UBC1319AA00 Quick Installation Guide
•
LED BEHAVIOR
LED

FRONT PANEL

DS/US
ON Solid White
(downstream/
upstream)
INTERNET
ON Solid White
Blinks White = WPS button is
pushed
WPS
(otherwise will be OFF)
On Solid White = WiFi Enabled
WIFI
OFF = WiFi Disabled
On Solid White = eMTA
Registered Successfully
PHONE
OFF = eMTA Disabled
POWER ON Solid White
REAR PANEL
ON Solid
TEL Blinks Green
OFF = Telephone is NOT connected
ON Solid
ETH 1-2 Blinks Green
OFF = Ethernet device is NOT connected
Normal State
(
LED ECO Mode Enabled)
Green = Telephone is connected
= Telephone call in progress
Green = Ethernet device is connected
= Data being transmitted
Normal State
(LED ECO Mode is Automatically Disabled)
Blinks White = Problem on the network and
OFF
device cannot link properly
OFF Blinks White = CPE fails to obtain IP address
OFF N/A
OFF Blinks White = WiFi initialization issue
OFF Blinks White = eMTA registration failed
ON Solid White N/A (but will remain ON if power connected)
Faulty/Alarm State
