ADS Technologies PYRO API-200 Technical Specifications

PYRO Web Cam
API-200/203

Technical Specifications:

CCD image sensor
Optical size
Number of effective pixels
Interface formats
Video modes
Frame rate
Brightness
White balance
Focal length
Back focal length
F #
Focus area
Angle of view
Distortion
Image Controls
Sony CCD Description:
The imager is a 1/4-inch optical interline CCD solid-state image sensor with a square pixel array
which supports VGA format. Progressive scan allows all pixel signals to be output independently
within approximately 1/30 second. This chip features an electronic shutter with variable charge-
storage time, which makes it possible to realize full-frame still image without a mechanical
shutter. High resolution and high color reproductivity are achieved through the use of R, G, B
primary color mosaic filters. Further, high sensitivity and low dark current are achieved through
the adoption of HAD (Hole-Accumulation Diode) sensors.
Features:
• High horizontal and vertical resolution (both approx. 400TV-lines) still image without a
mechanical shutter.
• Square pixel
• Supports VGA format
• Horizontal drive frequency: 12.27MHz
• R, G, B primary color mosaic filters on chip
• High resolution, high color reproductivity, high sensitivity, low dark current
• Continuous variable-speed shutter
• Low smear
Sony
1/4 inch format
659(h) x 494(v),
640 x 480, 320 x 240, 160 x 120
YUV 4:1:1, 4:2:2, 4:4:4, RGB 24-bit
30 frames/sec. at 640 x 480 format
Automatic or manual controlled
Manual adjust, or automatic
4.00 mm
3.50 mm
2.0
1.0 cm to infinity
62 degree, diagonal
<-12.0 %
Brightness, Contrast, Saturation,
Sharpness, Gamma, Exposure, White
Balance and Backlight compensation
