700 mm (color)
-
- Focal Length: f – 6.0 mm
- Field of view: 52°
ADS Technologies, Inc.
