- Page 1 User Manual DIGITAL WITH PUMP WITH OUT PUMP 101ME Tested and Certified by NSF International NSF/ANSI Standard 58 for the Reduction Claims Specified on the Performans Data Sheet.
- Page 2 WITH OUT PUMP Dear Customer, Thank you for choosing our product. We want Cebilon Reverse Osmosis System, manufactured in modern facilities with high quality standards to provide you with the best efficiency. Therefore, please read the entire user manual carefully and keep it as a reference.
-
Page 3: Table Of Contents
INSTALLATION WATER CONNECTION INSTALLING THE FAUCET WASTE WATER CONNECTION PRE-TESTS POINTS FOR ATTENTION MAINTENANCE FILTER REPLACEMENT PERFORMANCE DATA SHEET FILTER REPLACEMENT PERIODS CEBILON PARTS LIST TROUBLESHOOTING DIGITAL DISPLAY FUNCTIONS NSF CERTIFICATE MAINTENANCE CARD 20 - 21 AFTER INSTALLATION CHECKS CARD... -
Page 4: Osmosis, Osmotic Pressure, Reverse Osmosis (Ro) Process
Osmosis, Osmotic Pressure, Reverse Osmosis (RO) Process Osmosis is based on a semi-permeable The water level in the high concentration side membrane and a solution; the semi-permeable increases. This pressure arising from the membrane consisting of a thin membrane or a potential energy of this rising water column thin film allows some molecules or ions to pass is stabilized by the Osmotic Pressure. -
Page 5: Reverse Osmosis (Ro) Water Purification Systems
Mainly, pre-filtration is composed of reverse osmosis in the membrane, pH regulation and water storage processes which are the main elements of the system. Aura Unique Cebilon RO system consists of 3 interconnected pre-filters, membrane, pH regulator last filter, digital control group*, pump assembly and water tank * Applicable for 101 ME model. -
Page 6: Parts And Functions
Parts and Functions Abwasser / Mains Water Leitungswasser / Water with Sediment Eliminated Dekantiertes und entchloriertes Wasser / Water with Sediment and Chlorine Eliminated RO-Wasser / RO-Water Abwasser / Waste Water Cable Connection Colours White (Adapter) B Red (Solenoid Valve) C Green (Pump) Waste Water D Yellow (Low Pressure Switch) -
Page 7: Functions Of The Parts
Functions of the Parts Low Pressure Switch**, if the water is cut or if the pressure is lower than 0.2 bar (3 psi), it prevents unnecessary operation of the pump. 5M Sediment Filter (350003Z), it retains the substances and particles floating in water to make the water clear. -
Page 8: Field Of Use
Membrane Filter (349004Z) is the place where the reverse osmosis occurs. Solenoid Valve* controls the flow of water. When the water pressure in the tank A long film made of a semi-permeable material is wrapped onto a reel in two reaches a certain value, it closes the water inlet and prevents water being consumed layers. -
Page 9: Technical Specifications
• Aura Cebilon Reverse Osmosis System contains critical components that are required to be replaced periodically to purify the total dissolved solid materials (TDS) efficiently. To check the efficiency of the system, water from the appliance must be periodically tested. -
Page 10: Installation
Installation of your appliance must be made by Ihlas Authorized Services. 1- Measures should be taken against freezing. • Aura Cebilon Reverse Osmosis System contains 2- Waste water should not interfered with. critical components that are required to be replaced periodically to purify the total dissolved 3- When muddy (clay) water comes from the mains, solid materials (TDS). - Page 11 Installation scheme Leitungswasser / Mains Water RO-Wasser / RO-Water Abwasser / Waste Water 1 Cebilon 2 Water Inlet Valve 3 Appliance Water Inlet 4 Waste Water Outlet 5 RO Water Outlet (Clean Water) 6 24 V Input 7 Waste Water Bracket 8 Clean Water Faucet Applicable for 101 ME and 101 MD models.
