Please substitute the following sheet for pages 12-13 in the accompanying manual:
4 Position Dip Switch
POSITION:
UP
DOWN
Switch 1 - TV Format:
Set this switch to match the television/video format for your country. Generally, North America,
Japan and Taiwan are set to NTSC. Europe, Africa and Australia are set to PAL. See the back of
the user guide for a complete listing of every country.
Switch 2 and 3 - DV Source / Operating System Selection:
The device is factory set to be most compatible to the 1394 timing for Windows XP.
You can easily set the dip switches to match the timing of the device or operating system you are
using.
DV SOURCE /
OPERATING SYSTEM
DV Camcorder
Windows 2000
WinXP, Win98SE, WinME
Mac
Switch 4 - Locked Audio:
Switch to Locked Audio mode to ensure that audio and video synch remain locked during
video capture.
Audio is set to capture at 16-bit, 48 kHz.
1
PAL
See Below
NTSC
See Below
2
See Below
See Below
SWITCH 2
Down
Down
Up
Up
3
Unlock Audio
Locked Audio
SWITCH 3
Down
Down
Down
Hardware
4
Up
