4xem ENCLODHF Install Manual

Components:

Step 2: Pull the wire through the housing as
well. Insert the red (DC+) and blue
(DC-) plugs into the power sockets.
Make sure the red terminial is plugged into
"AC24+" and the blue terminial is plugged into
"AC24-".
Step 4: Screw the bridge to the chassis and
insert the power cable into the camera.
IPCAMENCLODHF
Aluminum Housing Assembly
Step 1: Pull the power wire through the
enclosure bracket.
Step 3 : Screw the dome on the fixing
bridge.
Step 5 : Put on the cover to complete the
asembly.
