Summary of Contents for Tractor Supply Shelton L-DN792SAL-1-A
- Page 1 Assembly Instructions Shelton set - Chair Item: L-DN792SAL-1-A...
- Page 2 SAFETY INFORMATION WARNINGS Paint on this product might peel off if it is mishandled. Use and carry it with care, and apply touch-up paint whenever necessary. Some parts may contain sharp edges. Wear protective gloves as necessary. CAUTIONS Chair Weight Capacity: 225 lbs. CARE AND MAINTENANCE Before using, clean the product completely with a soft, dry towel.
- Page 3 REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-800-643-0067, 8 a.m. - 8 p.m., EST, Monday - Friday. PART DESCRIPTION Chair Printed in China...
- Page 4 Assembly Instructions Shelton set – Table Item: L-DN792SAL-1-A...
- Page 5 Parts List Number Description Table Top Support Hardware List Number Description Q t y Image Bolt M6X20 Spring Washer M6 Flat Washer M6 Wrench M6...
- Page 6 Step 1：Attach leg (B) onto support (C), then connect with bolt (AA), spring washer (BB) and flat washer (CC). Number Description Image Bolt M6X20 Spring Washer M6 Flat Washer M6...
- Page 7 Step 2：Attach table top (A) onto leg (B), connect with bolt (AA), spring washer (BB) and flat washer (CC), then tighten all the bolts with wrench (DD). Number Description Image Bolt M6X20 Spring Washer M6 Flat Washer M6...
