- Page 1 User Manual Securope 2012 Horizontal DOC039-UK-19.07.15 Fallprotec S.A. 43-45. ZA Op Zaemer. L-4959 Bascharage. Luxembourg T +352 26 55 09 30 F +352 26 55 09 30 55 marketing@fallprotec.com...
-
Page 2: Table Of Contents
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 Table of content Description ........................................4 1.1. General ........................................4 1.2. Overall scheme of the equipment .............................. 4 1.3. Description of the components ..............................5 1.3.1. The wire rope ....................................5 1.3.2. Terminale anchors ..................................5 1.3.3. - Page 3 User Manual Securope 2012 horizontal DOC039-UK-19.07.15 9.1.6. Prohibited use .................................... 22 9.1.7. Instructions for storage and maintenance ........................22 9.1.8. Operational life of the installation ............................23 Recommandations relating of periodic review procedure ......................24...
-
Page 4: Description
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 1. Description 1.1. General The SecuRope Lifeline System is permanently installed on a building or other structure which needs to be maintained by personnel exposed to the risk of fall when carry out their maintenance work. -
Page 5: Description Of The Components
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 1.3. Description of the components 1.3.1. The wire rope The wire rope 8 mm diameter, construction 7x7 , material AISI 316 Fig. 1 LDV006 wire rope 1.3.2. Terminale anchors Terminal anchors are installed at the ends of the line, material AISI 316 Fig. -
Page 6: Glider
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 1.3.4. Glider The glider allows the user to attach himself on the line. The glider may be placed and removed from the line. Material AISI 431. Fig. 4 LDV001 Glider 1.3.5. Captive glider The captive glider is permanently attached to the line. Material AISI 316. -
Page 7: Crimping Ring 100Mm
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 1.3.7. Crimping ring 100mm The crimping ring serves as a stop for the line. Fig. 7 LDV008 Crimping ring 100mm 1.3.8. Line tensioner The tensioner serves as a stop for the line and allows the tensioning of the line. -
Page 8: Turnbuckle
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 1.3.10. Turnbuckle The turnbuckle allows end to end attachment of the wire rope in case of a closed loop. Fig. 10 LDV138 Turnbuckle 1.3.11. Cable guide for curve The cable guide for curve is used in conjunction with the corner plate and allows the tensioning of the cable from one of the ends of the line. -
Page 9: Marking
An identification plate is installed near to the zone where the users attach themselves to the line. Our web portal Fallprotec Assistant generates the plate. It can be printed on a sticker provided by Fallprotec (climate proof). The commissioning date must be on ... -
Page 10: End Anchor
DOC039-UK-19.07.15 2.2. End anchor Engraving shows : - The name of the manufacturer : Fallprotec - The name of the componant : Terminal Anchor - The standard N° EN795 Type C : 2012 - The logo directing to read the user manual ... -
Page 11: Intermediate Anchor Neo
DOC039-UK-19.07.15 2.3. Intermediate anchor NEO Engraving shows : - The name of the manufacturer : Fallprotec - The name of the componant : Terminal Anchor - The standard N° EN795 Type C : 2012 - The logo directing to read the user manual ... -
Page 12: Captive Glider
Securope 2012 horizontal DOC039-UK-19.07.15 2.5. Captive glider Engraving shows : - The name of the manufacturer : Fallprotec - The batch number (month/year) - The standard N° EN795 Type C : 2012 - The CE mark - The logo directing to read the user manual ... -
Page 13: Homologation
- Standard EN795:2012 - type C - Standard CEN/TS16415 (4 users max) : Conformity certificate n°13.6.0803/A The Securope 2012 life line has been subjected to a CE type examination by the notify body APAVE SUDEUROPE SAS 8 rue Jean-Jacques Vernazza Z.A.C. - Page 14 User Manual Securope 2012 horizontal DOC039-UK-19.07.15 The height of fall is the sum of the terms given below : : the deflection of the rigid anchor line Deflection : safety distance (1m) Safety Fall clearance : minimal height calculated and required in case of a fall...
-
Page 15: Structure On Which The Securope Is Installed
Securope 2012 horizontal DOC039-UK-19.07.15 If the height of fall is to large, Fallprotec advise mounting 20 mm crimping rings on both sides of each anchor means. The free length of cable can then be reduced to 5 times the distance between two successive anchors, see Fallprotec calculation software. -
Page 16: Personal Protective Equipment
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 7. Personal protective equipment The Securope lifeline should be used in conjunction with height safety PPE in accordance with EN354, EN355, EN361, EN362. Fig. 18 HAR010 Longe simple avec absorbeur Fig. 19 HAR018 / HAR013 Connecteur ½ tour... -
Page 17: Recommendations Relating To The Documentation Required After Installation
When several anchor points must be photographed for identification purposes, it is recommended to mark the anchoring devices with numbers and incorporate this numbering in the inspection records of anchoring device ground plan installation area. Fallprotec provides the installer with a model for the "Installer schematic plan"... - Page 18 Telephone N°: Installer Name : Installer chief: Adress : Telephone N°: Anchoring device Manufacturer : FALLPROTEC Model identification /type : Securope 2012 Building components Attachments / Studs Data of fixations Ø drilled hole Type : Depth Material : Torque...
-
Page 19: User Manual
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 9. User manual 9.1. Preliminary check The following checks are mandatory before using the SecuRope Lifeline. o The user of the lifeline must be in good physical condition, and not prone vertigo or giddiness. -
Page 20: Attach To The Cable
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 Fig. 21 Fall indicator not activated Fig. 22 Fall indicator activated 9.1.1. Attach to the cable The user attaches to the cable in an area where there is no risk of falling, in principle in the vicinity of one of the two end anchors. -
Page 21: Circulating Along The Lifeline
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 Once locking device is closed again under the action of the spring, the user is connected to the glider with a karabiner delivered with the glider. An energy absorber lanyard connects the glider to the harness. -
Page 22: Prohibited Use
• It is forbidden to use any another karabiner to attach the lanyard to the glider that provided by Fallprotec. The function of safety of the glider could be affected if the karabiner used is not the karabiner supplied by FALLPROTEC. -
Page 23: Operational Life Of The Installation
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 9.1.8. Operational life of the installation • All the components of the lifeline are manufactured from of stainless steel according to the AISI 316 / 431 / 304 , which have a great resistance to the atmospheric degradation. -
Page 24: Recommandations Relating Of Periodic Review Procedure
User Manual Securope 2012 horizontal DOC039-UK-19.07.15 10. Recommandations relating of periodic review procedure Periodic review of anchoring devices Manufacturer Visual review and Document relating identified? functional test to the available installation Controls of corrosion, deformation, cracking, loosened components, No visible Fixation... - Page 25 User Manual Securope 2012 horizontal DOC039-UK-19.07.15 Identification card of Securope Lifeline Type the equipment: Securope2012 lifeline Manufacturer : FALLPROTEC SA. 43-45, ZA Op Zaemer L- 4959 Bascharage Luxembourg Fax : +352 26 55 09 30 55 Email : ft@fallprotec.com www.fallprotec.com...
