Parts List - Casio TV-770B Service Manual & Parts List

LINEAR PCB
Item Code No.
Diodes
D100 2390 1176 Chip diode
D110 2315 0166 Chip zener diode
D150 2390 1176 Chip diode
D152 2390 1176 Chip diode
D155 2390 1302 Chip diode
D180 2390 1190 Chip diode
D500 2360 1344 Chip zener diode
D703 2390 0469 Chip diode
D705 2390 1358 Variable diode
D707 2360 1113 Chip zener diode
D800 2360 2919 Chip zener diode
D803 2390 0469 Chip diode
D805 2390 1253 Chip diode
Fuse
FU100 3632 0469 Fuse
ICs
IC200 2114 1827 Linear IC
IC300 2114 3332 Linear IC
IC500 2114 0182 Linear IC
IC600 2114 2464 Linear IC
IC700 2011 3514 LSI
Jacks
JK100 3501 8281 Jack
JK200 3501 5439 Jack
JK600 3501 5439 Jack
Transistors
Q101 2230 7011 Chip transistor
Q110 2230 7011 Chip transistor
Q111 2253 0308 Chip transistor
Q200 2252 0707 Chip transistor
Q300 2210 8026 Chip transistor
Q800 2230 7011 Chip transistor
Q801 2210 8026 Chip transistor
Q802 2230 7011 Chip transistor
Q803 2230 7011 Chip transistor
Q805 2253 0476 Chip transistor
Q806 2230 7011 Chip transistor
Switch
SW100 3412 0938 Slide switch
Converter
T100 3065 0672 DC-DC converter
Tuner
TU200 1013 5511 Tuner
Variable resistors
VR600 2765 1708 Volume
VR800 2765 2037 Volume
Notes: Q – Quantity per unit
R – Rank

PARTS LIST

Parts Name
— 6 —
Specification
MA152WK-(TX)
MA3047-L(TX)
MA152WK-(TX)
MA152WK-(TX)
MA153A-(TX)
ERA15-01Y
MA3330-M(TX)
MA157A-(TX)
MA329-(TX)
MA3082-M(TX)
MA3056-L(TX)
MA157A-(TX)
MA152WA-(TX)
PI-251001(F10)
M51348FP-T1
M52042FP-T1
MSC1169MS-K-620
NJM2070M-T1
MSM6625-02GSK-640F
HEC0811-010010
HSJ1456-01-210
HSJ1456-01-210
2SD601A-R(TX)
2SD601A-R(TX)
2SD1119-R(TX)
2SC4238-(TX)
2SB709A-R(TX)
2SD601A-R(TX)
2SB709A-R(TX)
2SD601A-R(TX)
2SD601A-R(TX)
2SD1149-S(TX)
2SD601A-R(TX)
ESD-11V231
LC12U-40
TEPU5-02
XV081PV1NB10K3017
XV081PV1NB20K3017
Q R
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 A
1 C
1 C
1 C
1 C
1 C
1 B
1 C
1 C
1 B
1 B
1 B
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 C
1 B
1 C
1 C
1 C
