Summary of Contents for Radio Flyer 910
- Page 1 #910 Connector Checks...
- Page 2 Functional Issue: Car Doesn’t Run First, try the following… 1. Remove the clear speed switch cover, set the car in speed 2 2. Insert the battery 3. Make certain the forward button is fully depressed 4. Hold the pedal down for a 3-5 seconds 5.
- Page 3 Removing the Rear Panel 1. Flip your car on its side 2. Remove 8 screws from rear valence panel 3. Press down on the snap to remove the panel...
- Page 4 Connector Check A Complete this step if… Battery will not charge while in the car Skip this step if… The battery charges in the car 1. Try charging the battery outside of the car to make sure it works 2. Unhook this connector and then reconnect it 3.
- Page 5 Connector Check B Complete this step if… The battery charges while in the car, but the car won’t function at all 1. Disconnect both connectors 2. Reconnect both connectors 3. Press the car’s pedal, see if the lights on top of the battery light up...
- Page 6 Removing the Front Right Wheel First pull the wheel cover Use an adjustable Remove the washer and off. If you can’t do it by wrench or a 17 mm the wheel. hand, use a screwdriver socket wrench to and pry the cover off. remove the nut holding the wheel on .
- Page 7 Connector Check C Complete this step if… 1. Remove the front right wheel The battery can be charged in the car, but both wheels don’t spin 2. Disconnect all 3 connectors pictured, Skip this step if… hook them back up 3.
- Page 8 Connector Check D Complete this step if… One wheels spins, or Check C has been completed and the car still doesn’t work 1. Disconnect both connectors 2. Hook the connections back up 3. Press the car’s pedal, see if the wheels spin...
