Control Panel - Coltech MDDE-10DEN3-QA3 Original Instructions Manual

Control panel

9 10
9. [ ] Indicates when the water reservoir is full.
10. [ ] Indicates the following:
- Steady glow: Automatic defrost function has been activated.
Refer to the Automatic defrost feature section.
- Flashing: The ambient temperature is too low, i.e. below 5 °C (41 °F).
Or the air humidity sensor or temperature sensor is defective.
Note: If the indicator flashes despite the room temperature being above 5 °C,
unplug the mains lead and wait for a few seconds. Plug the mains lead back in
again. If the indicator continues to flash, contact Customer Services.
11. [ ] Indicates that the continuous dehumidification function is activated.
12. Humidity selection indicators.
13. [ ] Select continuous dehumidification, 40%, 50% or 60% humidity.
14. [ ] On/off.
Placement
• The dehumidifier is only intended for normal domestic use and only in the manner
described in this instruction manual.
• Do not use the dehumidifier in a room in which the temperature might fall to
below 5 ºC.
• Make sure that the dehumidifier is standing firmly on a flat surface capable of
supporting its weight even when the water reservoir is full.
• Make sure that the mains lead is easily accessible and is not damaged by sharp
edges or is crushed in any way during use.
• Extra caution should taken be when the dehumidifier is used in the same
environment as infants, small children and the elderly.
• The dehumidifier should be placed where it can draw in air from the entire house.
• All interior doors should be opened. Close exterior doors and windows.
• If any part of your house suffers from severe humidity, the dehumidifier can be
placed there first and then moved to another part of the house later.
• Position the dehumidifier where the air can circulate freely, allow at least
20 cm of air space on all sides.
• Never place the dehumidifier next to a radiator or heating appliance.
11 12
11
13 14