-
Page 12: Water Connection
Water Connection • Close the mains water from the apartment inlet valve. • After draining the water left in the pipes from proper places, mount the three-way adapter to the mains by ensuring the sealing. • First, mount the 1/4 ball valve to the three-way adapter by wrapping a teflon tape in a position so that the valve is opened and closed easily (Figure 5.a). -
Page 13: Waste Water Connection
Waste Pre-tests Points Water • The adapter is plugged in after it is placed into the place where "24 Connection Attention V DC" is written on the appliance. In this case, it will not work due to lack of water and pressure in the system.** •... -
Page 14: Maintenance
Authorized Service Data Sheet will fall out of warranty. The life of the filters used in Aura Cebilon Reverse Osmosis System changes depending 101ME model system conform to NSF/ANSI on various factors with the amount of water 58 for the specific performance claims as... -
Page 15: Filter Replacement Periods
: +90 212 875 3664 Model No 101ME, 101MD, 101FG Aura Cebilon Reverse Osmosis System ! Daily capacity, efficiency rating and recovery raiting for 101ME model * Efficiency rating means the percentage of the influent water to the system that is available to the user as reverse osmosis treated water under operating conditions that approximate typical daily usage. -
Page 16: Cebilon Parts List
Aura Cebilon Reverse Osmosis System Parts List P. No Part Code Part Name P. No Part Code Part Name 351004Z Top Cover Panel 340006Z Auto Shutoff Valve*** 351003Z Top Cover 346003Z03 Pressure Pump** 351021Z Upper Body Back 350008Z Filter Housing Cover Group... -
Page 17: Troubleshooting
PROBLEM POSSIBLE CAUSES RECOMMENDED SOLUTION Foam in water or Air in the system. Air in the system is a normal occurrence after milky coloured initial installation. Sometimes, air caused by water. the mains may exist. This will return to normal after usage for a while. There is no Troubleshooting inconveniency for using this water. -
Page 18: Digital Display Functions
Digital Display Functions Figure. 11 a Figure 11 b DIGITAL DISPLAY FUNCTIONS* You can switch between modes on the digital screen by pressing the menu button. There are 7 modes available on the digital screen. These are; F MODE: Shows the instant water flow in litre/min. (Figure 11 a). 0 MODE: Shows the total water amount passing through the appliance in gallon. -
Page 20: Maintenance Card
MAINTENANCE CARD Customers Name Surname Installation Date PRODUCT SERIAL NO. SERVICE TELEPHONE Address Number of People in the Family Mains Water TUS Value REPLACED FILTERS Signature Recommended Filter Replacement Order TDS After TDS Before Service Personnel Name Surname Next Filter Date PRODUCT Filter Filter... - Page 21 Customers Name Surname Installation Date PRODUCT SERIAL NO. SERVICE TELEPHONE Address Number of People in the Family Mains Water TUS Value REPLACED FILTERS Signature Recommended Filter Replacement Order TDS After TDS Before Service Personnel Name Surname Next Filter Date PRODUCT Filter Filter Replacement Date...
-
Page 22: After Installation Checks Card
INSTALLATION CONTROL CARD O. No Points to Be Checked Yes No Have you measured the amount of chlorine in the mains water? Have you measured the hardness of water? Have you measured the TDS level of water? Have you measured the pressure of water? Is the tank pressure suitable? Have you counselled with the customer for the proper location of the appliance? Has the sealing been ensured for three-way adapter installation in full? - Page 23 Seller Company Information Company Name : Address Sales Date : Complies with WEEE Regulation This symbol on the product or packaging shows that the product should not be disposed of with normal domestic waste and should be transmitted to the collection points for recycling the electrical and electronic appliances.
- Page 24 FOR INFORMATION AND SUPPORT SERVICES Country Name of the Distributor Company BOSB Mermerciler San. Sitesi 7. Cad. No: 14 Beylikdüzü - İstanbul Telephone and Fax. Tel: 0212 875 35 62 Faks: 0212 875 36 64 www.iea.com.tr - info@iea.com.tr 358015ZEN TDF 583...
